Page 1 COBALT BOATS Owner’s Manual...
Page 2 We Wish You Safe and Happy Boating! Your Cobalt boat was built to meet or exceed all applicable boat building standards at the time of manufacture. Your Cobalt boat was inspected and certified prior to introduction, and periodic inspections of this model are conducted in-plant to ensure continued compliance.
Page 3: Table Of Contents
323 Owner’s Manual ABLE OF ONTENTS GENERAL INFORMATION WELCOME....................1-1 CERTIFICATE OF LIMITED WARRANTY ..........1-2 INTRODUCTION..................1-4 Intended Use ..................1-4 Craft Design Category................1-4 OWNER RESPONSIBILITY/WARRANTY PROCEDURE ......1-5 Before Operating .................. 1-5 Warranty Service Requirements ............1-5 Extended Service Agreement...............
Page 4 Before You Start................... 3-1 Fire/Explosion ..................3-1 FIRST-TIME OPERATION................. 3-1 FUEL ......................3-2 Fuel Requirements ................3-2 Fueling ....................3-2 LAUNCHING ....................3-5 Launching Checklist ................3-5 On the Water..................3-5 Boarding ....................3-5 Loading ....................3-5 Shipshape .................... 3-5 323 Owner’s Manual...
Page 5 VOLTAGE SENSITIVE RELAY (VSR) ............. 3-38 Features ..................... 3-38 CUDDY CABIN ACCESS DOOR ............. 3-38 BOW ACCESS LADDER ................. 3-39 CABIN DISTRIBUTION PANELS............. 3-39 ELECTRICAL SYSTEMS ................. 3-40 DC Electrical..................3-40 AC Electrical..................3-41 SHORE POWER CONNECTION............. 3-42 323 Owner’s Manual...
Page 6 General Maintenance Instructions ............5-3 Maintenance Techniques ..............5-3 Spot and Stain Removal ..............5-4 CABINETRY AND WOOD ................. 5-6 Cabinetry ....................5-6 Ebony Woodgrain Dash ............... 5-6 Teak Swim Platform ................5-6 Cedar ....................5-6 CARPET..................... 5-6 323 Owner’s Manual...
Page 7 LIFTING THE BOAT .................. 6-4 Using Lifting Slings................6-4 Storage Cradle ..................6-4 STORAGE/WINTERIZATION ..............6-5 Reactivating the Boat After Storage ............. 6-5 Cockpit Heater..................6-6 TROUBLESHOOTING ................6-6 Engine ....................6-7 Electrical....................6-8 Plumbing ....................6-8 323 Owner’s Manual...
Page 8 During Operation .................. 7-2 Returning to Port .................. 7-2 Stopping the Engines ................7-2 After Boating ..................7-2 SERVICE LOG................... 7-3 FUEL LOG ....................7-4 FLOAT PLAN ..................... 7-5 BOAT INFORMATION ................7-6 WARRANTY TRANSFER FORM............... 7-7 323 Owner’s Manual...
Page 9: General Information
ECTION 323 Owner’s Manual ENERAL NFORMATION WELCOME Dear New Cobalt Owner, From all of us at the factory and from your authorized Cobalt dealer, thank you for purchasing a Cobalt boat. We greatly appreciate your business and look forward to a long and enjoyable relationship with you as part of the Cobalt family.
Page 10: Certificate Of Limited Warranty
(10) deterioration (i.e.: fading, oxidation, discoloration) to the gelcoat finish of any Cobalt boat with colored (non-white) gelcoat located below the static waterline; (11) damage or failure related to alteration, modification, misuse, neglect, negligence, accident or failure to provide reasonable care and maintenance of such Cobalt boat. 323 Owner’s Manual...
Page 11 Service Agreement is administered by a third party. For more information regarding this coverage and obtaining service, refer to the Extended Service Agreement booklet in your boat bag. All warranties, Cobalt and Extended Service are transferable and transfer fees are applicable. 323 Owner’s Manual...
Page 12: Introduction
13' 1.44" (4 m) and above, and is largely self-sufficient. Abnormal conditions such as hurricanes are excluded. Such conditions may be encountered on extended voyages, for example across oceans, or inshore when unsheltered from the wind and waves for several hundred nautical miles. 323 Owner’s Manual...
Page 13: Owner Responsibility/Warranty Procedure
Cobalt boat to anyone other than an authorized Cobalt dealer, please refer to the Warranty Transfer Form on the last page of this manual. If the proper transfer procedures are not followed, future warranty may be denied. 323 Owner’s Manual...
Page 14: Certifications
Ultimately, the goal of the program is to improve integrated product quality and customer satisfaction as well as to reduce warranty visits and costs. 323 Owner’s Manual...
Page 15: Warning Labels
COBALT BOATS “MEET U.S. EPA EVAP STANDARDS USING CERTIFIED COMPONENTS” Hydraulic Swim Platform Helm (U.S. Only) WARNING AVOID OBSTRUCTION OF NAVIGATION LIGHTS AND POSSIBLE COLLISION. REMOVE CANVAS BEFORE USING NAVIGATION OR ANCHOR LIGHTS. Aft Sun Pad Navigation Light COB_0018_A 323 Owner’s Manual...
