1999 C
B
1999 C
B
OB
AL
T
O
A
TS
OB
AL
T
O
A
TS
C
B
- O
'
M
OBALT
OATS
WNER
S
ANUAL
Dear New Cobalt Owner,
From all of us at the factory and from your Cobalt Dealer, thank you for purchasing a
Cobalt. We greatly appreciate your business and look forward to a long and enjoyable
relationship with you as part of the Cobalt family.
This manual is designed to help you maximize the enjoyment of your Cobalt boat, and
to acquaint you with proper operation, care, storage, and maintenance of your
investment.
Even if you're a seasoned boater and have previously owned a Cobalt, I recommend you
take time to read through this Owner's manual. As you read this manual, please
remember that "common sense" and "courtesy" are the most valuable traits you can
have to fully enjoy safe boating. It is also to your personal advantage to become well
acquainted with the rules and general "know how" of boating.
For service and for assistance contact your Cobalt dealer. The dealership staff will be
happy to answer questions concerning maintenance, warranty, or any other operational
questions you may have about your Cobalt.
All the best in boating,
Pack St. Clair, Chairman and C.E.O.
i
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cobalt Digital Inc 1999 190
Summary of Contents for Cobalt Digital Inc 1999 190
- Page 1 1999 C 1999 C ’ OBALT OATS WNER ANUAL Dear New Cobalt Owner, From all of us at the factory and from your Cobalt Dealer, thank you for purchasing a Cobalt. We greatly appreciate your business and look forward to a long and enjoyable relationship with you as part of the Cobalt family.
-
Page 3: Table Of Contents
ABLE ONTENTS ABLE ONTENTS ’ OBALT OATS WNER ANUAL I - E QUIPMENT AND OVERNMENT EGULATIONS Educational Opportunities .......1 Safety Equipment and Boating Regulations . - Page 4 ABLE OF ONTENTS Telescoping Anchor Light .......19 Heater - optional ........19 Stereo System - optional .
-
Page 5: Safety Equipment And Boating Regulations
UIPMENT UIPMENT VERNMENT EGULA TIONS VERNMENT EGULA TIONS ’ OBALT OATS WNER ANUAL DUCATIONAL PPORTUNITIES Most boaters can enhance their enjoyment of boating experiences through increased knowledge of safe operation, navigation, and regulation of pleasure boats. The U.S. Coast Guard Auxiliary, U.S. Power Squadron, and The American Red Cross offer courses covering a wide range of boating knowledge and skills, Water Safety, First Aid, and CPR. -
Page 6: Quipment And Government Regulations
QUIPMENT AND OVERNMENT EGULATIONS DDITIONAL ECOMMENDED AFETY QUIPMENT In spite of all efforts to the contrary, problems or mishaps sometimes occur while boating. The items listed below should help make unexpected events more manageable: • Anchor and anchor line • Compass •... -
Page 7: We Wish You Safe And Happy Boating
ARINE AFETY ARDS ARINE AFETY ARDS ’ OBALT OATS WNER ANUAL AFE AND APPY OATING The American Boat and Yacht Council, Inc. is an independent organization dedicated to developing and maintaining the highest level of marine equipment safety standards for U.S. -
Page 9: Nterior /Exterior Care
NTERIOR XTERIOR NTERIOR XTERIOR ’ OBALT OATS WNER ANUAL INYL NTERIOR AND PHOLSTERY The vinyl fabric in your Cobalt’s interior has been especially selected to take the tough punishment of the elements and hard usage of an active boater. Avoid sharp objects that may cut or tear your vinyl. -
Page 10: Dark Storage Areas
NTERIOR XTERIOR STEP 2 CLEANERS* Solvent-type cleaner to be liberally applied with a cloth, damp sponge or fine bristle brush. • Rubbing alcohol (isopropyl alcohol). • Lighter fluid (naphtha). Rinse cleansed area with fresh water and dry with a clean cloth. -
Page 11: Leather Care
NTERIOR XTERIOR EATHER FOR SPOTS AND SPILLS Wipe up excess liquid immediately with a clean absorbent cloth or sponge. If necessary, use clean luke warm water only and let air dry naturally. If water is used, clean the entire area where the spot occurred. An example would be the entire seat cushion or entire arm. - Page 12 NTERIOR XTERIOR first few months after initial installation. When canvas items are erected on the boat and properly adjusted, shrinkage will only occur in areas of looseness. Mold and mildew can be avoided by keeping the canvas clean and well ventilated. DIRT Dirt can create a starting point for mold when moisture is present.
