Introduction
1

Name of parts

The unit can be operated by pressing buttons on the frame of the panel (panel but-
tons) and by touching buttons displayed on the screen (touch switches). This deck
supports use of a remote control. The remote control is sold separately and can be
purchased at your local retailer.

Panel buttons

Press the panel buttons found on either side of the screen to operate the device.
PWR button
1
CONT button
2
(AUDIO) SOURCE
3
Button
VOL buttons
4
DISP button
5
OPEN button
6
NAVI button
7
DEST button
8
(NAVI) MENU button
9
TUNE/TRACK buttons
10
INFO button
11
MUTE button
12
■
Press the
Press to turn the DVD or audio ON or OFF.
Press to display the audio or DVD operation screens.
Press to display the audio menu screen that enables the switching of audio
modes.
Press to adjust the DVD or audio volume.
Press to adjust the screen image quality or blacken the screen.
Calls up the TILT/EJECT screen.
Press to display the navigation screen and present location.
Press to set the destination determined by the navigation system.
Press to display the navigation menu screen.
Press to select radio stations, CD audio tracks and DVD chapters.
Press to operate each navigation information function.
Press to temporarily cut off the sound.
MENU
button.
A menu screen appears.