Page 16 USE BOTH TURN LOCKS TO SECURE DOOR. Walk-Through Door/Windshield CAUTION FOOT CAN SLIP THROUGH RUNG CAUSING BODILY INJURY, CLOSE CABIN DOOR BEFORE USING FORE DECK LADDER Companionway Area Helm Helm (California Only) Engine Compartment (actual capacity varies by model) COB_0019_A 323 Owner’s Manual...
Page 17: Publications
FATHOM – Unit of depth or measure; 1 fathom equals 6 feet. BUNKS – Carpeted trailer hull supports. FENDERS – Objects placed alongside the boat for BURDENED BOAT – Term for the boat that must cushioning. Sometimes called bumpers. “give-way” to boats with the right-of-way. 323 Owner’s Manual...
Page 18 TRANSOM – The transverse beam across the NMMA – National Marine Manufacturers stern. Association. TRIM – Fore to aft and side to side balance of the boat when loaded. 1-10 323 Owner’s Manual...
Page 19 WAKE – The waves that a boat leaves behind when moving through the water. WATERWAY – A navigable body of water. WINDLASS – An electric winch to raise the anchor. 323 Owner’s Manual 1-11...
Page 20: Symbols
Caution Hour Meter STOP Engine Engine Fuel Grease Height Holding Horn Stop Tank Above Water Tank Ignition Overall Lift Light Navigation Tank Switch Length Point Lights Trim Water Windshield Safety Alert Tabs Tank Wipers Symbol COB_0030_A 1-12 323 Owner’s Manual...
Page 21: Specifications
Bridge Clearance w/Arch or Tower 8' 10" (2.69 m) Draft, Drive Up 24" (0.61 m) Draft, Drive Down 35" (0.90 m) Dry Weight 12,300 lbs (5579 kg) Boat Certified Capacity Yacht Certified Boat Certified Capacity w/Gear Yacht Certified 323 Owner’s Manual 1-13...
Page 22: Layout
FUEL TANK FILL WATER TANK FILL PORT FUEL TANK FILL BATTERY SELECTOR SWITCH/ AIR COMPRESSOR/ STORAGE NAVIGATION LIGHT RECEPTACLE TRANSOM STORAGE/ SHORE POWER ICE CHEST BREAKERS/ OPTIONAL TRANSOM SPEAKER SWITCH SWIM PLATFORM/ SKI TOW EYE BOARDING LADDER COB_0013_A 1-14 323 Owner’s Manual...
Page 23: Propeller Application Chart
TWIN 5.7 GXi & GXiC 1.95 1.95 FH5’s 481405 3851495 VOLVO TWIN V8-320 VOLVO TWIN 8.1 Gi 1.78 1.78 FH7’s 481407 3885843 VOLVO TWIN V8-380 2.14 FH5’s 481405 3851495 VOLVO TWIN 8.1 GiC FH7’s 481407 3885843 323 Owner’s Manual 1-15...
Page 24: Alphabetical Index
Carpet ....... 5-6 Engine/Propulsion/Cooling System ..6-3 1-16 323 Owner’s Manual...
Page 25 Helm and Instrumentation ....3-22 OFFSHORE – Category B ....1-5 323 Owner’s Manual 1-17...
Page 26 Salt Water ......3-19 Tool Kit - Optional..... . 3-48 1-18 323 Owner’s Manual...
Page 27 Windshield ......5-10 Zippers......5-10 323 Owner’s Manual 1-19...
Page 28 COBAL T DAY CRUISER ECTION NOTES 1-20 323 Owner’s Manual...
Page 29: Owner/Operator Responsibilities
ECTION 323 Owner’s Manual ESPONSIBILITIES AND AFETY Your safety, the safety of your passengers, and While operating the boat, the owner/operator is other boaters are among your responsibilities as responsible for: operator of this boat. Your boat must be in •...
Page 30: Required Safety Equipment
Fire Extinguisher All inboard/outboard boats must carry an appropriate portable marine type fire extinguisher in operable condition and accessible location. Your Cobalt boat is equipped with a portable fire extinguisher and may have a fixed system fire extinguisher. 323 Owner’s Manual...
Page 31: Recommended Spare Parts
• Canadian Power and Sail Squadrons the engine compartment. When activated, the • Yacht Clubs blowers exhaust dangerous fumes and intake fresh air through vents. Operate the blowers for at least four minutes before starting the engines. 323 Owner’s Manual...
Page 32: Electrical Systems
While operating your boat, frequently check that the control and steering systems continue to operate smoothly. Monitor your gauges for signs of abnormal behavior. Beware of any excessive vibration. Refer to Section 3, Before Starting Checklist. 323 Owner’s Manual...
Page 33: Environmental Considerations
This label must stay affixed to the boat if it is operated in California. The label identifies your boat is equipped with a California Certified Engine. The label is positioned so it will be at the leading or trailing edge of the state registration numbers. 323 Owner’s Manual...
