Warranty
Coleman Gas Barbecue Grill 5/1 Year Limited Warranty
The Coleman Company, Inc. ("Coleman") warrants that for the lifetime of the product from the date of purchase, the stainless
steel panels will not break due to defects in materials or workmanship, and that for a period of five years from the date of purchase,
the burner, grates and stainless steel components will be free from defects in material and workmanship. All other components
of this barbecue grill are warranted to be free from defects in material and workmanship for one year from the date of purchase.
Coleman, at its option, will repair or replace this product or any component of the product found to be defective during the warranty
period. Replacement will be made with a new manufactured or remanufactured product or component. If the product is no longer
available, replacement may be made with a similar product of equal or greater value. This is your exclusive warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Keep the
original sales receipt. Proof of purchase is required to obtain warranty service. Coleman dealers, service centers, or retail stores
selling Coleman® products do not have the right to alter, modify or in any way change the terms and conditions of this warranty.
This warranty does not cover: normal wear of parts such as scratches and dents of the stainless steel components; or
damage resulting from any of the following: negligent use or misuse of the product, including exposing the product to chemicals
or cleaning products not approved by Coleman; use or installation contrary to specified instructions and applicable building codes,
including heating the product to temperatures above its rated specifications which can cause considerable warping; disassembly,
including removal of the product from a built-in installation; repair or alteration by anyone other than Coleman or an authorized
service center; acts of God, such as fire, flood, hurricanes and tornadoes; gas cylinders, propane tanks or other fuel delivery
systems, including connections to a household fuel supply; usage other than single-family household use such as commercial or
industrial use; minor warping or discoloration of certain parts, which is normal and not a defect under this warranty.
COLEMAN SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE BREACH
OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT OR OTHERWISE. EXCEPT TO THE EXTENT
PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE IS LIMITED IN DURATION TO THE DURATION OF THE ABOVE WARRANTY. SOME STATES, PROVINCES OR
JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES OR
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
THAT VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
How to Obtain Warranty Service
Take this product to an authorized Coleman service center. You can find the nearest authorized Coleman service center by
calling 1-800-356-3612 or TDD 316-832-8707 in the United States, or 1 800 387-6161 in Canada.
If a service center is not conveniently located, attach a tag to the product that includes your name, address, daytime telephone
number and description of the problem. Include a copy of the original sales receipt. Carefully package the product and send either
by courier or insured mail with shipping and insurance prepaid to:
For products purchased in the United States:
For products purchased in Canada:
Sunbeam Corporation (Canada) Limited
DBA Jarden Consumer Solutions
This warranty does not include transportation or shipping costs. If you ship your product, shipping and insurance must be
DO NOT RETURN THIS PRODUCT TO THE PLACE OF PURCHASE.
If you have any questions regarding this warranty please call 1-800-356-3612 or TDD 316-832-8707.
For Warranty, Service and Parts
Locate your model number and serial number on the
The Coleman Company, Inc. • 3600 N. Hydraulic • Wichita, KS 67219 U.S.A.
1-800-356-3612 • TDD: 316-832-8707
©2006 The Coleman Company, Inc. All rights reserved.
Coleman ® and
32
The Coleman Company, Inc.
3600 North Hydraulic
Wichita, KS, 67219
5975 Falbourne Street
Mississauga, Ontario
Canada L5R 3V8
prepaid.
label on the grill.
are registered trademarks of The Coleman Company, Inc.
Use, Care & Assembly Manual
With Grill Lighting Instructions
Read all instructions and keep in a safe place for future reference.
www.coleman.com
NOTE:
1) AA Battery is included.
2) Propane tank is not included.
3) See your dealer for a Rotisserie Kit
that is purchased separately (the
bracket shown in the photo is
provided with the Rotisserie Kit).
9992-031 (2/23/06)
Gas Barbecue
8300 Series
Model No. 9992-645 (LP Gas)
ASSEMBLER/INSTALLER:
Leave these instructions with the consumer.
CONSUMER/USER:
IMPORTANT
Read this manual carefully before assembling,
using or servicing this grill. Keep this manual for
future reference. If you have questions about
assembly, operation, servicing or repair of this
grill, please call Coleman at 1-800-356-3612 or
TDD: 316-832-8707. In Canada call
1 800 387-6161.
For Outdoor Use Only
®
