Summary of Contents for LG AS-W096E1G0

  • Page 1 Inverter Single (50Hz/R410A) 5RMA2-01A...

  • Page 2: Table Of Contents

    Inverter Single-50Hz(R410A) Contents Page 1. Models line up..................4 2. Nomenclature..................6 3. Features & Benefits................8 4. Specifications ..................19 5. Dimensions ...................31 6. Wiring diagrams ...................43 7. Refrigerant cycle diagram..............57 8. Capacity tables ..................62 9. Capacity coefficient factor..............76 10. Operation range..................78 11. Air flow and temperature distributions(reference data)....79 12.
  • Page 3 Test condition of international standard CLASSIFICATION AHAM 9306 5151 210/240 1861.1 DB°C(°F) 27.0 27.0 26.7(80) 26.7(80) 27.0 29.0 Indoor Cooling WB°C(°F) 19.5 19.0 19.4(67) 19.4(67) 19.0 19.0 Capacity DB°C(°F) 35.0 35.0 35.0(95) 35.0(95) 35.0 46.0 Outdoor WB°C(°F) 24.0 24.0 23.9(75) 23.9(75) 24.0 24.0...

  • Page 4: General Description

    1) General Wall Mounted Type Units : Units with Simplicity in design. 2) Art Cool Units : A new concept of cooling introduced by LG in the field of Air Conditioning. 3) Inverter Units : These units are capable of minimising the Power consumption with the unique inverter technology.

  • Page 5: Models Line Up

    ART COOL AS-W096F*G2 AS-W126F*G2 [A09AW* NF2] [A12AW* NF2] Silver Gold Wall Mounted Type AS-W096ADR0 AS-W126ADR0 [S09AA NA0] [S12AA NA0] Wall Mounted Type AS-W096E1G0 AS-W126E1G0 AS-W1865DH2 AS-W2465DH2 [S09AW1 NE0] [S12AW1 NE0] [S18AW N52] [S24AW N52] Wall Mounted Type AS-W0964GG1 AS-W1264GG1 AS-W1865GG1 AS-W306DGM0...

  • Page 6: Outdoor Unit

    1. Models Line up 1.2 Outdoor Unit AS-W0964GG1[S09AM N41G] AS-W1264GG1[S12AM N41G] AS-W096ADR0 [S09AA NA0] AS-W126ADR0 [S12AA NA0] AS-W096E*H2[C09AW* NE2] AS-W126E1G0[S12AW1 NE0] AS-W096E1G0[S09AW1 NE0] AS-W126E*H2 [C12AW*NE2] Heat pump AS-W096F1G2[A09AW1 NF2] AS-W126F1G2 [A12AW1 NF2] AS-W096F*G2 [A09AW* NF2] AS-W126F*G2 [A12AW* NF2] AS-W096U*H1[C09AW* NU1] AS-W126U*H1[C12AW* NU1] No.

  • Page 7: Nomenclature

    NBF F+(A/changeove)+A/clean+4way NBF F+(A/changeove)+A/clean+PTC NBF F+(A/changeove)+Autoclean+4way+PTC NBF F+(A/changeove)+A/clean+4way+Low A+PTC Negative ion+A/Clean (Nano)Plasma+Negative ion+A/Clean 4way+(Nano)Plasma F+Negative ion+A/Clean Nano Plasma F+4Way+(A/changeove)+A/clean+Oxygen generator 4way+(Nano)Plasma F+Negative ion+A/Clean+Oxygen generator Dry contact Basic + Low A Serial No. LG Model Development Serial No. 2008 Product Data...
  • Page 8 2. Nomenclature • Europe Model Number Development sequence Chassis For ART COOL type E : SE chassis F : SF chassis U : SU chassis 8 : S8 chassis For Wall mounted type D : SD chassis 4 : S4 chassis 5 : S5 chassis Indicator for unit type N : Indoor...

  • Page 9: Features & Benefits

    3. Features & Benefits LG Air Conditioners are environment-friendly and future-oriented. LG air conditioners are environment-friendly and future-oriented. To reduce freon gas, a prime ozone destroyer, we adopted an alternative refrigerant R-410A, and neo plasma air-purifying system for powerful sterilization for health-conscious customers. Also, ARTCOOL series with outstanding designs have received International Forum Design Award and Reddot Design Award.
  • Page 10 You may have heard the excitement about Inverter technology, LG Inverters are the pinnacle of energy efficiency due to the innovative operation. Rather than using a constant speed compressor, the LG Inverter system uses a variable speed compressor, which means the Cooling or Heating capacity of the Air Conditioning can be varied to suit Indoor conditions.
  • Page 11 3. Features & Benefits Strong Capable I Powerful Cooling & Heating I Powerful Heating Capacity (Chilly Area Available) You can change the power by changing the compressor frequency. Provides the greatest heating performance in cold areas Operational power with a greater scope - When outdoor temperatures fall to as low as -10°, - When you return home from outside, in case you start you can faster increase the speed of the...
  • Page 12 3. Features & Benefits NEO-Plasma Air Purifying System LG Electronics’ unique neo-plasma air purifying system, equipped with 12-level bio-enzyme filters, has further enhanced its sterilization power. While air passes each level of filters, the system can more powerfully eliminate household's fine dust and molds, ordinary odor, food smell, and cigar smoke, as well as can destroy bacteria's cell walls to completely kill them.
  • Page 13 3. Features & Benefits Plasma The PLASMA Air Purifying System Nano Bio developed uniquely by LG not only Filter Fusion Filter removes microscopic contaminants and dust, but also removes house mites, pollen, and pet fur to prevent Nano bio fusion filters allow their nano-size bio enzymes to directly allergic diseases like asthma.

