TCT-35 and TCT-35S
Iced Tea Brewers
Service Manual
Included in this service manual is information on the TCT-35 and TCT-35S.
The information is common to both TCT brewers except where noted.
For 220 volt units, a separate wiring diagram and parts list will be
provided.
1 2
1 2
1 2
1 2
1 2
WILBUR CURTIS CO., INC.
6913 Acco St., Montebello, CA 90640-5403 USA
Phone: 800/421-6150
Technical Service Phone: 800/995-0417 (M-F 5:30A - 4:00P PST) E-Mail: techsupport@wilburcurtis.com
Web Site: www.wilburcurtis.com
FOR THE LATEST SPECIFICATION INFORMATION GO TO WWW.WILBURCURTIS.COM
Fax: 323-837-2410
