AMPLIFIERS Introduction CONGRATULATIONS... must meet or exceed the rated specification on your purchase of a new MTX Audio before we’ll ship it. No questions. No exceptions. Thunder Amplifier! MTX has long been the industry leader in mobile enclosures We want to ensure you get continuous high...
Page 3
AMPLIFIERS Input Panel Layout 1. Input Select 2CH / 4CH / 5CH – This switch, found on the Thunder4405, is used to match the amplifier’s input to the source unit’s output so all five channels of the amplifier are driven. If your source unit has 2 outputs (a left and right) connect them to the amplifier’s front channel inputs, and place the input select switch in the 2CH position.
AMPLIFIERS Adjusting the Gain 1. Turn the gain controls on the amplifier all the way down. 2. Turn up the volume control on the source unit to approx- imately 3/4 of maximum. 3. Adjust the front channel gain control on the amplifier until audible distortion occurs.
‘actuelle’, et puis il note ce nombre sur votre Certificat de Performance Attesté. veau amplificateur MTX Audio Thunder ! MTX a été depuis longtemps un leader L’amplificateur doit satisfaire ou dépasser les spécifications d’évaluation avant d’être envoyé.
Page 6
Agencement du panneau d’entrée 1. Input Select 2CH/ 4CH/ 5CH – Ce contrôle, trouvé sur le Thunder 4405, est utilisé pour lier l’entrée à l’unité de source de sortie pour faire fonctionner tous les cinq canaux de l’amplificateur. Si votre unité de source a 2 sor- ties (une gauche et une droite) connectez-les aux entrées de canaux d’avant de l’amplificateur, et placez le con-...
AMPLIFIERS Réglage du volume 1. Baissez complètement le gain sur l’ampli. 2. Montez le volume à environ 3/4 du maximum sur la source. 3. Montez le gain du canal de droite sur l’ampli, jusqu’à ce qu’une distorsion audible se produise. Note: The information shown for bridged stereo channels is good for both the front and rear channels...
Page 8
RMS, a 12.5 voltios, y por su compra del nuevo Amplificador poder dinámico de 14.4 voltios. Sin embargo, Thunder MTX Audio! MTX es el líder en vamos mucho más allá. la industria de gabinetes de altopar- amplificador.
Page 9
Diagrama del panel de entrada 1. Selector de Entrada 2CH / 4CH / 5CH – Este selector, encontrado en el Thunder 4405, se usa para igualar la entrada del amplificador con la salida de la unidad fuente, de manera que los cinco canales del ampli- ficador sean accionados.
AMPLIFIERS Ajuste de los controles Configuraciones de las de ganancia conexiones eléctricas 1. Ajuste los controles de ganancia del amplificador hasta el valor mínimo. 2. Gire el control del volumen de la fuente de poder hasta aproximadamente 3/4 del máximo. Note: The information shown for 3.
Front and Rear 65 Watts x 4 into a 4 Ohm load 125 Watts x 4 into a 2 Ohm load MTX Audio 250 Watts bridged x 2 into a 4 Ohm load 4545 E. baseline Rd. Phoenix, AZ 85042...
Page 12
AMPLIFIERS Eingangskonsolen-Layout 1. Eingangsignaloption 2CH/4CH/5CH – Dieser Knopf am Thunder 4405 wird verwendet, um das Eingangssignal des Verstärkers an das Ausgangssignal der Quelle anzugleichen, damit all fünf Kanäle des Verstärkers angetrieben werden. Wenn das Quellgerät 2 Ausgangssignale hat (links und rechts), verbinden Sie diese mit den vorderen Eingangssignalkanälen des Verstärkers und stellen Sie den...
AMPLIFIERS Einstellen der Typischer Lautsprecher Anschlusskonfigurationen Verstärkungsregler 1. Drehen Sie die Verstärkungsregler auf dem Verstärker ganz aus. 2. Drehen Lautstärkeregler Eingangsgerät auf ca. æ des Maximums. Note: The information shown for bridged stereo channels is good 3. Stellen Sie den Verstärkungsregler des rechten Kanals for both the front and rear channels auf dem Verstärker ein, bis eine Verzerrung hörbar wird.
Notes Warranty All MTX Audio Thunder Amplifiers purchased in the United States from an authorized MTX dealer are guaranteed against defects in material and workmanship for a peri- od of three years from the date purchased by the end user if the product is installed by an authorized MTX dealer, and one year if installed by the consumer.