  • Page 14: Auto Clean

    3. Features & Benefits Healthy Dehumidification LG Wall Mounted Split models feature a Dehumidification mode to remove uncomfortable humidity from the room without over cooling. Indoor Temperature Distribution Chart Healthy Conventional Dehumidification Since the surrounding temperature is measured after the air from the unit is...
  • Page 15 Anti Corrosion Gold Fin™ LG ’s Outdoor Heat Exchanger is coated with a golden anti- corrosive epoxy treatment on the aluminum coil to minimized corrosion. This maintains heat transfer properties of the coil for an extended time where as non-Gold Fin coils progressively lose efficiency due to surface corrosion.

  • Page 16: Air Flow

    3. Features & Benefits Optimized Cooling & Heating Air Flow LG Electronics' air conditioner, which adopts the twin air vanes, blows winds horizontally far away in the cooling mode to prevent direct blowing. And, in the heating mode, the air conditioner pushes winds downwards to provide warm air evenly, thus offering pleasant air.
  • Page 17 The romantic pastel colors, subdued luster,modern texture and the In this mode, strong, cool air is blown at high speed for super slim design of LG ARTCOOL Mirror are the answers to your 30 minutes, until the room temperature reaches 18˚C.

  • Page 18: Auto Changeover

    3. Features & Benefits Auto Changeover Low Ambient With heat pump model,cooling and heating operation is Cools the room as is necessary, even in winter. changed automatically on the base of setting temp. - In case you hold a party indoors in winter, you need to operate equipment in the computer server room for long hours, or you cannot open windows for the security's sake, you can cool the room using the...
  • Page 19 Your room will shine chicly with a famous painting or a household. beautiful photo (showcased in the product). LG ARTCOOL will convert your room into a gallery. Do you like Western paintings, Oriental paintings, or photos? The product features your desired style of famous paintings.

