Daewoo EX236E2BCFA Service Manual page 9

5) Connector Specification
♦ CN3(6PIN/2.0): INVERTER CONNECTOR
NO. SYMBOL
1 12V
2 12V
3 BLO
4 ADJ
5 GND
6 GND
♦ CN17(2x15PIN/2.0): LVDS INTERFACE
NO. SYMBOL
1 VSEL
2 VSEL
3 VSEL
4 GND
5 GND
6 GND
7 RXO0-
8 RXO0+
9 RXO1-
10 RXO1 +
11 RXO2-
12 RXO2+
13 GND
14 GND
15 RXOC-
16 RXOC+
17 RXO3-
18 RXO3+
19 RXE0-
20 RXE0+
21 RXE1-
22 RXE1 +
23 RXE2-
DESCRIPTION
+ 12V DC Power Supply
Back-Light ON/OFF Control for Panel
Brightness Adjustment for Panel
Ground
Power Supply for Panel
Ground
LVDS ODD 0- Signal
LVDS ODD 0+ Signal
LVDS ODD 1- Signal
LVDS ODD 1+ Signal
LVDS ODD 2- Signal
LVDS ODD 2+ Signal
Ground
LVDS ODD Clock- Signal
LVDS ODD Clock+ Signal
LVDS ODD 3- Signal
LVDS ODD 3+ Signal
LVDS EVEN 0- Signal
LVDS EVEN 0+ Signal
LVDS EVEN 1- Signal
LVDS EVEN 1+ Signal
LVDS EVEN 2- Signal
DESCRIPTION