Page 34 There is a tremendous drain on our fishery waste discharge. resources. Over-fishing and pollution have strained the fish population. Do your part by keeping only what you will eat and practice catch-and-release. 323 Owner’s Manual...
Page 35: Components, Maintenance And Repairs
If the boat life. is abandoned, swim upwind, far enough to avoid fuel that may spread over the surface of the water. 323 Owner’s Manual...
Page 36 If you experience a propulsion, steering or control failure, immediately turn off the engines. Release the anchor to prevent drifting. Try to determine the failure and repair, if possible. Otherwise, call or signal for assistance. 323 Owner’s Manual...
Page 37: Lifesaving Equipment
Federal law requires at least one Type I, II, III or V TYPE III Personal Flotation Device (PFD) for each person FLOTATION AIDS onboard or being towed, and at least one Type IV KC-0042C throwable PFD in the boat. 323 Owner’s Manual...
Page 38 • A Type V PFD must be worn to be counted toward the minimum carriage requirements. • Special PFDs are available for skiing and other water sports. These PFDs are constructed with materials suitable for high impact falls. 323 Owner’s Manual...
Page 39 Radar Reflectors Radar reflectors allow you to be seen by other vessels’ radar within your area. Mount the reflector as high as possible on the radar arch. 323 Owner’s Manual...
Page 40: Safety
Indicates a hazardous situation which, if Seating not avoided, will result in death or Keep your passengers seated in seats. The boat’s serious injury. bow, gunwale, transom platform and seat backs are not intended for use as seats while underway. 323 Owner’s Manual...
Page 41 • Stow gear below deck and batten down equipment on deck. • Reduce speed and head for a safe place that you can easily reach. If you lose power, keep the boat headed into the waves by using the anchor. 323 Owner’s Manual...
Page 42 Federal and state law prohibit blast from your horn or whistle once every minute. operating a boat under the influence of Additionally, have passengers wear PFDs and alcohol and other drugs. These observe for oncoming vessels. regulations are actively enforced. 323 Owner’s Manual...
Page 43 Seek medical attention if transom platform while engines are running. necessary. Ventilation Your Cobalt boat may be equipped with carbon monoxide (CO) detector(s), if your boat is a cabin type or built with an enclosed changing area. 323 Owner’s Manual...
Page 44 Operating with high bow angle. Exhausts traveling along obstruction. Exhausts from other vessels in confined areas. Operating at slow speed or while dead in the water. Operating with canvas tops and side curtains in place without ventilation. COB_0033_A 323 Owner’s Manual...
Page 45 Road” for both federal and state waterways; you must stop if signaled to do so by enforcement Noise limits are regulated in many areas. Be sure officers, and permit to be boarded as asked. to follow regulations and be courteous. 323 Owner’s Manual...
Page 46: Water Sports Safety
• Do not use any fuel burning appliances with a liability arising from such assistance. transom exhaust port when swimming from the stern swim platform. DANGER Avoid injury or death. DO NOT practice unsafe water sports. 323 Owner’s Manual...
Page 47 The USCG issued a corrective action. Seek medical SAFETY ALERT on August 28, 2001, which covers attention if necessary. some issues regarding improper use of the boarding ladder/swim platform. The SAFETY ALERT and portions of the information follow: 323 Owner’s Manual...
Page 48: Safety Alert From August 28, 2001
In general, boats with less maneuverability have right-of-way over more agile craft. You must stay clear of the vessel with right-of-way and pass to his stern. 323 Owner’s Manual...
Page 49 12 O'CLOCK STAND-ON (PRIVILEGED) VESSEL HONK HONK HONK HONK HONK HONK DANGER ZONE GIVE-WAY (BURDENED) VESSEL PASSING PASSING MEETING PORT TO STARBOARD TO HEAD TO PORT STARBOARD HEAD COB_0034_A 4 O'CLOCK COB_0005_A 323 Owner’s Manual...
Page 50: Aids To Navigation
Buoys with unique light-flashing characteristics are identified on nautical charts with the specific Protect your night vision by avoiding bright lights flashing pattern. and have a passenger, if possible, help keep watch for other boats, water hazards and aids to navigation. 323 Owner’s Manual...
Page 51 Regulatory markers are white with orange geometric shapes and also have orange bands near the top and at the water line of the buoy. You must obey regulatory markers (see below). CONTROLLED DANGER BOATS INFORMATION AREA KEEP OUT KC-1903 323 Owner’s Manual...
Page 52 Quick Flashing Flashing Occulting Starboard Side Even Numbers Daymark Nun Buoy Lighted Buoy KC-1909 WHITE LIGHT ONLY MORSE CODE Mo (A) Safe Water Aids Marking Mid-Channels and Fairways (No Numbers–May be Lettered) Spherical Buoy Daymark Lighted KC-1910 323 Owner’s Manual...