-
Page 13: Fiberglass Finish Care
NTERIOR XTERIOR for long term storage. These tops were not designed for long term storage and do not provide good protection for your boat. Adequate ventilation is not possible and mold/mildew will form. For more information on appropriate covering for long term storage, please see your Cobalt Dealer. IBERGLASS INISH The finish on your Cobalt is known as gelcoat. - Page 14 NTERIOR XTERIOR against such occurrence: PREVENTIVE STEPS 1. Clean and wax metal brightwork twice yearly and prior to extended storage. In saltwater or other harsh environments, more often as needed. Many metal polish / cleaners are commercially available that contain wax for one-step convenience. 2.
-
Page 15: Boat Operation
PERA TION PERA TION ’ OBALT OATS WNER ANUAL RECTING ONVERTIBLE 1. Remove canvas top assembly from “top storage area”. 2. Attach top bow ends to top mounts on each side of the boat. Use quick disconnect pins. 3. Remove storage boot and unroll canvas top. -
Page 16: Camper Top - Optional
PERATION AMPER OPTIONAL 1. Install “Convertible Top” as outlined. 2. Remove “Camper Top” from storage area. 3. Attach legs to “Camper Top” mounts (toward rear of boat) on each side of the boat. 4. Remove storage boot and unroll “Camper Top”... -
Page 17: Bow Tonneau Cover - Optional
PERATION 23LS/25LS/293 1. Bimini top is stored in the upright position for both trailering and storage. 2. Open top and extend the telescoping legs by depressing the buttons protruding through the sides of the legs. 3. Install support leg ends to the appropriate mounting brackets on the deck or windshield. -
Page 18: Mooring Covers - Optional
PERATION OORING OVERS OPTIONAL Cobalt mooring covers are made from marine canvas duck, a cotton/polyester material, the best material for storage of your Cobalt. It has the ability to breathe properly, a trait other materials, especially synthetics, do not have to the same degree. Mooring covers are recommended by Cobalt for any storage longer than a few days. -
Page 19: Captain's Chairs Adjustment And Operation
PERATION (16 oz.) Clorox and one cup (8 oz.) Ivory Flakes. Line dry the canvas. UNDER NO CIRCUMSTANCE ARE THESE FABRICS TO BE PUT IN HOT WATER. UNDER NO CIRCUMSTANCE ARE THESE FABRICS TO BE RUN THROUGH THE HOT DRYING CYCLE OF AN AUTOMATIC DRYER. -
Page 20: Ignition Safety Switch
PERATION GNITION AFETY WITCH Your Cobalt is equipped with an ignition safety switch. It is located on the face of the side mount control or near the lower edge of the driver’s control panel. The driver should always attach the lanyard to his or her person. If the driver leaves the driver’s station, the lanyard will shut off the ignition immediately preventing the boat from moving under power. -
Page 21: Warning Labels
PERATION ARNING ABELS Your Cobalt has several warning labels displayed to point out safety hazards. The areas are as follows: BOARDING LADDER/SWIM WARNING PLATFORM PROPELLER LOCATED BEHIND THIS BOAT. CONTACT MAY CAUSE SEVERE INJURY OR FATALITY. DO NOT APPROACH OR USE LADDER AND PLATFORM WHEN THE ENGINE IS RUNNING. -
Page 22: High Speed Operation
PERATION WINDSHIELD WING, COBALT CHECK LIST DRIVER’S SIDE For maximum enjoyment and safety, check each of these items BEFORE you COBALT CHECK LIST start your engine: -- DRAIN PLUG (Securely in place?) -- LIFE-SAVING DEVICES (One for every person on board?) -- STEERING SYSTEM (Working smoothly and properly?) -- FUEL SYSTEM (Adequate fuel? Leaks? Fumes?) -- BATTERY (Fully charged? Proper water level?) -
