Summary of Contents for Vivotek AM-214
- Page 1 VIVOTEK Fixed Dome & PTZ Series Wall-mount Bracket User’s Manual Using AM-214 wall-mount bracket and compatible accessories Rev. 1.1 IP Sur veillance...
- Page 2 FD7131, FD8162, FD8135H, FD8362E, FD8362, FD8372, FD8335H, FD8361, FD8361L, FD8131 PZ7111, PZ7112, PZ7121, PZ7122, PZ7131, PZ7132, PTZ series PZ7151, PZ7152, PZ81x1W, PZ81x1 You may also refer to VIVOTEK's website for the list of supported models. Support for other models can be available through time.
-
Page 3: Installation
Accessories Adaptor ring for FD8162 Installation Mounting Hole Definitions Above are the locations of different groups of mounting holes for matching different cameras: Hole Type Applicable Cameras Screw No. of screws FD8161 / FD7132 / FD7131 M4X15 FD8162 / FD8135H FD8133V / FD8134V M4X8XD6 3 FD8133 / FD8134 / FD8131... - Page 4 Refer to the table below for the description of the included screws: Screw Description Quantity Applies to M4X15 Phillips pan head A holes M3X4 Phillips pan head D holes for PZ (black) and PT series M4X8XD6 Phillips pan B holes head M4X25XD9 Phillips pan Securing the...
- Page 5 Wall Mount Installation - FD8134V Below is a general, sample procedure using a wall mount bracket: 1. Locate the position where you want to install the wall mount bracket and camera. Drill holes on the wall for securing the bracket and for routing the cables. 2.
- Page 6 5. Proceed with initial setup such as enabling network access, focus tuning, or zooming. When done, secure the outer dome cover. NOTE: Use the correct type of screws when installing cameras to the mounting cap. Refer to page 3 for the screw type.
- Page 7 Wall Mount Installation - FD8134 Below is a sample procedure using wall mount bracket and an FD8134: 1. Determine a hard surface wall location, and use the four mounting holes on the wall mount bracket to mark the positions where holes will be drilled to secure the bracket. M3X6 Screws 2.
-
Page 8: Camera Lens Orientation
Wall Mount Installation - FD8162 Below is a sample procedure using wall mount bracket and an FD8162: 1. Determine a hard surface wall location, and use the four mounting holes on the bracket to mark the positions where holes will be drilled to secure the bracket. A* holes M4X15 Camera Lens Orientation... - Page 9 6. Secure the camera to the adaptor ring using the included screws. 7. Connect power lines and cables to the camera. 8. Proceed with initial setup such as enabling network access, focus tuning, or zooming. When done, secure the outer dome cover. Wall Mount Installation - PZ7151 (and Applies to All PZ Series) Below is a general, sample procedure for installing a PZ pr PT series camera with the wall mount bracket:...
- Page 10 2. Secure the camera from the inner side of the mount panel by driving M3 screws to the bottom of camera. 3. Locate the position where you want to install the wall mount bracket. Drill holes on the wall for securing the bracket and for routing cables. 4.
- Page 11 Wall Mount Installation - FD8161 Below is a general, sample procedure using a wall mount bracket with the FD8161 camera: 1. Locate the position where you want to install the wall mount bracket and camera. Drill holes on the wall for securing the bracket and for routing cables. 2.
- Page 12 6. Attach dome cover to the camera.
- Page 13 Wall Mount Installation - FD8362E / 8335H / 8372 Below is a general, sample procedure using a wall mount bracket with the FD8362E, FD8335H, and FD8372 cameras: 1. Locate the position where you want to install the wall mount bracket and camera. Drill holes on the wall for securing the bracket and for routing cables.
- Page 14 This page is intentionally left blank.
- Page 15 This page is intentionally left blank.