Page 53 RED and GREEN horizontally striped buoys. A RED band at the top means the preferred channel is to the left of the buoy; a GREEN top band means the preferred channel is to the right of the buoy. 323 Owner’s Manual...
Page 54 They are similar to lighted BLACK-STRIPED buoys, except they are usually higher and on more WHITE BUOY stable platforms to increase visibility. Most minor KC-1902 lights are part of a series to mark a channel, river or harbor. 323 Owner’s Manual...
Page 55 RIGHT OF RANGE LINE ON RANGE LINE COB_0038_A Lighthouses Lighthouses can be found at harbor entrances, prominent headlands, isolated danger areas and along the coast. These striped or patterned structures have unique flashing characteristics to help identify them. KC-0443C 323 Owner’s Manual...
Page 56 Boaters must also recognize the flag designs which indicate that skin divers are present and keep well clear of the area. KC-0250C Watch for swimmers. Swimming areas may not be marked. Steer clear from the area and remain alert. 323 Owner’s Manual...
Page 57: Operating Information
ECTION 323 Owner’s Manual PERATING NFORMATION FIRST-TIME OPERATION This section is not intended to provide complete training on all aspects of boat operation. We strongly recommend that all operators of this WARNING Cobalt boat seek additional training on boat Avoid injury or death. Improper handling and safety.
Page 58: Fuel
Operate the type of discharge, trash or blowers for at least four minutes. DO litter into our waterways. NOT store rags used to wipe up fuel or solvent spills in the boat. Dispose of rags properly ashore. 323 Owner’s Manual...
Page 59 If you smell filler cap, open by pressing the cap and turning the gasoline fumes, do not start the engine; cap counterclockwise (approximately 10°); remove continue to run the blower until fumes have cap. dissipated. 323 Owner’s Manual...
Page 60 Do not attempt to continue fueling after the nozzle automatically shuts off, indicating the tank is full. • A carbon canister is present to capture hydrocarbon molecules before air is vented outside the fuel system. 323 Owner’s Manual...
Page 61: Launching
Avoid stepping on fiberglass or other potentially slippery surfaces. Board one person at a time. Do not board the boat while carrying gear. Set the gear on the dock, board the boat and then pick up the gear. 323 Owner’s Manual...
Page 62: Getting Underway
Immediately have any problem attended to by your authorized Cobalt dealer. • Operate bilge blowers for at least four minutes before starting engines or generators. • Do not overload your boat. 323 Owner’s Manual...
Page 63: Handling Dock And Mooring Lines
Be sure to use spring lines when boating in waters where the tide movement is significant. The forward quarter spring line is fastened to a forward cleat and heads aft. The after bow spring is fastened to a stern cleat and heads forward. 323 Owner’s Manual...
Page 64 ENGINE IS RUNNING. water inlets for blockage. If the inlets are open, • TURN OFF ENGINE AND ALL ELECTRICAL have your authorized Cobalt dealer service the SYSTEMS WHILE REFUELING. engine. • TURN OFF ENGINE WHEN SWIMMERS ARE NEAR BOAT. 323 Owner’s Manual...
Page 65 • Regularly inspect the steering system for kinks, damage and corrosion. Your Cobalt boat is equipped with a tilt steering wheel. Adjust the tilt position with the release lever. Refer to Basic Maneuvering, in this section, for additional steering information. 323 Owner’s Manual...
Page 66 COBAL T DAY CRUISER ECTION RIGHT TURN LEFT TURN BACKING TO LEFT Turn wheel to right—Stern Turn wheel to left—Stern Turn wheel to left—Stern will move to left. will move to right. will pull to left. COB_0062_A 323 Owner’s Manual...
Page 67 When leaving a mooring, you should already have enough space around the boat to maneuver. Untie from the mooring and move back slowly until you can see it. Proceed slowly while giving the buoy wide clearance. 323 Owner’s Manual...
Page 68 If you must approach the dock downwind or down current, use a slow speed and shallow angle. Be ready to reverse in order to stop and maintain position. 323 Owner’s Manual...
Page 69: Basic Maneuvering
If the steering wheel remains in a centered position, the boat will wander back and forth slightly; however, the overall course of the boat will be a straight one. 323 Owner’s Manual...
Page 70 To use power trim effectively, start with the drive unit trimmed in. As the boat planes, increase the angle out. Experience is the best teacher for understanding proper drive trim. 323 Owner’s Manual...
Page 71 Some systems may include indicators to show position of the tabs and drive unit. STARBOARD TAB LOWERED STARBOARD STERN RISES PORT BOW LOWERS COB_0067_A LOWERS STERN RISES HULL WATER IS REDIRECTED CREATING UPWARD FORCE AT STERN COB_0068_A 323 Owner’s Manual...
Page 72 • Prepare the boat. Be sure all gear is properly accident. stowed and compartments are latched. • Weight distribution affects performance. Keep weight in the boat to a minimum and evenly distributed. 323 Owner’s Manual...
Page 73 Look for signs of underwater pipes or cables. With the engine off, you have no control of the boat. Water and wind conditions will affect an anchored boat. Be sure the anchor will hold before leaving the boat. 323 Owner’s Manual...