Page 23: Lifting Your Cobalt
PERATION IFTING OBALT Please consult your Cobalt dealer for the proper method of lifting your Cobalt. THE SKI TOW CANNOT BE USED TO LIFT THE BOAT. IT CAN ONLY BE USED FOR WATER SKIING. IT IS NOT DESIGNED FOR TOWING ANOTHER BOAT OR FOR PARASAILING. THE TRANSOM MOUNTED EYES SHOULD BE USED FOR PULLING A HEAVIER LOAD. -
Page 24: Stereo System - Optional
PERATION TEREO YSTEM OPTIONAL There are separate instructions in the owner’s packet that give specific instructions for operation. OCKING IGHTS OPTIONAL Docking lights are to be used for docking only. It is illegal to use your docking lights while cruising. Please consult your Cobalt dealer for further information. OPTIONAL The trim tabs are a separate system in themselves and are not to be used in lieu of the engine power trim system. -
Page 25: Engine Operation/Maintenance/Servicing
ECHNICAL NFORMA TION ECHNICAL NFORMA TION ’ OBALT OATS WNER ANUAL NGINE PERATION AINTENANCE ERVICING Included with your owner’s packet is your engine manual(s). This manual was prepared by the engine manufacturer and contains information concerning the operation and care of your engine. -
Page 26: Technical Information
ECHNICAL NFORMATION Good storage is very important whether indoors or outdoors. Boat trailers designed for specific model boats provide excellent support for your Cobalt for long term storage. If you are storing your Cobalt by some other means; rack, hoists, blocks, etc., consult your Cobalt Dealer. -
Page 27: Circuit Breakers
ECHNICAL NFORMATION Circuit Breakers Most electrical standard equipment devices are controlled with circuit breakers. These breakers will activate if overloaded and cut power to the switch. To restore power, simply push the breaker button in and release. (Breakers do not require fuse replacement). -
Page 29: Cobalt Warranty
ARRANTY OCEDURE ARRANTY OCEDURE WNER ESPONSIBILITY WNER ESPONSIBILITY ’ OBALT OATS WNER ANUAL OBALT ARRANTY Ten-year limited transferable warranty on hull and deck structure, two-year limited transferable warranty on other component parts. Cobalt Boats warrants the hull and deck, including floor, stringers, motor mounts, transom and deck/hull joints, of each new Cobalt boat to be free from structural defects in material and workmanship under normal recommended use for a period of ten (10) years from the date of delivery to the original retail purchaser. -
Page 30: Warranty Procedure And Owner Responsibility
ARRANTY ROCEDURE AND WNER ESPONSIBILITY discovery of the alleged basis for any warranty claim. During the applicable warranty period, as set forth above, warranty repairs shall be made without charge by an authorized Cobalt Boats dealer or, at the option of Cobalt Boats, by Cobalt Boats at its plant in Neodesha, Kansas. -
Page 31: If You Sell Your Cobalt
ARRANTY ROCEDURE AND WNER ESPONSIBILITY F YOU SELL YOUR OBALT Your warranties are transferable. If you sell your Cobalt to anyone other than an authorized Cobalt dealer, please call Cobalt Boats for the appropriate warranty transfer information (800-468-5764 or 316-325-2653). If the proper transfer procedures are not followed, future warranty may be denied. -
Page 33: Trouble Shooting
OUBLE TING OUBLE TING ’ OBALT OATS WNER ANUAL ATTERY WITCH All but 293 - Your Cobalt is equipped with a master battery switch. With this switch turned off, nothing in the boat will operate. If you have the optional dual battery system, make sure the master switch is in the “1”... -