  • Page 20: Specifications

    4. Specifications Inverter single Inverter Single, ART COOL Models Unit AS-W096ADR0 [S09AA NA0] AS-W096E*H2[C09AW* NE2] Cooling Capacity 0.89~2.64~3.69 0.89~2.64~3.69 Btu/h. 3,070~9,000~12,620 3,070~9,000~12,620 Heating Capacity 0.89~3.60~5.00 0.89~3.60~5.00 Btu/h. 3,070~12,300~17,060 3,070~12,300~17,060 Power Input Cooling/Heating 650 / 870 650 / 870 Running Current Cooling/Heating 3 / 4 3 / 4...
  • Page 21 4. Specifications Inverter single Models Unit AS-W096F1G2[A09AW1 NF2] AS-W096F*G2 [A09AW* NF2] 1.30~2.70~3.50 1.30~2.70~3.50 Cooling Capacity Btu/h. 4,436~9,210~11,942 4,436~9,210~11,942 Heating Capacity 1.30~3.50~4.20 1.30~3.50~4.20 Btu/h. 4,436~11,940~14,330 4,436~11,940~14,330 830 / 960 830 / 960 Power Input Cooling/Heating Running Current Cooling/Heating 3.8 / 4.4 3.8 / 4.4 Starting Current Cooling/Heating...
  • Page 22 4. Specifications Inverter single Models Unit AS-W096U*H1[C09AW* NU1] AS-W126ADR0 [S12AA NA0] 0.65 ~ 2.64 ~ 3.25 0.89~3.51~4.04 Cooling Capacity Btu/h. 2,200 ~ 9,000 ~ 11,080 3,070~12,000~13,800 Heating Capacity 0.90 ~ 3.17 ~ 3.87 0.89~4,57~5,49 Btu/h. 1,800 ~ 10,800 ~ 13,950 3,070~15,600~18,720 750 / 870 1,090 / 1,260...
  • Page 23 4. Specifications Inverter single Models Unit AS-W126E*H2 [C12AW*NE2] AS-W126F1G2 [A12AW1 NF2] Cooling Capacity 0.89~3.51~4.04 1.30~3.50~4.00 Btu/h. 3,070~12,000~13,800 4,436~11,940~13,648 Heating Capacity 0.89~4.57~5.48 1.30~4.20~5.00 Btu/h. 3,070~15,600~18,720 4,436~14,330~17,060 Power Input Cooling/Heating 1,090 / 1,260 1,090 / 1,160 Running Current Cooling/Heating 4.8 / 5.7 4.9 / 5.2 4.8 / 5.7 5.7 / 6.9...
  • Page 24 4. Specifications Inverter single Models Unit AS-W126F*G2 [A12AW* NF2] AS-W126U*H1[C12AW* NU1] Cooling Capacity 1.30~3.50~4.00 0.82 ~ 3.52 ~ 3.87 Btu/h. 4,436~11,940~13,648 2,800 ~ 12,000 ~ 13,200 Heating Capacity 1.30~4.20~5.00 1.29 ~ 3.96 ~ 4.35 Btu/h. 4,436~14,330~17,060 4,400 ~ 13,500 ~ 14,850 Power Input Cooling/Heating 1,090 / 1,160...
  • Page 25 4. Specifications Inverter single Models Unit AS-W1863*H3[C18AW* N33] AS-W1868*H1 [C18AW* N81] Cooling Capacity 1.61~5.28~5.83 1.76 ~ 5.28 ~ 5.80 Btu/h. 5,500~18,000~19,900 6,000 ~ 18,000 ~ 19,800 Heating Capacity 1.67~6.07~6.73 1.40 ~ 6.07 ~ 6.65 Btu/h. 5,700~20,700~23,000 4,800 ~ 20,700 ~ 22,700 Power Input Cooling/Heating 1,630 / 1,890...
  • Page 26 4. Specifications Inverter single Models Unit AS-W2463*H3[C24AW* N33] AS-W2468*H1 [C24AW* N81] Cooling Capacity 4.43~7.03~7.73 3.87 ~ 7.03 ~ 7.74 Btu/h. 15120~24000~26400 13,200 ~ 24,000 ~ 26,400 Heating Capacity 4.19~7.95~8.35 3.37 ~ 8.44 ~ 8.88 Btu/h. 14,300~27,100~28,500 11,500 ~ 28,800 ~ 30,300 Power Input Cooling/Heating 2,600 / 2,800...
  • Page 27 4. Specifications Inverter single Inverter Single, General Wall Mounted Models Unit AS-W096E1G0[S09AW NE0] AS-W0964GG1[S09AM N41G] Cooling Capacity 0.89~2.64~3.69 0.90 ~ 2.64 ~ 3.46 Btu/h. 3,070~9,000~12,620 3,070 ~ 9,000 ~ 11,800 Heating Capacity 0.89~3.60~5.00 0.90 ~ 3.17 ~ 3.87 Btu/h. 3,070~12,300~17,060...
  • Page 28 4. Specifications Inverter single Models Unit AS-W126E1G0[S12AW* NE0] AS-W1264GG1[S12AM N41G] Cooling Capacity 0.89~3.52~4.04 0.90 ~ 3.52 ~4.04 Btu/h. 3,070~12,000~13,800 3,070 ~ 12,000 ~ 13,800 Heating Capacity 0.89~4.57~5.48 0.90 ~ 4.00 ~ 4.86 Btu/h. 3,070~15,600~18,720 3,070 ~ 13,650 ~ 16,600 Power Input Cooling/Heating 1,090 / 1,260 1,090 / 1,170...
  • Page 29 4. Specifications Inverter single Models Unit AS-W1865DH2[S18AW N52] AS-W1865GG1[S18AM N51G] Cooling Capacity 1.76~5.28~5.80 1.78~5.28 ~ 5.80 Btu/h. 6,000~18,000~19,800 6,000 ~ 18,000 ~ 19,800 Heating Capacity 1.41~6.07~6.65 1.40 ~5.80 ~ 6.65 Btu/h. 4,800~20,700~22,700 4,800 ~ 19,790 ~ 22,700 Power Input Cooling/Heating 1,640 / 1,770 1,730 / 1,800 Running Current...
  • Page 30 4. Specifications Inverter single Models Unit AS-W2465DH2[S24AW N52] AS-W306DGM0[S30AW SD0] Cooling Capacity 3.87~7.03~7.74 3.6 ~ 8.0 ~ 8.8 Btu/h. 13,200~24,000~26,400 12,283 ~ 27,296 ~ 30,026 Heating Capacity 3.37~8.08~8.88 5.3 ~ 9.6 ~ 10.2 Btu/h. 11,500~27,570~30,300 18,084 ~ 32,775 ~ 34,802 Power Input Cooling/Heating 2,500 / 2,880...

  • Page 31: Dimensions

    4. Specifications Inverter single Models Unit AS-W366DGM0[S36AW SD0] Cooling Capacity 4.0 ~ 9.0 ~ 9.8 Btu/h. 13,648 ~ 30,708 ~ 33,438 Heating Capacity 5.6 ~ 10.4 ~ 11.0 Btu/h. 19,107 ~ 35,485 ~ 37,532 2,980 / 3,450 Power Input Cooling/Heating Running Current Cooling/Heating 13.6 / 16.5...
  • Page 32 5. Dimensional drawings Indoor units 5.1 Indoor Units 2008 Product Data...