Page 74 DO NOT use deck cleats or place safety switch in the ON position. handrails. DO NOT allow anyone to be in line with the tow rope. Press and hold the toggle switch down to pay out sufficient rope/chain to set the anchor. 323 Owner’s Manual...
Page 75: Environmental Considerations
This will help prevent damage from freezing. Upon removing your Cobalt boat from the water, leave the drive unit in the vertical position until cooling system has drained. Refer to your propulsion unit operator’s manual for additional information regarding winterization. 323 Owner’s Manual...
Page 76: Entertainment System
The speakers can be damaged if struck by a sharp object or if the moving elements are restricted from movement. Do not store or place any sharp objects near the speakers, or restrict the element movement. 323 Owner’s Manual...
Page 77: Cobalt Instrumentation System
(go to zero, or minimum reading). With the speedometer as the Data Interface Gauge, it will perform an LCD all-segments-on test. Once the initializations are complete, the gauges will be able to receive and display data. 323 Owner’s Manual...
Page 78: Helm And Instrumentation
Cobalt dealer. make the right decision on saving equipment or lives. Do not jeopardize Refer to the engine operator’s manual for normal the safety of you or others to protect recommended ranges. your boat. 323 Owner’s Manual...
Page 79: Basic Depth Sounder Operation
See your authorized Cobalt dealer when and above, it should show 12 to 14 volts. See your experiencing a high engine temperature reading. authorized Cobalt dealer and have the charging system checked if the voltmeter reads below these normal ranges. 323 Owner’s Manual...
Page 80 After installing the light, press the switch toward the “NAV.” Press the switch 18. HORN - This switch activates the horn. Press toward the “ANC” and the anchoring/mooring light the switch to activate. (360° white) will illuminate. 323 Owner’s Manual...
Page 81 • Run blower below cruising speed. 24. TILT STEERING RELEASE LEVER - Adjusts the steering wheel angle to a comfortable operating position when the boat is not moving. COB_0042_A 1 – Ignition Safety Switch 2 – Lanyard 3 – Hook 323 Owner’s Manual...
Page 82 27. DIMMER - Controls the intensity of the gauge When shifting from NEUTRAL to cluster lighting. FORWARD or REVERSE, shift briskly and decisively. 323 Owner’s Manual...
Page 83 The controls are arranged with the shift levers (all one size) grouped together and throttle levers (all one size, and larger than the shift levers) grouped together. 323 Owner’s Manual...
Page 84: Standard And Optional Equipment
Flip-Down Swim Step w/o Ladder Midship Cleats Motorbox Actuator Passenger Seat Flip Backrest System Recessed Hull-Side Logo Retractable Dock Lines (locking) Ski Tow Eye - Stainless Steel Sof-Trac Mat (std swim platform) Sof-Trac Mat (swim platform w/step) Spotlight w/Helm Remote 323 Owner’s Manual...
Page 85 Dinette Table w/Cockpit Receptacle Double Wide Helm Seat Floor Covering, Seagrass (Sand & Terra) Grey Water System Head Compartment w/Shower Head w/Vacu-Flush Head w/Vacu-Flush, Macerator Microwave Refrigerator Remote Courtesy Lights w/Key Fob Removable Cockpit Carpet Seating, Helm Flip-Up 323 Owner’s Manual...
Page 86 Cruise Control, Volvo w/EVC Fiberglass Cockpit Liner Fiberglass Stringer System Fire Extinguisher, Automatic System Fire Extinguisher, Automatic System (generator) Fire Extinguisher, Manual Generator (5kw) w/Sound Shield Hot Water Heater (110 volt) Ignition Safety Switch Kevlar™ Reinforced Hull 323 Owner’s Manual...
Page 87 PERATING NFORMATION FEATURES Standard Optional Stainless Steel Windshield Braces Through-Prop Exhaust Tool Kit Trim Tabs Windlass w/Line, Chain & Anchor 323 Owner’s Manual...
Page 88: Captain's Chair Adjustments And Operation
COB_0088_A DANGER Avoid potential injury or ejection of occupants. Do not stand while driving above engine idle speeds and make sure all passengers are seated and seats are in a locked/secured position when the boat is underway. 323 Owner’s Manual...
Page 89: Flip Down Swim Step - Optional
1 – Swim Step 2 – Plunger 2. Pull the plunger and allow the step to float up. 3. Move to the side and pull the step onto the platform. It will automatically lock into place. 323 Owner’s Manual...
Page 90: Bow Inserts
Return the seat cushion by placing the front of the 4. Install inserts. seat cushion in position. To return the table to its stowed position, reverse previous steps. 323 Owner’s Manual...
Page 91: Passenger Seat
DANGER Avoid the possibility of injury or death from explosion or fire. Do not smoke or have any flame near an open faucet; hydrogen gas is extremely flammable. 323 Owner’s Manual...
Page 92: Stove
Do not return to the cabin area until the cause of the CO has been identified and corrected. For additional information, refer to the carbon monoxide detector operating instructions in your owner’s packet. Air Flow COB_0101_A 323 Owner’s Manual...
