S - -S G
TEP BY TEP
Preliminaries
do this:
IMPORTANT!
do this:
do this:
Manual filename: Delius Manual v2.3x.doc
English version
UIDE
This section guides you through setting up the unit for basic operation. You may
find this useful if you have not used the Delius for a while.
The Control Summary sheet details the menu structure and outlines the use of
the front panel controls. For more information, see the Menu section on page
20.
For digital interfaces, use with cables designed for digital audio:
•
for AES/EBU interfaces use 110Ω screened, twisted pair cables fitted with
one male XLR connector and one female XLR connector.
•
for SDIF, Wordclock or SPDIF BNC interfaces, use 75Ω coax cables fitted
with BNC plugs.
•
for SPDIF RCA interfaces, use 75Ω coax cables fitted with RCA Phono
plugs.
•
for TOSLINK optical interfaces, use Toslink fibre-optic cables.
•
for IEEE 1394 interfaces, use the IEEE 1394 cable provided with the unit.
For analogue inputs / outputs, use with screened cables of the correct type:
•
for balanced inputs / outputs, use screened, twisted pair cables fitted with
one male XLR connector and one female XLR connector.
•
for unbalanced inputs / outputs, use coax cables fitted with RCA Phono
plugs.
Connect the power cable supplied to the Power inlet on the Delius rear panel,
plug the other end into a convenient power outlet.
Please do not use an excessively thick power cable as this may damage the
power inlet connector.
Press the button and wait about 30 seconds while Delius configures
Power
itself.
The display will show in sequence: Delius,
If the unit is likely to be set in an unfamiliar state, you can reset it as follows:
Press the button once, then press the
Function
the display shows Factory. Press the
reboots.
The and one of the input indicators will be lit.
PWR, MUTE
Testing ...
Select
Page 10
Manual for Software Issue 2.3x
September 2004
and
No Input.
button repeatedly until
Input
button and wait while the unit