  • Page 33: Dimensional Drawings

    5. Dimensional drawings Indoor units 2008 Product Data...
  • Page 34 5. Dimensional drawings Indoor units 2008 Product Data...
  • Page 35 5. Dimensional drawings Indoor units 2008 Product Data...
  • Page 36 5. Dimensional drawings Indoor units 2008 Product Data...
  • Page 37 5. Dimensional drawings Indoor units 2008 Product Data...
  • Page 38 5. Dimensional drawings Indoor units 2008 Product Data...
  • Page 39 5. Dimensional drawings Indoor units 2008 Product Data...
  • Page 40 5. Dimensional drawings Outdoor units 5.2 Outdoor Units 2008 Product Data...
  • Page 41 5. Dimensional drawings Outdoor units 2008 Product Data...
  • Page 42 5. Dimensional drawings Outdoor units 2008 Product Data...
  • Page 43 5. Dimensional drawings Outdoor units 2008 Product Data...

  • Page 44: Wiring Diagrams

    6. Wiring diagrams Indoor Unit 6.1 Indoor units Models: AS-W096E1G0, AS-W0964GG1, AS-W126E1G0, AS-W1264GG1,AS-W1865GG1, AS-W2465DH2 Models: AS-W096F1G2, AS-W096F*G2, AS-W126F*G2 2008 Product Data...
  • Page 45 6. Wiring diagrams Indoor Unit Models: AS-W096U*H1, AS-W126U*H1, AS-W1863*H3 Models: AS-W096E*H2, AS-W126E*H2, AS-W126F1G2 2008 Product Data...
  • Page 46 6. Wiring diagrams Indoor Unit Models: AS-W096ADR0, AS-W126ADR0 2008 Product Data...
  • Page 47 6. Wiring diagrams Indoor Unit Models: AS-W1865DH2 CN_L/R(BL) CN_U/D(WH) CN_HVB(BL) CN_DISP2(BL) CN_DISP1(WH) CN_MOTOR1 CN_TH1 CN_TH2 2008 Product Data...
  • Page 48 6. Wiring diagrams Indoor Unit Models: AS-W1868*H1 Models: AS-W2463*H3 2008 Product Data...
  • Page 49 6. Wiring diagrams Indoor Unit Models: AS-W2468*H1 2008 Product Data...
  • Page 50 6. Wiring diagrams Indoor Unit Models:AS-W306DGM0,AS-W366DGM0 CN-U/D(WH) CN-DISP2(BL) CN-MOTOR1 CN-L/R(BL) CN-HVB CN-12V CN-DISP1(WH) CN-TH1 CN-TH2 2008 Product Data...
  • Page 51 6. Wiring diagrams Outdoor units 6.2 Outdoor units Models: AS-W096E1G0, AS-W096U*H1, AS-W126E1G0, AS-W126U*H1AS-W096E*H2, AS-W126E*H2, AS-W096F1G2, AS-W096F*G2, AS-W126F1G2, AS-W126F*G2 Models: AS-W0964GG1, AS-W1264GG1 2008 Product Data...
  • Page 52 6. Wiring diagrams Outdoor units Models: AS-W096ADR0, AS-W126ADR0 2008 Product Data...
  • Page 53 6. Wiring diagrams Outdoor units Models: AS-W1865DH2 CN_FAN(A) CN_4WAY CN_COIL1 CN_COIL2 CN_TH3 (SUC/DIS_I) CN_TH2 CN_COM CN_LEV1 (AIR/PIPE) 2008 Product Data...
  • Page 54 6. Wiring diagrams Outdoor units Models: AS-W1865GG1, AS-W1863*H3 Models: AS-W1868*H1 2008 Product Data...
  • Page 55 6. Wiring diagrams Outdoor units Models: AS-W2463*H3 Models: AS-W2468*H1, AS-W2465DH2 2008 Product Data...
  • Page 56 6. Wiring diagrams Outdoor units Models: AS-W306DGM0 CN_H/P CN-PFC-IN CN 4WAY CN-PFC-OUT CN_TH3 CN-TH2 CN_LEV1 CN-MOTOR1 CN_COM 2008 Product Data...
  • Page 57 6. Wiring diagrams Outdoor units Models: AS-W366DGM0 CN_H/P CN-PFC-IN CN 4WAY CN-PFC-OUT CN_TH3 CN-TH2 CN-MOTOR1 CN_LEV1 CN_COM CN-MOTOR2 2008 Product Data...

