ATR833A - OLED
VHF Communication
Transceiver
P/N 833A-(1xx)-(1xx)
Operation and Installation
(Document-No. 01.1411.010.71e)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATR833A and is the answer not in the manual?

Questions and answers

Related Manuals for Funkwerk ATR833A

Summary of Contents for Funkwerk ATR833A

  • Page 1 ATR833A - OLED VHF Communication Transceiver P/N 833A-(1xx)-(1xx) Operation and Installation (Document-No. 01.1411.010.71e)
  • Page 2 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation Change History Revision Date Description of Change 1.00 20.07.2010 FAV – First Release – 2-Knob-HMI New operation function SW V6.1 Microphone-Muting for single-PTT 1.01 31.08.2010 Squelch default Correction after internal review 1.02 07.12.2010 Correction of Compliance New cable harness 2.00...

  • Page 3: Table Of Contents

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation CONTENTS GENERAL......................5 Symbols ....................5 Abbreviations ................... 5 Customer Support..................6 Features....................6 OPERATION ....................... 7 Controls ....................7 ON/OFF ....................9 Display ..................... 9 Basic Settings ..................11 2.4.1 VOL - Volume................12 2.4.2...
  • Page 4 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation INSTALLATION ....................29 Advices and Tips ................... 29 Telecommunication Data ............... 29 Scope of delivery ................... 29 Unpacking and Inspecting the Equipment..........30 Mounting ....................30 Equipment Connections................. 31 4.6.1 Microphone-Connection ............31 4.6.2...

  • Page 5: General

    1 GENERAL This manual contains information about the physical, mechanical and electrical characteristics, as well as information about installation and operation of the aeronautical VHF voice radio ATR833A. 1.1 Symbols Advices whose non-observance can cause damage to the device or other parts of the equipment.

  • Page 6: Customer Support

    Avionics portal www.funkwerk-avionics.com. Any suggestions for improvement of our manuals are welcome. Contact: service@funkwerk-avionics.com. Informations on software updates are available at Funkwerk Avionics web portal www.funkwerk-avionics.com. 1.4 Features • VHF communication transceiver with 6W output power in 160mm format • Frequency range 118,000 to 136,975 MHz •...

  • Page 7: Operation

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 2 OPERATION 2.1 Controls Short press: CHANGE Access user frequency Activate / memory / list of last Interchange Deactivate used frequencies active and dual watch Long press: standby reception of In MEM only: store...
  • Page 8 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation Switch On press button for approx. 0.5 s ON/OFF Switch Off press button for approx. 2 s Activates/Deactivates the mode for mutual DUAL reception of standby frequency WATCH (indicated by “DW” instead of “SBY” for standby frequency) 1.

  • Page 9: On/Off

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 2.2 ON/OFF Turn the device on with press button for 0.5 s OFF: press button for 2 s After turning-on the display shows the software version as follows: ATR833A Device Name ATR833A v6.0 Software-Version e.g.
  • Page 10 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation Display Meaning Remark Fixed label for active frequency Label for standby frequency, Dual watch mode allows when no dual watch activated intermittent monitoring of standby frequency activity Label for standby frequency, Dual watch mode allows...

  • Page 11: Basic Settings

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation Display Meaning Remark Volume of external audio- Set to 00, if no external signals device attached, to prevent noise pickup Item from user memory Substitutes standby frequency; can have name, if provided by user. Active...

  • Page 12: Vol - Volume

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 2.4.1 VOL - Volume button, but is also Can be reached by a long press of the automatically chosen by the radio after 12 seconds of user inactivity. Adjusts the volume of received radio signals by turning the knob.

  • Page 13: Dim - Display Brightness

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation The default Squelch setting is SQ05 (up to SW V5.7: SQ07). High values can suppress weak signals. Squelch is not related to any function of the Intercom. 2.4.3 DIM – Display Brightness By short pressing the...

  • Page 14: Dwm - Dual Watch Mute

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 2.4.5 DWM - Dual Watch Mute By short pressing the key four times, with help from the rotary knob the muting of the volume level for receptions on the standby frequency (when having dual watch active) can be controlled. This allows acoustic distinction between both frequencies.

  • Page 15: Ext - Volume Of The External Audio Input

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 2.4.7 EXT - Volume of the External Audio Input By short pressing the key six times, with help from the rotary knob, the volume from the connected external audio signals (Warning tones, music, etc…) can be set.

  • Page 16: Frequency Setting

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 2.5 Frequency Setting Frequency setting is always done by the two steps of 1. entering a new standby frequency to the desired value, and then 2. interchanging the new standby frequency and the previous active...

  • Page 17: Recall A Frequency From The User Memory

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation In order to speed up the entering of new frequencies, it is possible to configure the radio to allow entering of those frequencies only that are used with 25 kHz channel width. Please refer to chapter 3.1 for information on this configuration.