Page 34: Starter Won't Crank Engine
ROUBLE HOOTING ’ TARTER WON T CRANK ENGINE Ignition switch inoperative - see Authorized Cobalt Dealer. Throttle position - Check to see that remote control is in start or neutral position. Change position of throttle only slightly. Dead battery - Check level of electrolyte, disconnect battery. Charge battery. BATTERY ACID CAN CAUSE BLINDNESS IF SPLASHED IN EYES;... -
Page 35: Engine Runs But Boat Makes Little Or No Progress
ROUBLE HOOTING NGINE RUNS BUT BOAT MAKES LITTLE OR NO PROGRESS Fouled or damaged propeller - Stop and shut off engine. Check for weeds on propeller, bent or broken propeller. See your Authorized Cobalt Dealer. ERFORMANCE LOSS Throttle not fully open - Check to see that throttle opens fully at engine. Improper fuel - Fill tank with correct fuel. - Page 37 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Centerline ...18’6” 5.64 m Beam ....8’ 1” 2.46 m Dry Weight .
-
Page 38: Model Specific Information
ODEL PECIFIC NFORMATION NSTRUMENT ANEL 1. Fuel Gauge - shows approximate amount of fuel remaining in tank. 2. Speedometer (Miles Per Hour) 3. Tachometer - (Revolutions Per Minute) 4. Temperature Gauge - Temperature may fluctuate slightly while running. Maximum temperature may vary depending on type of engine. SHOULD WATER TEMPERATURE REACH 180 DEGREES FAHRENHEIT, YOUR ENGINE IS OVERHEATING AND SHOULD BE CHECKED IMMEDIATELY FOR PROBABLE CAUSE. - Page 39 ODEL PECIFIC NFORMATION ’ APTAIN HAIR DJUSTMENT AND PERATION Your captain’s chair has the flip-up position for greater visibility and maneuverability while docking. You can sit on the raised cushion or stand in front of the cushion. The 190 driver’s captain’s chair is adjustable fore and aft and also rotates. There is a large handle on the inboard side of the mechanism that when loosened, allows the seat to slide fore and aft.
- Page 40 ODEL PECIFIC NFORMATION factors: atmospheric conditions; additions of extra equipment and accessories or passengers; marine growth on the bottom; and, engine condition. Other factors include damage to the prop(s), tides, water temperature and direction of wind. Some of these factors are directly correctable by repair or maintenance. Others are beyond human control.
- Page 41 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Centerline ...19’6” 5.94 m Beam ....8’ 2” 2.49 m Dry Weight .
- Page 42 ODEL PECIFIC NFORMATION ’ APTAIN HAIR DJUSTMENT AND PERATION Your captain’s chairs have the flip-up position for greater visibility and maneuverability while docking. You can sit on the raised cushion or stand in front of the cushion. Standing while driving your boat should only be done while maneuvering at an idle by an experienced driver.
- Page 43 ODEL PECIFIC NFORMATION 8. Trim Gauge - Shows the position of the drive unit in reference to the bottom of the boat. 9. Depth Sounder (optional) - Included in your owner’s packet are the instructions pertaining to the operation of this unit. Consult your Cobalt Dealer for further information.
- Page 44 ODEL PECIFIC NFORMATION damage to the prop(s), tides, water temperature and direction of wind. Some of these factors are directly correctable by repair or maintenance. Others are beyond human control. INCORRECT PROPELLER APPLICATION CAN CAUSE ADVERSE HANDLING CHARACTERISTICS. DO NOT CHANGE TYPE OR SIZE OF PROPELLER WITHOUT CONSULTING YOUR COBALT DEALER! TAINLESS TEEL...
