Ares RC Crossfire AZSZ2802 Quick Start Manual page 3

5
Plug the wires into the respective
sockets on your receiver noting
that the single-pin connectors
should be attached to the 'signal'
pin, usually reserved for the
yellow, orange or white wire.
6
Secure your receiver to the upper
frame using hook and loop tape
and secure the aerial(s).
7
Note that only end pin receivers
can be secured to the upper
frame due to the proximity of the
body.
8
Install the downlink antenna
noting that the Crossfire should
never be powered ON without the
antenna connected as this can
damage the video transmitter
circuitry.
Full manual available to download from: www.Ares-RC.com