  • Page 18: Recall A Frequency From The List Of The 10 Last Used

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation Alternatively, the memory access automatically ends after a timeout, or can be ended by pressing twice. The former standby frequency has now been substituted by the frequency selected from the memory. 2.5.4 Recall a Frequency from the List of the 10 Last Used The radio automatically keeps track of the last 10 used active frequencies.
  • Page 19 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation • Display (Example) Step 1. Have frequency to be stored set as 124.350 active frequency 135.700 VOL 03 2. Enter memory list: 124.350 • Press once in order to access 122.000 the user memory. (This overwrites the MEM 00 KEMPTEN former standby frequency.)

  • Page 20: Dual Watch Operation

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 6. Enter the name • 124.350 by changing the selected character with , and advancing the selection 124.350 MEM 17 KONSTANZ with , just as when manually entering a standby frequency. 7. Store the name 124.350...
  • Page 21 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation For dual watch, the squelch must be set to a value of 02 at least, as without proper squelch functionality the radio would not be able to detect whether on the active frequency a reception takes place.

  • Page 22: Transmission

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 2.7 Transmission By pushing the PTT button, the device starts transmission on the active frequency. The operation of the transmission is indicated by “TX” in front of the frequency used. ACT TX 123.450 135.700...

  • Page 23: Configuration

    3.1 SPC - Channel Spacing With this setting, the ATR833A can be configured to constrain frequency selection to 25 kHz channels only. This can be used to speed up the manual frequency input in areas where no 8.33 kHz channel spacing is used.

  • Page 24: Energy Saving Mode - Automatic Display Darkening

    This configuration item is not used for selection of 8.33 kHz or 25 kHz use of a specific frequency, as this is done by the ATR833A automatically depending onto the frequency value entered. The interested user may refer to chapter 5 for information about which frequency values correspond to which channel widths.

  • Page 25: Ptt-Button Selection

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation This feature should only be used when • it can be foreseen that no frequency changes will be required (i.e. when using only limited airspace near one airport, e.g. for circuit pattern training flights), and •...

  • Page 26: Ext - External Audio Input's Behavior

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation When deactivating one PTT button and microphone for transmissions in order to keep passengers from interfering with ATC communication, don’t forget to reactivate the copilot’s PTT after end of the flight. 3.4 EXT – External Audio Input’s Behavior The external audio input can be used to feed a monaural audio signal to the amplifier for the headsets/speaker.

  • Page 27: Microphone Input Sensitivity (Mls/Mld/Mrs/Mrd)

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 3.5 Microphone Input Sensitivity (MLS/MLD/MRS/MRD) 3.5.1 MLS – Left Standard microphone Input Sensitivity 3.5.2 MLD – Left Dynamic Microphone Input Sensitivity 3.5.3 MRS – Right Standard Microphone Input Sensitivity 3.5.4 MRD – Right Dynamic Microphone Input Sensitivity Every microphone input’s sensitivity can be individually...

  • Page 28: Tst - Test Mode

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation For correct microphone sensitivity configuration, VOX must be set to 5 previously (for VOX-settings refer to section 0). Don’t care for volume of the headset’s/speakers output during this configuration, as this is set separately by INT.

  • Page 29: Installation

    6k00A3E for 25khz channel spacing Emission Designator: 5k00A3E for 8,33kHz channel spacing 4.3 Scope of delivery Part Number Description ATR833A ATR833A - VHF communication transceiver SSATR2 Connector (Only if no cable set was ordered) MB800A2 Mounting Block Set 01.1411.010.71e User Manual „Operation and Installation“...

  • Page 30: Unpacking And Inspecting The Equipment

    • In cooperation with a maintenance shop, location and kind of the installation are specified. The maintenance shop can supply all cables. Suitable sets of cables are available from Funkwerk Avionics GmbH. • Select a position away from heat sources. Care for adequate convection cooling.

  • Page 31: Equipment Connections

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 4.6 Equipment Connections One 25 pin D-SUB miniature connector includes all electrical connections, except for the antenna. The (+UB)-wire has to protected by circuit breaker (4 Amp. slow-blow)! 4.6.1 Microphone-Connection Microphone Left Right...

  • Page 32: Audio-Input

    GND, in order to avoid disturbances received through that wire. 4.6.4 Remote Control Panel In tandem-seated aircrafts it is possible to control the ATR833A by a remote control panel (ATR600RT Remote Control Unit). The choice of the remote control depends onto the software version of the ATR833A: Version up to SW V6.3 are remote controlled by the...

  • Page 33: Wiring

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 4.7 Wiring 4.7.1 Conductor Cross Section Power Supply (Power, GND): AWG18 (0.96 mm²) Signals: AWG22 (0.38 mm²) The conductors used must be approved for aircraft installation. 4.7.2 Connector – Pin Allocation SSATR2 25-pin connector at...
  • Page 34 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation MIC-L-DYN MLD+ Input dynamic Microphone (Glider/Gooseneck) Pilot/Left DATA-RX RS232 RX (for Remote Control) do not connect 11 +12V-PWR Input Power Supply +12V 12 +12V-PWR Input Power Supply +12V 13 GND Ground Side of Power Supply 14 MIC-R-GND MRS−...