- Page 45 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Centerline ...21’0 6.40 m Beam ....8’ 6” 2.59 m Dry Weight .
- Page 46 ODEL PECIFIC NFORMATION ’ APTAIN HAIR DJUSTMENT AND PERATION Your captain’s chairs have the flip-up position for greater visibility and maneuverability while docking. You can sit on the raised cushion or stand in front of the cushion. Standing while driving your boat should only be done while maneuvering at an idle by an experienced driver.
- Page 47 ODEL PECIFIC NFORMATION 9. Depth Sounder - Your Cobalt is equipped with a Humminbird Depth Sounder. Included in your owner’s packet are the instructions pertaining to the operation of this unit. Consult your Cobalt Dealer for further information. 10. Two Position Switch - Controls equipment as labeled. 11.
- Page 48 ODEL PECIFIC NFORMATION INCORRECT PROPELLER APPLICATION CAN CAUSE ADVERSE HANDLING CHARACTERISTICS. DO NOT CHANGE TYPE OR SIZE OF PROPELLER WITHOUT CONSULTING YOUR COBALT DEALER! TAINLESS TEEL Some Cobalts are standard equipped with stainless propellers. In this instance, do not substitute aluminum propellers. Adverse handling and top speed characteristics may be experienced.
- Page 49 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Centerline ...21’11 6.68 m Beam ....8’ 5” 2.57 m Anchor Dry Weight .
- Page 50 ODEL PECIFIC NFORMATION ’ APTAIN HAIR DJUSTMENT AND PERATION Your captain’s chairs have the flip-up position for greater visibility and maneuverability while docking. You can sit on the raised cushion or stand in front of the cushion. Standing while driving your boat should only be done while maneuvering at an idle by an experienced driver.
- Page 51 ODEL PECIFIC NFORMATION 9. Depth Sounder (optional) - Your Cobalt may be optionally equipped with a Humminbird Depth Sounder. Included in your owner’s packet are the instructions pertaining to the operation of this unit. Consult your Cobalt Dealer for further information.
- Page 52 ODEL PECIFIC NFORMATION INCORRECT PROPELLER APPLICATION CAN CAUSE ADVERSE HANDLING CHARACTERISTICS. DO NOT CHANGE TYPE OR SIZE OF PROPELLER WITHOUT CONSULTING YOUR COBALT DEALER! TAINLESS TEEL Some Cobalts are standard equipped with stainless propellers. In this instance, do not substitute aluminum propellers. Adverse handling and top speed characteristics may be experienced.
- Page 53 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Anchor Centerline ...22’8” 6.91 m Locker Beam ....8’ 6” 2.59 m Dry Weight .
- Page 54 ODEL PECIFIC NFORMATION ’ APTAIN HAIR DJUSTMENT AND PERATION Your captain’s chairs have the flip-up position for greater visibility and maneuverability while docking. You can sit on the raised cushion or stand in front of the cushion. Standing while driving your boat should only be done while maneuvering at an idle by an experienced driver.
- Page 55 ODEL PECIFIC NFORMATION 9. Depth Sounder - Your Cobalt is equipped with a Humminbird Depth Sounder. Included in your owner’s packet are the instructions pertaining to the operation of this unit. Consult your Cobalt Dealer for further information. 10. Two Position Switch - Controls equipment as labeled. 11.
- Page 56 ODEL PECIFIC NFORMATION INCORRECT PROPELLER APPLICATION CAN CAUSE ADVERSE HANDLING CHARACTERISTICS. DO NOT CHANGE TYPE OR SIZE OF PROPELLER WITHOUT CONSULTING YOUR COBALT DEALER! TAINLESS TEEL Some Cobalts are standard equipped with stainless propellers. In this instance, do not substitute aluminum propellers. Adverse handling and top speed characteristics may be experienced.
- Page 57 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Centerline ...23’ 2” 7.06 m Anchor Beam ....8’ 6” 2.59 m Locker Dry Weight .