Page 93: Battery Switch
CO may be present in other areas. Electronic devices have limited life spans and may fail without warning. Inspect the CO detector periodically. Refer to the detector manufacturer’s literature and follow their recommendation for replacement. 323 Owner’s Manual...
Page 94: Voltage Sensitive Relay (Vsr)
Unlock and remove the key to avoid breaking, unless leaving the boat. Do not use caustic materials or a dry rag to clean the door. Use only a mild soap and water. 323 Owner’s Manual...
Page 95: Bow Access Ladder
These systems have a load center panel which serves as COB_0008_A the main distribution panel. The DC system supplies electricity to all of the boat’s electrical circuits (lights, pumps, blowers, ignition, etc.). 323 Owner’s Manual...
Page 96: Electrical Systems
DC Electrical ACCESSORY Your Cobalt boat has a 12-volt negative ground DC system. The positive wire is hot, and feeds current HELM from the batteries to all 12-volt equipment; the ELECTRONICS negative wire is the ground. COB_0009_A 323 Owner’s Manual...
Page 97: Ac Electrical
The indicator light next to the switch will illuminate. • Activate the individual component circuit breaker. AC Electrical When the shore power cord is plugged in, all AC equipment can be operated. The shore power cord supplies power to the breakers. 323 Owner’s Manual...
Page 98: Shore Power Connection
The shore power inlet breaker switch is located behind the door, at the port side of the aft sun pad of your Cobalt boat. COB_0059_A 1 – Shore Power Cord 2 – Threaded Locking Collar 3 – Boat Receptacle 323 Owner’s Manual...
Page 99 4. Disconnect the cable from the boat and close The voltmeter monitors the AC voltage. Damage the cap. can occur to your equipment if the voltage is less than 105 volts. Do not use AC-powered equipment if voltage is less than 105 volts. 323 Owner’s Manual...
Page 100: Generator - Optional
Water Level Indicator output AC Circuit Breaker. If your Cobalt is equipped with the level indicator display panel, it will show the level of the water and/or waste in the tanks as follows: 323 Owner’s Manual...
Page 101: Macerator Discharge Pump - Optional
3. Pull elastic cords over discs on transom, Refer to the battery charger operator’s manual for starting in the center and working outboard (you additional information. may have to readjust the support poles for proper fit). 323 Owner’s Manual...
Page 102: Bimini Top - Optional
4. Zip forward and aft bimini canvas together around the arch. 5. Install supports to forward bimini top. 6. Secure and tighten forward bimini. 7. Install two aft support bars and tighten the bimini by twisting the tensioners. 323 Owner’s Manual...
Page 103: Tie-Down Locations
Cobalt. COB_0001_A 1 – Bow Eye 2 – Cleats 3 – Stern Eyes WARNING Avoid injury, death or property damage. Never anchor a boat from the stern, and keep the boat headed into the waves. 323 Owner’s Manual...
Page 104: Motor Box Assembly
Be sure to return the support back to its stow position and any obstructions are cleared before closing the box. Wind and conditions may allow the motor box to open beyond its limits. Use caution during these conditions. 323 Owner’s Manual...
Page 105: Systems
ECTION 323 Owner’s Manual YSTEMS INTRODUCTION This section discusses the mechanical, electronic, and manual operating systems of your Cobalt boat. It describes basic operating characteristics and provides information for efficient use of the equipment, and for prevention of casualties. Be sure to read and understand all information provided before operating its systems.
Page 106: Electrical Wiring Harness
LIGHT BLUE/BLACK (L BL/B) SPEAKER GROUND GR/B (GR/B) SPEAKER GROUND PINK/B (PK/B) SPEAKER GROUND ORANGE/RED (O/R) HEATER RED/YELLOW (R/Y) SPOT LIGHT A/C POWER DIST. PANEL GENERATOR REMOTE SWITCH TO DASH TO SHORE GENERATOR POWER INLET GROUND TO PORT ENG. COB_0118_A 323 Owner’s Manual...
Page 107: Fuel Routing
3 – Fuel Tank Fill Caps 9 – Optional Generator 4 – Starboard Engine Fuel Line 10 – Generator Fuel/Water Separator 5 – Port Engine Fuel Line 11 – Starboard Fuel Tank Pickups 6 – Port Fuel Tank Pickups 323 Owner’s Manual...
Page 108: Water/Plumbing
Fresh Water INDICATE DIRECTION OF FLOW OPTIONAL WATER LINES STANDARD HOT WATER LINES STANDARD COLD WATER LINES GALLEY SINK HEAD SINK WATER PRESSURE PUMP WATER HEATER 35-GALLON FRESHWATER TANK COCKPIT GALLEY SINK WATER FILL OPTIONAL TRANSOM SHOWER C0B_0120_A 323 Owner’s Manual...
