Yaesu FT1DR Technical Supplement page 4

RA1360400
SPACER (LED)
DS2001
RA1414200
LIGHT SHEET(LCD)
RA1360300
DOUBLE FACE (LCD)
RA1360200
LCD HOLDER
②
③
RA1013800
SHEET (LCD)
RA1037500
③
O RING(6.5X2)
④
④
RA1272300
④
SHEET(CNT)
④
DSP-UNIT
②
RA140600
SUPPORT (M-SD)
③
RA1359900
⑦
COVER (JACK)
③
⑥
③
③
⑥
⑤
③
RF-UNIT
③
RA1012800
PACKING PAD (POW)
FR021610A
CABLE (PCB)
RA060450B
SPECIAL NUT(M)
RA1037500
O RING(6.5X2)
⑩
⑨
⑨
MD0001
P1091472
RA1037400 CONNECTOR SMAJ-VM2
O RING (4.8X1.9)
RA0292100
RA1359400
SHEET(MICROTEX C010)
MASK SHEET
RA1358700
DOUBLE FACE (PAD-R)
RA1403700
PROTECTOR(R)
RA1358400
CAP (SIDE)
RA1358300
LIGHT GUIDE (LED)
RA1229100
RUBBER PACKING(LED)
②
RA1361700
②
ENCODER KNOB ASSY
CNTL-UNIT
②
MICRO-SD-UNIT
RA1410400
DOUBLE FACE(DSP)
M00001
RA1359800
③
HOLDER (MOTOR)
⑦
RA1012700
GASKET
⑧
⑧
CQ0150001
CHASSIS ASSY
w/ PACKING PAD (POW), O RING (4.8X1.9),
CONNECTOR SMAJ-VM2
⑩
RA1359700
CAP (SW)
EXPLODED VIEW-1
RA1357900
WINDOW (YAESU)
RA1358000
DOUBLE FACE(WINDOW)
RA1359100
LIGHT GUIDE (WIN)
RA1358200
SUPPORT (PTT)
RA1392200
DOUBLE FACE(FPC/B)
RA135900B
KEY PAD
RA1229400
GASKET(SP)
SP0001
RA101370C
SP HOLDER
RA1355300
①
MIC HOLDER RUBBER
①
①
①
MC8021
CONNECT-UNIT
RA1358900
SPACER (LCD)
Exploded View & Miscellaneous Parts
RA1359200
MASK SHEET (B-ANT)
AT0001
RA1395700A
DOUBLE FACE(ANT)
RA1358800
DOUBLE FACE (PAD-L)
Removing the Rear Case Assy
1. Please order the screw M2.6X30 (P/N;
RA1403800
PROTECTOR(L)
U00230001).
2. Remove the ENCODER KNOB (A).
RA107300A
3. Remove the two screws (B).
SPACER (PTT)
4. Turn the M2.6x30 screw several times to af-
fix the screw to the bottom right corner.
5. Press the top of the screw toward to a panel
top to remove the CHASSIS Assy from the
front panel.
RA1358100
RUBBER KNOB (PTT)
CQ0151006 (SLVR)
CQ0151007 (BLAC)
FRONT CASE ASSY
REF. YAESU P/N Description
① U9900280 TAPPING SCREW M2X2.5 (3KA)
② U9900243 SCREW M2X3NI
U9900277 PAN HEAD TAPTITE-B M2X3 #3 3KA
③
④ U9900279 TAPPING SCREW M1.4X3 (3KA)
⑤ U07230102 PAN HEAD SCREW M2X3NI #1
U1359600 STUD (B)
⑥
⑦ U1359500 STUD (A)
⑧ U9900278 PAN HEAD TAPTITE-B M2X5 #3 3KA
U07240202 PAN HEAD SCREW M2X4NI#2
⑨
⑩ U9900241 PAN HEAD TAPTITE-B 2X10SUS #3
Non-designated parts are available only as part of a designated assembly.
(B)
(B)
(A)
screw M2.6X30
Qty.
4
5
9
4
1
2
2
2
2
2
FT1DR/DE Technical Supplement