  • Page 58: Refrigerant Cycle Diagram

    7. Refrigerant cycle diagram Model No : AS-W096U*H1, AS-W126U*H1, AS-W1865GG1, AS-W1863*H3, AS-W2463*H3 Indoor Unit Outdoor Unit CHECK VALVE Liquid Side 3-Way Valve CAPILLARY TUBE Heat Heat Exchanger Exchanger (Evaporator) (Condenser) Gas Side Reversing Valve Accumulator 3-Way Valve Cooling Compressor Heating N.B.
  • Page 59 7. Refrigerant cycle diagram Model no: AS-W096ADR0,AS-W0964GG1, AS-W096E*H2, AS-W096F1G2, AS-W096F*G2, AS-W096E1G0, AS-W126E1G0, AS-W126ADR0, AS-W126E*H2, AS-W126F1G2, AS-W126F*G2, AS-W1264GG1 Indoor Unit Outdoor Unit Liquid Side 2-Way Valve Heat Heat Exchanger Exchanger (Evaporator) (Condenser) Gas Side Accumulator 3-Way Valve Cooling Compressor Heating LOC.
  • Page 60 7. Refrigerant cycle diagram Model no: AS-W1865DH2, AS-W1868*H1 Indoor Unit Outdoor Unit Liquid Side 2-Way Valve Heat Heat Exchanger Exchanger (Evaporator) (Condenser) Gas Side Reversing Valve 3-Way Valve Cooling Compressor Heating LOC. Description PCB Connector Thermistor for indoor air temperature CN_TH1(INDOOR) Thermister for indoor pipe(in) temperature Thermister for indoor pipe(out) temperature...
  • Page 61 7. Refrigerant cycle diagram Model no: AS-W2468*H1, AS-W2465DH2 Indoor Unit Outdoor Unit Liquid Side 3-Way Valve Heat Heat Exchanger Exchanger (Evaporator) (Condenser) Gas Side Reversing Valve 3-Way Valve Cooling Compressor Heating LOC. Description PCB Connector Thermistor for indoor air temperature CN_TH1(INDOOR) Thermister for indoor pipe(in) temperature Thermister for indoor pipe(out) temperature...
  • Page 62 7. Refrigerant cycle diagram Model no: AS-W306DGM0, AS-W366DGM0 Indoor Unit Outdoor Unit Reversing Liquid Side Valve 3-Way Valve High Pressure Heat Heat Accumulator Exchanger Exchanger (Condenser) (Evaporator) Inverter Compressor Gas Side 3-Way Valve Cooling Heating LOC. Description PCB Connector Thermister for indoor air temperature CN_TH1(INDOOR) Thermister for indoor pipe(in) temperature Thermister for indoor pipe(out) temperature...

  • Page 63: Capacity Tables

    8. Capacity tables Cooling 8.1 Cooling Capacity AS-W096ADR0 Indoor Air Outdoor Air Temperature : °CDB Temperature °CWB °CDB 14.0 20.0 2.59 2.21 0.36 2.48 2.14 0.37 2.32 2.06 0.50 16.0 22.0 2.75 2.24 0.49 2.63 2.18 0.49 2.48 2.09 0.59 18.0 25.0 2.91...
  • Page 64 8. Capacity tables Cooling AS-W096F1G2, AS-W096F*G2 Indoor Air Outdoor Air Temperature : °CDB Temperature °CWB °CDB 14.0 20.0 2.19 1.71 0.54 2.14 1.69 0.64 2.04 1.65 0.75 16.0 22.0 2.55 1.94 0.55 2.50 1.92 0.65 2.38 1.86 0.76 18.0 25.0 2.85 2.11 0.56...
  • Page 65 8. Capacity tables Cooling AS-W0964GG1 Indoor Air Outdoor Air Temperature : °CDB Temperature °CWB °CDB 14.0 20.0 2.14 1.67 0.54 2.09 1.65 0.64 2.00 1.61 0.74 16.0 22.0 2.50 1.89 0.55 2.44 1.88 0.65 2.33 1.82 0.75 18.0 25.0 2.79 2.06 0.55 2.73...
  • Page 66 8. Capacity tables Cooling AS-W126E1G0, AS-W126E*H2 Indoor Air Outdoor Air Temperature : °CDB Temperature °CWB °CDB 14.0 20.0 2.85 2.22 0.71 2.79 2.21 0.85 2.66 2.14 0.99 16.0 22.0 3.33 2.53 0.73 3.26 2.50 0.86 3.10 2.43 1.00 18.0 25.0 3.71 2.75 0.74...
  • Page 67 8. Capacity tables Cooling AS-W126U*H1 Indoor Air Outdoor Air Temperature : °CDB Temperature °CWB °CDB 14.0 20.0 2.85 2.22 0.71 2.79 2.21 0.85 2.66 2.14 0.99 16.0 22.0 3.33 2.53 0.73 3.26 2.50 0.86 3.10 2.43 1.00 18.0 25.0 3.71 2.75 0.74 3.63...
  • Page 68 8. Capacity tables Cooling AS-W1863*H3 Indoor Air Outdoor Air Temperature : °CDB Temperature °CWB °CDB 14.0 20.0 4.28 3.34 1.07 4.19 3.31 1.27 3.99 3.22 1.48 16.0 22.0 4.99 3.79 1.08 4.89 3.75 1.29 4.66 3.64 1.50 18.0 25.0 5.57 4.12 1.10 5.45...
  • Page 69 8. Capacity tables Cooling AS-W1865GG1 Indoor Air Outdoor Air Temperature : °CDBB Temperature °CWB °CDB 20.0 5.18 4.25 0.96 4.95 4.11 1.00 4.65 3.94 1.34 22.0 5.50 4.30 1.30 5.27 4.17 1.31 4.97 4.02 1.58 25.0 5.81 4.34 1.40 5.59 4.22 1.41 5.28...
  • Page 70 8. Capacity tables Cooling AS-W2463*H3 Indoor Air Outdoor Air Temperature : °CDB Temperature °CWB °CDB 14.0 20.0 5.70 4.45 1.70 5.58 4.41 2.02 5.32 4.29 2.35 16.0 22.0 6.66 5.05 1.73 6.52 5.00 2.05 6.21 4.86 2.39 18.0 25.0 7.43 5.50 1.76 7.27...
  • Page 71 8. Capacity tables Cooling AS-W2468*H1 Indoor Air Outdoor Air Temperature : °CDB Temperature °CWB °CDB 14.0 20.0 5.70 4.65 1.61 5.58 4.61 1.90 5.32 4.49 2.22 16.0 22.0 6.66 5.28 1.63 6.52 5.23 1.93 6.21 5.08 2.25 18.0 25.0 7.43 5.75 1.65 7.27...
  • Page 72 8. Capacity tables Cooling AS-W366DGM0 Indoor Air Outdoor Air Temperature : °CDB Temperature °CWB °CDB 14.0 20.0 8.82 7.29 1.65 8.44 7.05 1.72 7.93 6.77 2.31 16.0 22.0 9.37 7.38 2.23 8.98 7.16 2.25 8.46 6.89 2.72 18.0 25.0 9.91 7.44 2.41 9.52...

