Appendix
LEDs
The CS-102/CS-122 contains one Power LED, two Ready LEDs, and two Port Select LEDs on its front panel. Their
indications are as follows:
Power LED:
Ready LED:
Port Select LED:
Depending on conditions, the Port Select LED turns on and off according to the following pattern:
1
Port Not Selected
2
Port Connects to a CPU Switch
3
Port Connects to a Computer
4
Port Connects to a Computer Under Previous/Next Mode
5
Port Connects to a Computer Under Scan Mode
DIP Switch Setting
Scan Time is determined by the DIP Switch of the First Stage* CPU Switch. For the second and the third-stage CS-102/122
units, all DIP switches are set to Off.
1
ON
OFF
ON
OFF
* The CPU Switch that the keyboard, monitor, and mouse connect to is the First Stage unit.
Lights when the CPU Switch is running.
Lights when the connected PC or CPU Switch is running.
Lights to indicate the currently selected port.
Condition
DIP Switch Number
2
ON
ON
OFF
OFF
Pattern
Off
Flashes Long Off; Short On
Steady On
Flashes Long On; Short Off
Flashes On and Off Equally
3
X
ON
X
ON
X
ON
X
ON
Scan Time
4
3 Sec.
10 Sec.
20 Sec.
40 Sec.
