SY-6BB V1.0
Mainboard

Quick Start Guide

Tested To Comply
FC
C
With FCC Standards
FOR HOME OR OFFICE USE
POST CONSUMER
100%
RECYCLED PAPER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SY-6BB V1.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for SOYO SY-6BB V1.0

  • Page 1: Quick Start Guide

    SY-6BB V1.0 Mainboard Quick Start Guide Tested To Comply With FCC Standards FOR HOME OR OFFICE USE POST CONSUMER 100% RECYCLED PAPER...
  • Page 2 Our customers should ensure that their use of our products does not infringe upon any patents. It is the policy of Soyo Computer Inc. to respect the valid patent rights of third parties and not to infringe upon or assist others to infringe upon such rights.
  • Page 3 SY-6BB V1.0 Quick Start Guide Introduction Congratulations on your purchase of the SY-6BB V1.0 Mainboard. This Quick Start Guide describes the steps for installing and setting up your new mainboard. This guide is designed for all users to provide the basic steps of mainboard setting and operation.
  • Page 4: Key Features

    SY-6BB V1.0 Quick Start Guide SY-6BB V1.0 Mainboard Layout PS/2 Mouse Connector Connector Flash BIOS ITE8671 AT Power ATX Power PRT 1 CPUFAN JP50 COM 1 COM 2 AGP Slot JP44 Slot 1 for PCI Slot #3 Header ® Pentium...
  • Page 5: Installation

    Follow the directions in this section designed to guide you through a quick and correct installation of your new SY-6BB V1.0 Mainboard. For detailed information, please refer to SY-6BB V1.0 Mainboard User's guide and Technical Reference online manual included on the CD-ROM packed with your mainboard.
  • Page 6: Install The Mainboard

    SY-6BB V1.0 Quick Start Guide Install the Mainboard Follow the steps below in order to perform the installation of your new SY-6BB V1.0 Mainboard. Step 1. Install the CPU Record the working frequency of your CPU Mark your CPU Frequency: that should be clearly marked on the CPU cover.
  • Page 7 Switch.), Wake-On-LAN card, VGA card, Sound Card, and other devices. For more details on how to connect internal and external peripherals to your new SY-6BB V1.0 Mainboard, please refer to SY-6BB V1.0 Mainboard User's Guide and Technical Reference online manual on CD-ROM.
  • Page 8: Memory Configuration Table

    SY-6BB V1.0 Quick Start Guide Step 3. Configure Memory Your board comes with three DIMM sockets, providing support for up to 768MB of main memory using DIMM modules from 8MB to 256MB. For 66MHz front side bus CPUs use 12ns or faster memory; for 100MHz front side bus CPUs use 8ns (100MHz, PC100 compliant) memory.
  • Page 9 SY-6BB V1.0 Quick Start Guide Step 5. Set the CPU Frequency You do not need to set any jumper for the CPU frequency. Instead, CPU setting are changed through the BIOS [CHIPSET FEATURES SETUP]. Please refer to Chapter 3 - Quick BIOS ®...
  • Page 10 Select [Save & Exit SETUP] and press <Enter> to save the configuration to the CMOS memory, and continue the boot sequence Note: SOYO does not guarantee system stability if the user over clocks the system. Any malfunctions due to over-clocking are not covered by the warranty.
  • Page 11: Quick Bios Setup

    Move the cursor to the [CPU Speed] field to set the CPU frequency. Available [CPU Speed] settings on your SY-6BB V1.0 Mainboard are detailed in the following table. If you set this field to [Manual], you are then required to fill in the next two consecutive fields: (1) the [CPU Host Clock], and (2) the [CPU Ratio].
  • Page 12 Step 1. Insert the SOYO CD into the CD-ROM drive The SOYO CD will auto-run, and the SOYO CD Start Up Menu will display as shown below. (SOYO CD Start Up Program Menu) The SOYO CD Start Up Program automatically detects which SOYO mainboard you own and displays the corresponding model name.
  • Page 13 However, to display the list of all drivers software available with SOYO mainboards, click the Display all drivers on the SOYO CD button. Please make sure to install only the drivers adapted to your system, or otherwise this cause system malfunctions.
  • Page 14 SY-6BB V1.0 Quick Start Guide The following drivers are available for Windows 95 (Driver Installation Menu) The following drivers are available for Windows 98 (Driver Installation Menu)
  • Page 15 Select which driver you want to install and click OK, or click Cancel to abort the driver installation and return to the main menu. Note: Once you have selected a driver, the system will automatically exit the SOYO CD to begin the driver installation program. When the installation is complete, most drivers require to restart your system before they can become active.
  • Page 16 Fax: 44-(0)181-569 4134 Web Site: http://www.soyo.nl E-mail: sales@soyo.nl Japan Branch Office Soyo Computer (Japan) Tel: 81-3-33682188 Fax: 81-3-33682199 Web Site: http://www.soyo.co.jp E-mail: soyo@po.iijnet.or.jp Hong Kong Branch Office Soyo Hong Kong Ltd. (H.K.) Tel: 852-2710-9810 Fax: 852-2710-9078 Web Site: http://www.soyo.com.hk E-mail: rshu@hkstar.com...