  • Page 73: Heating Capacity

    8. Capacity tables Heating 8.2 Heating Capacity AS-W096ADR0, AS-W096E*H2 Outdoor Air Temperature : °CWB Indoor Air Temperature (°C) °CDB 16.0 2.71 0.71 2.85 0.69 3.09 0.72 3.30 0.78 3.66 0.83 3.87 0.87 4.20 0.92 18.0 2.68 0.72 2.84 0.71 3.09 0.75 3.30 0.80...
  • Page 74 8. Capacity tables Heating AS-W126ADR0, AS-W126E1G0, AS-W126E*H2 Outdoor Air Temperature : °CWB Indoor Air Temperature (°C) °CDB 16.0 3.44 1.03 3.62 1.00 3.92 1.05 4.19 1.13 4.65 1.21 4.91 1.25 5.33 1.34 18.0 3.40 1.04 3.61 1.03 3.92 1.08 4.18 1.16 4.62 1.23...
  • Page 75 8. Capacity tables Heating AS-W1863*H3 Outdoor Air Temperature : °CWB Indoor Air Temperature (°C) °CDB 16.0 4.56 1.54 4.80 1.50 5.20 1.57 5.56 1.69 6.17 1.81 6.52 1.88 7.08 2.00 18.0 4.52 1.56 4.79 1.54 5.21 1.62 5.56 1.74 6.13 1.85 6.44 1.92...
  • Page 76 8. Capacity tables Heating AS-W2465DH2 Outdoor Air Temperature : °CWB Indoor Air Temperature (°C) °CDB 16.0 6.08 2.35 6.39 2.29 6.93 2.40 7.40 2.58 8.21 2.76 8.68 2.87 9.42 3.06 18.0 6.01 2.38 6.38 2.35 6.94 2.47 7.40 2.65 8.16 2.82 8.57 2.92...

  • Page 77: Capacity Coefficient Factor

    9. Capacity coefficient factor Cooling 30k/36k 9k/12k/18k Total Pipe Length(m) Heating 30k/36k 9k/12k/18k Total Pipe Length(m) 2008 Product Data...
  • Page 78 9. Capacity coefficient factor Max. Pipe Max. Elevation Additional Model No. Length(m) Refrigerant[g/m(oz/ft)] AS-W096ADR0 20(0.22) AS-W0964GG1 20(0.22) AS-W096E*H2 20(0.22) AS-W096E1G0 20(0.22) AS-W096F*G2 20(0.22) AS-W096F1G2 20(0.22) AS-W096U*H1 20(0.22) AS-W126ADR0 20(0.22) AS-W1264GG1 20(0.22) AS-W126E*H2 20(0.22) AS-W126E1G0 20(0.22) AS-W126F*G2 20(0.22) AS-W126F1G2 20(0.22) AS-W126U*H1 20(0.22)

  • Page 79: Operation Range

    10. Operation range Cooling Heating Operative Outdoor Unit [°C DB] Continuous operation Continuous Outdoor Unit operation [°C DB] Operative Indoor Unit [°C DB] Indoor Unit [°C DB] Operative: Intermittent operation due to the operational conditions (indoor/outdoor temperature, humidity, load etc.) can cause the heating capacity to decrease.