- Page 58 ODEL PECIFIC NFORMATION ’ APTAIN HAIR DJUSTMENT AND PERATION Your captain’s chair has the flip-up position for greater visibility and maneuverability while docking. You can sit on the raised cushion or stand in front of the cushion. The chairs are adjustable fore and aft and also rotate. Rotation - A large knob next to the pedestal when loosened will allow the seat to rotate.
- Page 59 ODEL PECIFIC NFORMATION 10. Depth Sounder - Your Cobalt is equipped with a Humminbird Depth Sounder. Included in your owner’s packet are the instructions pertaining to the operation of this unit. Consult your Cobalt Dealer for further information. 11. Three Position Exterior Light Switch NAV. position - navigation (running) lights, bow light and stern light.
- Page 60 ODEL PECIFIC NFORMATION tip of one blade and multiplying that figure by two. Pitch is expressed in the number of inches a prop will advance in a solid medium in one revolution. Operational characteristics of your boat, including its speed, may change due to several factors: atmospheric conditions;...
- Page 61 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Centerline ...23’ 2” 7.06 m Anchor Beam ....8’ 6” 2.59 m Locker Dry Weight .
- Page 62 ODEL PECIFIC NFORMATION UDDY ABIN CCESS The sliding door assembly can be in the open or closed position while running. Make sure the door is secured in either the open or closed position. Do not allow to slide free. ’ APTAIN HAIR DJUSTMENT AND...
- Page 63 ODEL PECIFIC NFORMATION with your boat concerning the oil pressure the engine in your boat should attain. 9. Three Position Exterior Light Switch NAV. position - navigation (running) lights, bow light and stern light. Center position - off. ANC. position - stern light only. NEVER OPERATE YOUR BOAT AT NIGHT WITHOUT ALL OF THE REQUIRED LIGHTS OPERATING.
- Page 64 ODEL PECIFIC NFORMATION inches a prop will advance in a solid medium in one revolution. Operational characteristics of your boat, including its speed, may change due to several factors: atmospheric conditions; additions of extra equipment and accessories or passengers; marine growth on the bottom; and, engine condition. Other factors include damage to the prop(s), tides, water temperature and direction of wind.
- Page 65 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Centerline ...25’ 7.62 m Anchor Beam ....8’ 6” 2.59 m Locker Dry Weight .
- Page 66 ODEL PECIFIC NFORMATION ’ APTAIN HAIR DJUSTMENT AND PERATION Your captain’s chairs have the flip-up position for greater visibility and maneuverability while docking. You can sit on the raised cushion or stand in front of the cushion. The chairs are adjustable fore and aft and also rotate. Rotation - A large knob next to the pedestal when loosened will allow the seat to rotate.
- Page 67 ODEL PECIFIC NFORMATION 10. Depth Sounder - Your Cobalt is equipped with a Humminbird Depth Sounder. Included in your owner’s packet are the instructions pertaining to the operation of this unit. Consult your Cobalt Dealer for further information. 11. Three Position Exterior Light Switch NAV. position - navigation (running) lights, bow light and stern light.
- Page 68 ODEL PECIFIC NFORMATION ROPELLERS ENERAL Nothing is more important to the proper performance of your boat than the condition of the propeller(s). Even minor damage (often invisible to the naked eye) can adversely affect the boat’s performance. Common symptoms of damage to propellers are a sudden drop in RPM, vibration or sudden loss of speed.
- Page 69 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Anchor Centerline ...25’ 7.62 m Locker Beam ....8’ 6” 2.59 m Dry Weight .
- Page 70 ODEL PECIFIC NFORMATION UDDY ABIN CCESS The sliding door assembly can be in the open or closed position while running. Make sure the door is secured in either the open or closed position. Do not allow to slide free. ’ APTAIN HAIR DJUSTMENT AND...
