If installed 4 HDD drives
\ \
Below illustrations are based on the 16-channel model.

Remove screws on the DVR
1.
Pull the cover case forwards to separate it.
2.
Remove screws fixing the bracket to separate it from
3.
the main unit.
Once the bracket is separated, remove screws on
4.
both sides of the HDD drive to be separated and
replaced.
Install the new HDD and fix screws on both sides.
5.
Make sure to install the drive with proper orientation.

s rear and both sides.
'
a
VID EO
IN
b
HD -M
ON ITO
R e-S
AT A