  • Page 80: Air Flow And Temperature Distributions(Reference Data)

    11. Air flow and temperature distributions(reference data) General Wall Mouted 9kBtu/h Cooling Heating Discharge angle:45° Discharge angle:50° Air velocity [m/s] Air velocity [m/s] 2.7m 2.7m 0.75 0.75 Temperature [˚C] Temperature [˚C] 2.7m 2.7m ART COOL Deluxe 9kBtu/h Cooling Heating Discharge angle:45° Discharge angle:50°...
  • Page 81 11. Air flow and temperature distributions(reference data) ART COOL Deluxe 12kBtu/h Cooling Heating Discharge angle:45° Discharge angle:50° Air velocity [m/s] Air velocity [m/s] 2.7m 2.7m 0.75 0.75 Temperature [˚C] Temperature [˚C] 2.7m 2.7m ART COOL Standard 12kBtu/h Cooling Heating Discharge angle:45° Discharge angle:45°...
  • Page 82 11. Air flow and temperature distributions(reference data) General Wall Mouted 12kBtu/h Cooling Heating Discharge angle:45° Discharge angle:50° Air velocity [m/s] Air velocity [m/s] 2.7m 2.7m 1.25 1.25 0.75 0.75 Temperature [˚C] Temperature [˚C] 2.7m 2.7m General Wall Mouted 18kBtu/h Cooling Heating Discharge angle:45°...

  • Page 83: Sound Level

    Microphone - The operating conditions are assumed to be standard. Sound Levels [dB(A)] Sound Levels [dB(A)] Model Model AS-W096ADR0 AS-W1863*H3 AS-W0964GG1 AS-W1865DH2 AS-W096E*H2 AS-W1865GG1 AS-W1868*H1 AS-W096E1G0 AS-W2463*H3 AS-W096F*G2 AS-W2465DH2 AS-W096F1G2 AS-W2468*H1 AS-W096U*H1 AS-W306DGM0 AS-W126ADR0 AS-W366DGM0 AS-W1264GG1 AS-W126E*H2 AS-W126E1G0 AS-W126F*G2...

  • Page 84: Sound Levels

    12. Sound levels AS-W126E1G0 AS-W126F1G2 AS-W1264GG1 AS-W126E*H2 AS-W126F*G2 High High High Middle Middle Middle NC-65 NC-65 NC-65 NC-60 NC-60 NC-60 NC-55 NC-55 NC-55 NC-50 NC-50 NC-50 NC-45 NC-45 NC-45 NC-40 NC-40 NC-40 NC-35 NC-35 NC-35 NC-30 NC-30 NC-30 NC-25 NC-25 NC-25 Approximate Approximate...
  • Page 85 12. Sound levels AS-W366DGM0 AS-W306DGM0 Octave Band Center Frequency (Hz) Octave Band Center Frequency (Hz) 2008 Product Data...

  • Page 86: Sound Pressure Level

    - The operating conditions are assumed to be standard. Sound Levels [dB(A)] Sound Levels [dB(A)] Model Model AS-W096ADR0 AS-W1863*H3 AS-W0964GG1 AS-W1865DH2 AS-W096E*H2 AS-W1865GG1 AS-W096E1G0 AS-W1868*H1 AS-W096F*G2 AS-W2463*H3 AS-W096F1G2 AS-W2465DH2 AS-W096U*H1 AS-W2468*H1 AS-W126ADR0 AS-W306DGM0 AS-W1264GG1 AS-W366DGM0...
  • Page 87 12. Sound levels AS-W126F1G2 AS-W126F*G2 AS-W1264GG1 AS-W1863*H3 AS-W126U*H1 NC-65 NC-65 NC-65 NC-60 NC-60 NC-60 NC-55 NC-55 NC-55 NC-50 NC-50 NC-50 NC-45 NC-45 NC-45 NC-40 NC-40 NC-40 NC-35 NC-35 NC-35 NC-30 NC-30 NC-30 NC-25 NC-25 NC-25 Approximate Approximate Approximate NC-20 NC-20 NC-20 Hearing Hearing...
  • Page 88 12. Sound levels AS-W306DGM0 AS-W366DGM0 Octave Band Center Frequency (Hz) Octave Band Center Frequency (Hz) 2008 Product Data...

  • Page 89: Remote Controller

    13. Remote controller Models: AS-W096E*H2/AS-W126E*H2/AS-W096F1G2/AS-W126F1G2/ AS-W096F*G2/AS-W126F*G2/AS-W1868*H1/AS-W2468*H1 The controls will look like the following. 1. ON/OFF BUTTON Used to turn off/on the unit. Signal transmitter 2. OPERATION MODE SELECTION BUTTON Used to select the operation mode. 3. ROOM TEMPERATURE SETTING BUTTONS Used to select the room temperature.
  • Page 90 13. Remote controller Models: AS-W096ADR0/AS-W126ADR0 The controls will look like the following. Signal transmitter 1. ON/OFF BUTTON Used to turn off/on the unit. 2. OPERATION MODE SELECTION BUTTON Used to select the operation mode. 3. ROOM TEMPERATURE SETTING BUTTONS Used to select the room temperature. 4.

  • Page 91: Wireless Remote Controller

    13. Remote controller Wireless Remote Controller 1. START/STOP BUTTON The controls will look like the following. Used to turn off/on the unit. 2. OPERATION MODE SELECTION BUTTON Signal transmitter Used to select the operation mode. 3. ROOM TEMPERATURE SETTING BUTTONS Used to select the room temperature.