- Page 71 ODEL PECIFIC NFORMATION Please consult the engine owner’s manual supplied with your boat concerning the oil pressure the engine in your boat should attain. 9. Three Position Exterior Light Switch NAV. position - navigation (running) lights, bow light and stern light. Center position - off. ANC. position - stern light only. NEVER OPERATE YOUR BOAT AT NIGHT WITHOUT ALL OF THE REQUIRED LIGHTS OPERATING.
- Page 72 ODEL PECIFIC NFORMATION tip of one blade and multiplying that figure by two. Pitch is expressed in the number of inches a prop will advance in a solid medium in one revolution. Operational characteristics of your boat, including its speed, may change due to several factors: atmospheric conditions;...
- Page 73 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Centerline ...27’ 3” 8.3 m Anchor Beam ....8’ 6” 2.59 m Locker Dry Weight .
- Page 74 ODEL PECIFIC NFORMATION ’ APTAIN HAIR DJUSTMENT AND PERATION Your captain’s chairs have the flip-up position for greater visibility and maneuverability while docking. You can sit on the raised cushion or stand in front of the cushion. The chairs are adjustable fore and aft and also rotate. Rotation - A large knob next to the pedestal when loosened will allow the seat to rotate.
- Page 75 ODEL PECIFIC NFORMATION 6. Voltmeter - shows the condition of charge in the battery. It only indicates while the ignition is in the “ON” position. With the engine at idle or not running, it may show as low as 10 to 12 volts. With the engine running at cruising speeds and above, it should show 12 to 14 volts.
- Page 76 ODEL PECIFIC INFORMATION diameter is determined by measuring the distance from the center of the propeller to the tip of one blade and multiplying that figure by two. Pitch is expressed in the number of inches a prop will advance in a solid medium in one revolution. Operational characteristics of your boat, including its speed, may change due to several factors: atmospheric conditions;...
- Page 77 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Centerline(w/ anc roller) .29’5” 9.1 m Centerline(w/o anc roller)28’10” 8.8 m Windlass Beam ....9’ 6” 2.89 m (optional) Fuel Capacity .
- Page 78 ODEL PECIFIC NFORMATION ’ APTAIN HAIR DJUSTMENT AND PERATION Your captain’s chair has the flip-up position for greater visibility and maneuverability while docking. You can sit on the raised cushion or stand in front of the cushion. The chairs are adjustable fore and aft and also rotate. Rotation - A large knob next to the pedestal when loosened will allow the seat to rotate.
- Page 79 TUFF BOUT OVERNMENT EGULATIONS 8. Three Position Exterior Light Switch NAV. position - navigation (running) lights, bow light and stern light. Center position - off. ANC. position - stern light only. NEVER OPERATE YOUR BOAT AT NIGHT WITHOUT ALL OF THE REQUIRED LIGHTS OPERATING.
- Page 80 ODEL PECIFIC NFORMATION ATCHES The deck hatches are is manually operable. To open, simply release the one or two hasps on the edge of the hatch, make sure the support bracket adjusters are loose, and raise the hatch to the desired position and secure the adjusters. DO NOT USE A RAISED HATCH FOR A SUPPORT OR HAND HOLD WHILE ON THE DECK.
- Page 81 ODEL PECIFIC NFORMATION unless the main battery switches are turned on. For further information referencing the ship’s shore power system, please consult your authorized Cobalt dealer. ATER OPTIONAL Your Cobalt maybe equipped with a six-gallon hot water heater. This unit operates in two modes.
- Page 82 ODEL PECIFIC NFORMATION OMPRESSOR Your Cobalt is equipped with an inflation device located in the port side, aft storage locker. This is a 12 VDC system and will operate when the ship’s batteries are turned ATTERY HARGER AND SOLATOR OPTIONAL Your Cobalt is equipped with a charging system.
