VIVOTEK Fixed Dome Series
AM-105 Recessed-mount Bracket
Installation Guide
Corresponding part number: 900026800G
Rev. 1.0
IP Sur veillance
Advertisement
Table of Contents
Related Manuals for Vivotek AM-105
Summary of Contents for Vivotek AM-105
- Page 1 VIVOTEK Fixed Dome Series AM-105 Recessed-mount Bracket Installation Guide Corresponding part number: 900026800G Rev. 1.0 IP Sur veillance...
- Page 2 Compatible VIVOTEK Cameras Fixed Dome series FD8167, FD8138-H You may also refer to VIVOTEK's website for the list of supported models. Support for other models can be available through time. IMPORTANT: Before installing your camera, make sure the built-in PIR (Passive Infrared Sensor) can be directed toward the area of interest, where possible intrusion may occur.
- Page 3 Installation Mounting Hole Definitions 1. Determine a secure location for the recessed-mount bracket. 2. Drill or cut a 190mm hole (in diameter). The maximum thickness of the ceiling/board is 24mm. The ceiling should be able sustain at least a weight of 1.4kg. 190mm Up to 24mm...
- Page 4 4. Use the included stardriver to detach the dome cover from the recessed mount bracket. 5-1. Install camera to the recessed-mount bracket by driving 3 screws.
- Page 5 FD8167 and FD8138-H 5-2. Attach foam washers to the top of 5-3. Install camera to the bracket. screw holes. • 3x round head M4x8L Foam washers NOTE: 1. Connect and route cables before you secure the recessed-mount bracket to a ceiling. 2.
- Page 6 6. Pass cables through the routing hole and connect cables to the camera. 7. Use a #2 Phillips screwdriver to loosen the clamping plates (see drawing below) and insert the recessed-mount bracket through the hole in the ceiling.
- Page 7 8. Use a #2 Phillips screwdriver to move the clamping plates down so that the ceiling/ board is caught between the clamps and the flange on the other side of the ceiling. Clockwise Counter- clockwise 9. Adjust shooting angle and check for a satisfactory image over a web session. When you have a satisifactory live view, tighten the tilt screw, and secure the dome cover from below the ceiling using the T10 stardriver.
- Page 8 10. You are done with the installation.