  • Page 92: Installation

    14. Installation Installation Map NOTICE Installation parts you should purchase. Installation plate Sleeve Bushing-Sleeve Putty(Gum Type Sealant) Bend the pipe as closely on the wall as possible, but be careful that it doesn't break. Air Discarge Vertical Air deflector Operation Indication Lamps Vinyl tape (Wide) Forced Operation Button •...

  • Page 93: Select The Best Location

    14. Installation Select the best Location Indoor unit 1. Do not have any heat or steam near the unit. More than 2. Select a place where there are no obstacles in front 100mm More than 200mm of the unit. 3. Make sure that condensation drainage can be conveniently routed away.

  • Page 94: Fixing Installation Plate

    14. Installation Fixing Installation Plate The wall you select should be strong and solid Installation Plate enough to prevent vibration 1. Mount the installation plate on the wall with type "A" screws. If mounting the unit on a concrete Chassis Hook wall, use anchor bolts.

  • Page 95: Burrs Removal

    14. Installation Burrs removal Pipe 1. Completely remove all burrs from the cut cross Reamer section of pipe/tube. 2. Put the end of the copper tube/pipe in a downward Point down direction as you remove burrs in order to avoid dropping burrs into the tubing.

  • Page 96: Connecting The Piping

    14. Installation Connecting the Piping Indoor 1. Prepare the indoor unit's piping and drain hose for installation through the wall. 2. Pull the plastic tubing cover(see the illustration by) and pull the tubing and drain hose away from chassis. For right rear piping 1.
  • Page 97 14. Installation For left rear piping 1. Route the indoor tubing and the drain hose to the required piping hole position. 2. Insert the piping, drain hose, and the connecting cable into the piping hole. Drain pipe 3. Insert the connecting cable into the indoor unit. •...
  • Page 98 14. Installation Wrap the insulation material around the connecting portion. Drain pipe 1. Overlap the connection pipe insulation material and the indoor unit pipe insulation material. Bind them Indoor unit drain hose together with vinyl tape so that there may be no gap. Vinyl tape(narrow) Adhesive 2.
  • Page 99 14. Installation Installation Information. For left piping. Follow the instruction below. Good case • Press on the upper side of clamp and unfold the tubing to downward slowly. Bad case • Following bending type from right to left may cause damage to the tubing. 2008 Product Data...
  • Page 100 14. Installation Outdoor Align the center of the pipings and sufficiently tighten the flare nut by hand. Finally, tighten the flare nut with torque wrench until the Outdoor unit wrench clicks. • When tightening the flare nut with torque wrench, ensure the direction for tightening follows the arrow on Liquid side piping the wrench.

  • Page 101: Connecting The Cables

    14. Installation Connecting the Cables Indoor Connect the cable to the indoor unit by connecting the wires to the terminals on the control board individually according to the outdoor unit connection. (Ensure that the color of the wires of the outdoor unit and the terminal No. are the same as those of the indoor unit.) •...
  • Page 102 14. Installation Outdoor 1. Remove the control cover from the unit by loosening Outdoor Unit the screw. Connect the wires to the terminals on the control board individually. 2. Secure the cable onto the control board with the cord clamp. 3.

  • Page 103: Checking The Drainage

    14. Installation Checking the Drainage To check the drainage. 1. Pour a glass of water on the evaporator. 2. Ensure the water flows through the drain hose of the Connecting area indoor unit without any leakage and goes out the drain hose drain exit.

  • Page 104: Forming The Piping

    14. Installation Forming the Piping Form the piping by wrapping the connecting portion of the indoor unit with Pipe insulation material and secure it with two Drain hose Vinyl tape(narrow) kinds of vinyl tapes. • If you want to connect an additional drain hose, the end of the drain outlet should be routed above the ground.
  • Page 105 14. Installation Air Purging Air purging The air and moisture remaining in the refrigerant system have undesirable effects as indicated below. 1. Pressure in the system rises. 2. Operating current rises. 3. Cooling(or heating) efficiency drops. 4. Moisture in the refrigerant circuit may freeze and block capillary tubing. 5.

  • Page 106: Finishing The Job

    14. Installation Soap water method 1. Remove the caps from the 2-way and 3-way valves. Gas side 2. Remove the service-port cap from the 3-way valve. 3. To open the 2-way valve turn the valve stem counterclockwise approximately 90°, wait for about 2~3 sec, Liquid side and close it.

  • Page 107: Test Running

    14. Installation Test Running 1. Check that all tubing and wiring are properly connected. 2. Check that the gas and liquid side service valves are fully open. Prepare remote controller 1. Remove the battery cover by pulling it according to the arrow direction.
  • Page 108 14. Installation NOTICE If the actual pressure is higher than shown, the system is most likely over-charged, and charge should be removed. If the actual pressure are lower than shown, the system is most likely undercharged, and charge should be added. PUMP DOWN This is performed when the unit is relocated or the refrigerant circuit is serviced.

  • Page 109: Installation Guide At The Seaside

    3) Select a well-drained place. 1. If you can’t meet above guide line in the seaside installation, please contact LG Electronics for the additional anticorrosion treatment. 2. Periodic ( more than once/year ) cleaning of the dust or salt particles stuck on the heat exchanger by using water...
