Computer-controlled Lockstitch Buttonholing Machine
LBH-1700
The World's First
The World's First
Introducing the World's First Electronic Buttonholing Machine,
marking the beginning of a new era.
● LBH-1700SA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the lbh-1700 and is the answer not in the manual?

Questions and answers

Related Manuals for JUKI lbh-1700

Summary of Contents for JUKI lbh-1700

  • Page 1 Computer-controlled Lockstitch Buttonholing Machine LBH-1700 The World's First The World's First Introducing the World's First Electronic Buttonholing Machine, marking the beginning of a new era. ● LBH-1700SA...
  • Page 2 IMPROVEMENTS OF SEWING PERFORMANCE Needle thread tension controlled by active-tension. (electronic thread-tension-control system) • Needle thread tension for sewing parallel and bartacking sections of buttonholes can be separately controlled through the operation panel and stored in memory according to various sewing conditions (e.g., type of thread, type of material and sewing speed).
  • Page 3 HIGHER FLEXIBILITY Many different buttonhole shapes can be selected on the operation panel. The machine is provided as standard with seven different stitching shapes. • New buttonholing shapes are added. The machine is now able to sew buttonholes with radial tacks and those with larger-pitch tacks to offer handstitch-like appearance.

  • Page 4: Mechanical Parts

    EASY-TO-OPERATE MULTI-FUNCTIONAL OPERATION PANEL All pieces of data on sewing specifications can be established/selected on the operation panel. ●The operation panel permits hand-held manipulation. ●List of major functions of the operation panel Item Function Invokes patterns stored in memory. Pattern No. Moves the needle bar to the far right position Needle threading of its stroke when threading the needle.
  • Page 5 LBH-1700 with an auto-lifter. The auto-lifter allows a single pedal switch to be used not only for moving the work clamp up and down, but also for starting the machine. This makes operation more comfortable by reducing the operator's fatigue. Two types of auto-lifter are available: the magnet-driven (B type) and the air-driven (C type).

  • Page 6: Specifications

    Power consumption 400VA Automatic Lubrication Lubricating oil JUKI New Defrix Oil No.1 (equivalent to ISO VG7) Weight Machine head (include motor) 63kg, Control box 13.5kg WHEN YOU PLACE ORDERS ■ Please note when placing orders, that the model name should be written as follows: LB H -1700S □...