- Page 83 ODEL PECIFIC NFORMATION (GPS) S LOBAL OSITIONING ATELLITE YSTEM OPTIONAL The GPS system in your Cobalt performs many functions. The system can precisely tell you your location, form a trip record, a speed log, and many other functions. In addition, individual mapping chips can be purchased through your Cobalt dealer for most lakes, rivers, and coastal areas of the United States and Canada.
- Page 84 ODEL PECIFIC NFORMATION TAINLESS TEEL Some Cobalts are standard equipped with stainless propellers. In this instance, do not substitute aluminum propellers. Adverse handling and top speed characteristics may be experienced. ULLING OWER If you need extra pulling power, you can obtain this by decreasing the pitch of your propeller(s) by two degrees.
- Page 85 202/203 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS SPECIFICATIONS Centerline ... .20” 2” 6.15 m Beam ....7’ 5” 2.26 m Dry Weight .
- Page 86 202/203 ODEL PECIFIC NFORMATION ’ APTAIN HAIR DJUSTMENT AND PERATION Your captain’s chair has the flip-up position for greater visibility and maneuverability while docking. You can sit on the raised cushion or stand in front of the cushion. The 190 driver’s captain’s chair is adjustable fore and aft and also rotates. There is a large handle on the inboard side of the mechanism that when loosened, allows the seat to slide fore and aft.
- Page 87 202/203 ODEL PECIFIC NFORMATION 12. Circuit Breakers - Push to reset if necessary. If the button continues to pop out consult your Authorized Cobalt Dealer. 13. Horn Button - The horn, itself, is located under the deck. SHOULD WATER TEMPERATURE REACH 180 DEGREES FAHRENHEIT, YOUR ENGINE IS OVERHEATING AND SHOULD BE CHECKED IMMEDIATELY FOR PROBABLE CAUSE.
- Page 88 CS.4...
- Page 89 23/25 ODEL PECIFIC NFORMA TION ODEL PECIFIC NFORMA TION ’ OBALT OATS WNER ANUAL AYOUT AND PECIFICATIONS 25LS Layout 23LS SPECIFICATIONS Centerline ... .23’ 2” 7.06 m Beam ....8’ 6” 2.59 m Anchor Dry Weight .
- Page 90 23/25 ODEL PECIFIC NFORMATION ’ APTAIN HAIR DJUSTMENT AND PERATION Your captain’s chair has the flip-up position for greater visibility and maneuverability while docking. You can sit on the raised cushion or stand in front of the cushion. The 190 driver’s captain’s chair is adjustable fore and aft and also rotates. There is a large handle on the inboard side of the mechanism that when loosened, allows the seat to slide fore and aft.
- Page 91 23/25 ODEL PECIFIC NFORMATION 11. Three Position Exterior Light Switch NAV. position - navigation (running) lights, bow light and stern light. Center position - off. ANC. position - stern light only. NEVER OPERATE YOUR BOAT AT NIGHT WITHOUT ALL OF THE REQUIRED LIGHTS OPERATING.
- Page 92 23/25 ODEL PECIFIC NFORMATION ROPELLERS ENERAL Nothing is more important to the proper performance of your boat than the condition of the propeller(s). Even minor damage (often invisible to the naked eye) can adversely affect the boat’s performance. Common symptoms of damage to propellers are a sudden drop in RPM, vibration or sudden loss of speed.
- Page 93 23/25 ODEL PECIFIC NFORMATION Model Mfgr Engine Drive Fuel system std. ratio Option Prop Dscpt Mfg. part # 23LS Merc 350 Mag MPI Bravo 3 Multi-Port 2.00 2.20 26’s 48-823667A6/68A6 23LS Merc 7.4L MPI Bravo 1 Multi-Port 1.50 1.65 14 1/4 x 21 RH 48-1370245 23LS Merc...
- Page 95 VICE VICE ’ OBALT OATS WNER ANUAL ETER ERVICE ERFORMED...
- Page 96 ERVICE ETER ERVICE ERFORMED ’ OBALT OATS WNER ANUAL...
