Cobalt Digital Inc 343 PERFORMANCE Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

343 Owner's Manual

Table of Contents

WELCOME................................................................................................. 1-1
CERTIFICATE OF LIMITED WARRANTY ................................................. 1-2
INTRODUCTION........................................................................................ 1-4
Intended Use ........................................................................................ 1-4
Craft Design Category.......................................................................... 1-4
OWNER RESPONSIBILITY/ WARRANTY PROCEDURE ........................ 1-5
Before Operating .................................................................................. 1-5
Warranty Service Requirements .......................................................... 1-5
Extended Powertrain Warranty ............................................................ 1-5
If You Sell Your Cobalt Boat................................................................. 1-5
CERTIFICATIONS ..................................................................................... 1-6
NMMA .................................................................................................. 1-6
MerCruiser............................................................................................ 1-6
Volvo Penta .......................................................................................... 1-6
FEATURES/CONSTRUCTION .................................................................. 1-6
Amenities.............................................................................................. 1-6
Construction Standards/Certifications .................................................. 1-6
Serial Number Locations ...................................................................... 1-6
WARNING LABELS ................................................................................... 1-7
PUBLICATIONS ......................................................................................... 1-9
NAUTICAL TERMS .................................................................................... 1-9
SYMBOLS ................................................................................................ 1-12
SPECIFICATIONS ................................................................................... 1-13
LAYOUT ................................................................................................... 1-14
PROPELLER APPLICATION CHART ..................................................... 1-15
ALPHABETICAL INDEX .......................................................................... 1-16
