Summary of Contents for Duratrax DXR500
-
Page 2: Required Tools
REQUIRED TOOLS Needle Nose Pliers DTXR0300 Phillips Screwdriver DTXR0124 Flat Blade Screwdriver DTXR0102 Hex Wrenches DTXR0288 (1.5mm) DTXR0291 (3mm) Threadlocker DTXR0288 2mm Wrench (Included) ITEMS REQUIRED FOR OPERATION 7.4V 2S LiPo Battery DTXC1814 or 7.2V 6-Cell Battery DTXC2054 Peak Charger ONYX 200 AC/DC Sport (DTXP4200) ONYX 210 AC/DC with LCD (DTXP4210) ONYX 220 AC/DC Programmable with LCD (DTXP4220) -
Page 3: Warranty
• Make sure to read the instructions included with the battery and charger • In that DuraTrax has no control over the fi nal user assembly or material before charging the battery. -
Page 4: Transmitter Preparation
TRANSMITTER PREPARATION • Slide off the battery tray door and install four “AA” batteries. Make sure the polarity is correct. RED BATTERY LIGHT • Raise the antenna at the top of the transmitter. • The receiver should be factory bound to the transmitter. -
Page 5: Battery Installation
BATTERY INSTALLATION • Remove the body clip from the • Install the battery into the battery holder battery door post. and secure in place with the hook and loop straps. With the ESC “OFF”, plug the battery into the ESC lead. •... -
Page 6: Important Operation Notes
IMPORTANT OPERATION NOTES The best place to operate your DXR500 is on a large, open parking lot, clear of any traffic. For better stability, be sure to get the gyro spinning before launching the DXR500. BEFORE Display For easier starts,... - Page 23 OTHER ITEMS AVAILABLE ™ DuraTrax 1/18 Vendetta SC RTR DTXD17** duratrax.com DuraTrax DX450 DuraTrax DX4 DTXD02** DTXD02** duratrax.com Heli-Max ® Novus ™ CX 2.4GHz Nano Sized Coaxial RTF Heli HMXE0803 helimax-rc.com...
- Page 24 ® © 2011 Hobbico , Inc. DTXZ1154 forDTXD04xx...
