GUIA DE SOLUCIÓN DE PROBLEMAS
Cualquier otra tarea de mantenimiento debe ser realizada por un representante de mantenimiento autorizado.
Si el electrodoméstico no está funcionando como debería, se ha dejado caer, se ha dañado, se ha dejado a la intemperie, o
ha caído dentro del agua, devuélvalo a un centro de servicio antes de continuar con el uso.
ADVERTENCIA
!
Advertencia: para reducir el riesgo de lesiones personales, desconecte antes de dar servicio.
PROBLEMA
POSIBLE CAUSA
La aspiradora no
1. El cordón eléctrico no está bien
funciona
conectado en la toma de
corriente.
2. Fusible quemado o interruptor
desconectado.
3. Necesita servicio.
La aspiradora no
1. El recipiente de polvo no está
recoge o presenta
instalado correctamente.
bajo ponder de
2. El recipiente de polvo está lleno.
succion
3. Banda rota o desgastada.
4. Filtro tapada.
5. Boquilla/cepillo giratorio tapado.
6. Manguera tapada.
7. Ajuste incorrecto de altura de
alfombra.
Polvo escapando
1. El recipiente de polvo está lleno.
de la aspiradora
2. El recipiente de polvo no está
instalado correctamente.
3. La manguera no está instalada
correctamente.
4. El filtro no está instalado
completamente.
CUALQUIER OTRO SERVICIO DEBE SER REALIZADO POR UN REPRESENTANTE AUTORIZADO DE SERVICIO
SERVICIO AL CLIENTE
En caso de necesitar más ayuda, consulte las Páginas Amarillas para encontrar a un Distribuidor Autorizado Royal
Web en www.dirtdevil.com. Los costos de transporte hacia y desde el sitio de reparación serán pagados por el propietario. Las partes
de repuesto utilizadas en esta unidad son de reemplazo fácil y están disponibles a través de un Distribuidor Autorizado Royal
tiendas. Siempre identifique su aspiradora por medio del número de modelo y el código de fabricación cuando pida información u ordene
partes de repuesto. (El número de modelo aparece en la parte posterior de la aspiradora).
!
SOLUCIÓN POSIBLE
1. Conecte el enchufe firmemente.
2. Revise el fusible o el interruptor en casa.
Reemplace el fusible / reajuste el interruptor.
3. Llame al Servicio al Cliente: 1-800-321-1134.
1. Revise la forma de retiro y reemplazo del
recipiente de polvo.
2. Vacíe el recipiente de polvo.
3. Reemplace la banda.
4. Retire y limpie el filtro.
5. Inspeccione la boquilla/el cepillo giratorio.
Retire la obstrucción/el atasco.
6. Retire la manguera; retire la obstrucción.
7. Ponga el ajuste en el nivel apropiado para la
alfombra que se esté limpiando.
1. Vacíe el recipiente de polvo.
2. Revise la forma de retiro y reemplazo del
recipiente de polvo.
3. Revise la instalación de la manguera.
4. Revise el retiro y reemplazo del filtro.
(1-800-321-1134)
®
o visite nuestro sitio
24
OWNER'S MANUAL
Guide d'utilisation
Manual del usuario
Operating and Servicing Instructions
Notice d'utilisation et d'entretien
Instrucciones de Funcionamiento y
Servicio
Vous trouverez des pièces de rechange d'ORIGINE sur le site www.dirtdevil.com
Encuentre piezas de repuesto GENUINAS en www.dirtdevil.com
This product uses the following parts:
Ce produit comprend les pièces suivantes :
Este producto usa las siguientes piezas:
• Please read these instructions carefully before using your product.
E
• Let us help you put your product together, order parts and accessories or answer
any questions.
• Please Do Not Return This Product To The Store.
• Lire ces instructions attentivement avant d'utiliser ce produit.
F
• Permettez-nous de vous aider à assembler votre produit ou à obtenir des pièces et
des accessoires, ou de répondre à vos questions.
• Ne pas retourner ce produit au magasin.
®
o en otras
• Lea atentamente estas instrucciones antes de usar su producto.
S
• Permítanos ayudarle a armar su producto, encargar piezas y accesorios, o
responder cualquier pregunta.
• Por favor no devuelva este producto a la tienda.
Call us toll-free:
Customer Service
1-800-321-1134
Mon.-Fri. 8:00 a.m.-7:00 p.m. E.S.T.
(USA & Canada)
www.dirtdevil.com
Find GENUINE Replacement Parts at www.dirtdevil.com
BELT STYLE/MODÈLE DE COURROIE
ESTILO DE BANDA
FILTER TYPE/TYPE DE FILTRE
TIPO DE FILTRO
EXHAUST FILTER/FILTRE
D'ÉVACUATION/FILTRO DE ESCAPE
Appelez-nous sans frais au
1 800 321 1134
du lundi au vendredi, de 8 h à 19 h
(HNE).
(É.U. et Canada)
www.dirtdevil.com
©2013 All rights reserved ID108821 # 961151119 R0 12/13
19
F87
F89
Llámenos gratuitamente
al 1 800 321 1134,
de lunes a viernes, de 8 a.m. a 7
p.m. (HNE).
(EE.UU. y Canadá)
www.dirtdevil.com