  • Page 35: Wiring With Cable Harness Bsks833S/Bsks833D

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 4.7.3 Wiring with Cable Harness BSKS833S/BSKS833D 4.7.3.1 Overview Dokument-Nr.: 01.1411.010.71e / Revision: 2.00...
  • Page 36 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 4.7.3.2 Connector PWR View from aircraft’s side Input Power Supply: 12V / 14V External Fuse or Circuit Breaker: 4A slow-blow LCD Illumination: In aircraft with 12V-Lighting-Bus: connect there In all other cases: connect C2-C3...
  • Page 37 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 4.7.3.3 Connectors PL (Pilot/Left) and CR (Copilot/Right) View from aircraft’s side Per Headset-equipped Seat in Powered Aircraft: BSKSHS / BSKSOE + BSKSPTT Short-circuit the unused dynamic microphone input When using a hand-held microphone with it’s own...
  • Page 38 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation Per Seat in Motor Gliders: BSKSHS / BSKSOE + BSKSPTT „Glider-Mic“ = Gooseneck microphone, connect using shielded cable „Microphone“ = Headset-microphone External Loudspeaker in Gliders and Motor Gliders: Connection is done at connector PL...
  • Page 39 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation In Aircraft with Audio Panel: BSKSOE Connection is done at connector PL Short-circuit the unused dynamic microphone input 4.7.3.4 Connector RMT for Remote Control This connector contains the serial interface and the power supplies for the remote control unit.

  • Page 40: Wiring With Older Cable Harness Bsks833T

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 4.7.4 Wiring with older Cable Harness BSKS833T 4.7.4.1 Overview Dokument-Nr.: 01.1411.010.71e / Revision: 2.00...

  • Page 41: Antenna

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 4.7.4.2 Auto-ON Connector pin 20 determines the radio’s behaviour when applying power: To activate the radio in aircraft with a dedicated avionic master switch by this master (i.e. by applying power to the radio), connect pin 20 to the avionic master additionally to pins 11 and 12;...

  • Page 42: Microphone / Intercom Settings

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation • To avoid a mutual interference of the radios, the antenna isolation between a voice transmission and a navigation antenna as well as between double COM antennas should be as large as possible. A distance of 2 meters usually is sufficient.

  • Page 43: Post-Installation Check

    • If possible, perform the radio test on frequencies within the upper and lower VHF communication frequency range 4.11 Accessories Suitable accessories like antennas, cable sets, connectors or switches can be purchased at our online shop on www.funkwerk-avionics.com. Dokument-Nr.: 01.1411.010.71e / Revision: 2.00...

  • Page 44: Drawings

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 4.12 Drawings 4.12.1 Dimensions 14 mm Fixing clips (spring) left / right 15 mm 20 mm 140 mm 160 mm O 4,3 mm 148 mm The D-Sub-Connector (plug) has to be clamped with both spring locks.

  • Page 45: Mounting Advices

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 4.12.2 Mounting Advices Panel cut-out: 160 x 42 mm, horizontal aligned, in viewable and reachable position to the pilot Use the standard mounting blocks of Mounting Block Set MB833AS (included in delivery). For mounting in panels with a thickness of 3 mm to 5 mm longer screws are required.

  • Page 46: Frequency/Channel-Plan

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 5 ANHANG 5.1 Frequency/Channel-Plan In the following table examples for operating and displayed frequencies in the range between 118.000 ... 118.100 MHz are given. This table can be continued to 136.975 MHz following the same scheme.

  • Page 47: Technical Data

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 5.2 Technical Data GENERAL COMPLIANCE ETSO-2C37e,ED-23B Class 4, 6 ETSO-2C38e,ED-23B Class C, E STANDARD TSO-C37d, RTCA DO-186A Class 4, 6 TSO-C38d, RTCA DO-186A Class C, E Height: 38,5 mm (1,49 in) Width: 140 mm (5,51 in)
  • Page 48 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation TRANSMITTER 6 W (nominal) POWER OUTPUT 4 W (minimal) HARMONIC DISTORTION < 10 % bei 70 % modulation SIDETONE OUTPUT >0,5W into 300Ω (per headphone) 2 x standard (50mV…2V) into 100Ω MICROPHONE INPUTS...

  • Page 49: Environmental Conditions

    ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation 5.3 Environmental Conditions Characteristic DO–160D Section Cat Condition Temperature / Altitude ground survival 4.5.1 – 55°C temperature Low operating temperature 4.5.1 – 20°C High ground survival 4.5.2 + 85°C Temperature High Short-time Operating 4.5.2...
  • Page 50 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation Characteristic DO–160D Section Cat Condition Induced Signal Susceptibility 19.0 Radio Frequency 20.0 Susceptibility Emission of RF Energy 21.0 Lightning Induced Transient 22.0 Susceptibility Lightning Direct Effects 23.0 No test required Icing 24.0 No test required Electrostatic Discharge (ESD) 25.0...
  • Page 51 ATR833A / P/N 833A-(1xx)-(1xx) Operation and Installation Notes: Dokument-Nr.: 01.1411.010.71e / Revision: 2.00...
  • Page 52 Funkwerk Avionics GmbH Gewerbestraße 2 D-86875 Waal Germany phone.: +49-8246 9699 0 fax.: +49-8246 1049 E-mail: service@funkwerk-avionics.com www.funkwerk-avionics.com...