Page 109: Raw Water
YSTEMS Raw Water AIR CONDITION WATER DISCHARGE AIR CONDITIONING UNIT GENERATOR AIR CONDITIONING STRAINER AIR CONDITIONING PUMP GENERATOR DISCHARGE GENERATOR STRAINER AIR CONDITIONING GENERATOR SEACOCK SEACOCK COB_0121_A 323 Owner’s Manual...
Page 110: Gray Water/Waste
DRAIN SINK SINK SINK DRAIN SINK DRAIN SUMP PUMP DRAIN HEAD WATER FRESH HEATER WATER TANK WASTE TANK COCKPIT GALLEY SINK OPTIONAL MACERATOR LINE WASTE OUT INDICATE DIRECTION OF FLOW GRAY WATER OPTION STANDARD WATER LINES COB_0122_A 323 Owner’s Manual...
Page 111: Bilge Area
9 – Starboard Engine 21 – Generator Battery Switch 10 – Aft Bilge Pump 22 – Starboard Engine Battery Switch 11 – Port Engine 23 – Windlass Circuit Breaker 12 – Port Drive Unit Pump 24 – Battery Jump Terminals 323 Owner’s Manual...
Page 112: Water System
Avoid injury, death or explosion. DO NOT open the engine compartment hatch immediately. This will allow oxygen to the fire, and flashback can occur. When the fire extinguisher discharge occurs, turn off all engines, bilge blowers and electrical system components. 323 Owner’s Manual...
Page 113: Circuit Breaker Panel
DOCKING SPOT RECEPTACLE LIGHTS LIGHT STEREO HORN BLOWER BLOWER 1 BLOWER 2 NAV. LIGHTS ENGINE ENG COMP. COCKPIT WIPER MACERATOR HATCH LIGHTS LIGHTS RADAR BILGE PUMP BILGE PUMP BILGE PUMP SUMP PUMP 323 Owner’s Manual...
Page 114: Lighting/Bulb Replacement
Chrome Courtesy Light (Round) Overhead Console Light GE 912 Dome Light Ice Chest Instrument Lighting Tachometer 194 SF2 Speedometer 194 SD2 Voltmeter 658 S11 Oil Pressure 658 SH2 Temperature 658 SC2 Fuel 658 SC2 Trim 658 SC2 323 Owner’s Manual...
Page 115: Battery Connections
Read and understand the safety information on or without the batteries connected supplied with your battery(ies). Maintain the to the boat’s charging system. battery(ies) following the manufacturer’s Damage to engine and charging recommendations. system will result. COB_0090_A COB_0100_A 1 – Receptacle 323 Owner’s Manual...
Page 116 COBAL T DAY CRUISER ECTION NOTES 323 Owner’s Manual...
Page 117: Vinyl Interior And Upholstery
ECTION 323 Owner’s Manual NTERIOR XTERIOR The best way to take care of your Cobalt boat is The vinyl manufacturer or Cobalt Boats warranties with prevention and proper care. All of the care do not cover vinyl staining from suntan lotions.
Page 118 Do not apply water or try to wash a butter, oil or grease spot. Hair oil tonic Blood NOTICE: DO NOT use saddle soap, cleaning solvents, Urine furniture polish, oils, varnish, Grape juice abrasive cleaners, soaps or Olive oil ammonia water. Chocolate Ketchup Baby oil 323 Owner’s Manual...
Page 119: Sea Grass Floor Covering Cleaning Instructions
Crystal Dry™ as well; see Periodic Comprehensive and other foot-borne contaminants onto the Plynyl Cleaning (1) on next page. floor. If a walk-off mat is not provided, it will result in premature wear of the Plynyl installation. 323 Owner’s Manual...
Page 120: Spot And Stain Removal
Care should be taken to remove all detergent residue or it may attract more dirt. Care should be taken not to abrade Plynyl with the rotating pad. Hard-to-remove stains should be treated by hand, not machine, as per instructions in Spot and Stain Removal. 323 Owner’s Manual...
Page 121 5 minutes. Rinse the area with water only in order to remove the bleach residue. Allow to dry completely before trafficking. Some stains may require a professional to complete the stain-removal process. 323 Owner’s Manual...
Page 122: Cabinetry And Wood
The natural oils in beginning of the season, depending on the type of teak will cause poor adhesion. winter boat storage (covered, enclosed storage facility), and again mid-season. * 3M carries a complete line of fiberglass care products. 323 Owner’s Manual...
Page 123: Stainless Steel And Chrome
These types of cleaners can damage the surface permanently. Apply metal or automotive wax after cleaning for additional protection. Always test any product in an inconspicuous area before applying to the complete surface. 323 Owner’s Manual...
Page 124: Topside
Refer to the propulsion unit operator’s manual for http://www.corrosionx.com or manufacturer’s saltwater operating call 800-638-7361. recommendations. Corrosion destroys underwater metal parts and can occur in fresh or salt water. Salt, brackish and polluted waters will accelerate corrosion. 323 Owner’s Manual...
Page 125: Canvas
(no more than 100°F). Rinse thoroughly to remove soap. DO NOT USE DETERGENTS. Allow to air dry. Do not store canvas wet or in an unventilated, moist area. 323 Owner’s Manual...
Page 126: Other Canvas Components
Use care when starting zipper to prevent damage. the hull to slow growth and prevent gelcoat damage. Consult your authorized Cobalt dealer for recommendations. 323 Owner’s Manual...
Page 127: Scheduled Maintenance And Service
ECTION 323 Owner’s Manual AINTENANCE AND ROUBLESHOOTING SCHEDULED MAINTENANCE Use the following chart to establish your maintenance routine. Detailed information AND SERVICE concerning the task is listed in this section. Your Cobalt boat may not include all of the features...
Page 128: Break-In
• If a hose is leaking or damaged, close the authorized Cobalt dealer for service. Do not appropriate seacock. Consult your authorized continue to use badly damaged propellers. Cobalt dealer for repairs. Using damaged propellers may damage the drive unit(s) within time. 323 Owner’s Manual...
Page 129: Every 100 Hours
Do not operate your boat knowing you have a fuel must be replaced. Refer to the propulsion unit system problem. Upon discovery of a fuel system operator’s manual for additional information. problem, immediately notify your authorized Cobalt dealer for repair. 323 Owner’s Manual...
Page 130: Water System (If Equipped)
Mold and mildew may form as a authorized Cobalt dealer to identify the proper result of the inability of moisture to escape. location for slings. Slings may need to be adjusted forward or aft for your particular boat. 323 Owner’s Manual...
Page 131: Storage/Winterization
It is very important that all fuel systems and mold or mildew. exhaust systems be thoroughly inspected and repaired, if necessary, before operating the boat. Also, any accessory exhaust systems must be in proper operating condition. 323 Owner’s Manual...
Page 132: Cockpit Heater
The removable feature is for boat storage only. Cockpit Heater To winterize the optional cockpit heater, remove the two 5/8-inch cockpit heater hoses from the engine. Pump antifreeze into one hose until entire heater system is filled. 323 Owner’s Manual...
Page 133: Engine
Boat overloaded – reduce load. Boat trim – distribute boat load evenly. Improper propeller selection – see your authorized Cobalt dealer. Excessive bilge water – check for excessive water, drain bilge. Boat hull condition – clean if marine growth is present. 323 Owner’s Manual...
Page 134: Electrical
Damaged freshwater pump, restriction or obstruction in water line – see your authorized sink Cobalt dealer. Head will not flush Head circuit breaker tripped or in OFF position – correct the problem and reset; turn circuit breaker ON. Line to waste tank blocked – see your authorized Cobalt dealer. 323 Owner’s Manual...
Page 135: Reference And Forms
ECTION 323 Owner’s Manual EFERENCE AND ORMS OPERATION QUICK Pre-Operation • Test operation of carbon monoxide detector. REFERENCE • Open all seacocks and check for leaks. Your safety, the safety of your passengers and • Check seawater strainers for leaks and other boats are among your responsibilities as accumulation of debris.
Page 136: Starting Engines
Returning to Port the boat. • Come to a stop a short distance from the dock, • Secure lockers, hatches and canvas as then proceed slowly. equipped. • Have your fenders, mooring lines and the crew ready. 323 Owner’s Manual...
Page 137: Service Log
EFERENCE AND ORMS SERVICE LOG Date Hour Reading Service/Repairs Performed 323 Owner’s Manual...
Page 138: Fuel Log
COBAL T DAY CRUISER ECTION FUEL LOG Gallons/ Gallons/ Date Gallons Hours Date Gallons Hours Hour Hour 323 Owner’s Manual...
Page 139: Float Plan
Radio: Yes Type Freq Destination Est. Time of Arrival Expect to Return By Auto Type License No. Parked If not returned by call the Coast Guard, or (Local Authority). Coast Guard Telephone Number: Local Authority Telephone Number: 323 Owner’s Manual...
Page 140: Boat Information
DVD Make and Model Number Serial Number Stereo Make and Model Number Serial Number TV, Cabin Make and Model Number Serial Number TV, Mid-berth Make and Model Number Serial Number Subwoofer Make and Model Number Serial Number 323 Owner’s Manual...
Page 141: Warranty Transfer Form
To transfer your extended powertrain and accessory coverage, refer to the transfer form in the Premium Marine Protection Booklet (US & Canadian Only) located in your Cobalt Boat Bag or your Passport Marine Service Agreement (International Only). Thank you for purchasing a Cobalt. I decline the Cobalt Warranty Transfer 323 Owner’s Manual...
Page 142 COBAL T DAY CRUISER ECTION NOTES 323 Owner’s Manual...

Cobalt Digital Inc 323 Owner's Manual

General Information

Responsibilities and Safety

Operating Information

Systems

Interior/Exterior Care

Maintenance and Troubleshooting

Reference and Forms

Quick Links

Need help?

Questions and answers

Related Manuals for Cobalt Digital Inc 323

Summary of Contents for Cobalt Digital Inc 323

Table of Contents
