RODEC
TABLE OF CONTENTS
- Specifications
- Installation of the mixer-pre-amplifier
- Pictures on cover
Inputs
Outputs
- THD:
- Tone controls:
- Power source:
- Fuse:
- Power consumption:
- Approbation:
- Dimensions:
- Weight:
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
MODEL Multi source II
SERIAL NUMBER ................................. (on the back of the set)
Please give model and serial number when you request info.
Thank you very much for purchasing the RODEC mixer-pre-amplifier Multi source II.
This mixing panel is a topline-mixing panel, capable of outstanding performance in combination with
high-grade systems.
SAFETY INSTRUCTIONS
1)
Do not expose the set to rain or water. Do not spill liquid or insert (metal) objects inside the
set. Rain, water or liquid such as cosmetics as well as metal, may cause electric shocks,
which can result in fire or shock hazard. If anything gets inside, unplug the power cord.
2)
Frayed cords and broken plugs may cause a fire or shock hazard. Do not damage the power
cord. When removing the power cord from wall outlet, be sure to unplug by holding the plug
attachment and not by pulling the cord.
3)
Do not open the set, there are no serviceable parts inside.
Input sensitivity
Signal/Noise
< 0.02%
Bass +/-12dB @ 80Hz
Middle +/-12dB @ 800Hz
High +/-12dB @ 7.5kHz
Panels are leaving the factory on: 230V / 50Hz-60Hz
on request: 100V-117V / 50Hz-60Hz
OFF=0VA
CE
Front: 482mm x 89mm (19" x 2HE)
3.0kg
Remarks
RIAA correction
Phones 600Ω-2kΩ
ON=22VA
Multi source II
- 2 -
- 2 -
- 3 -
- 3 -
- 4 -
- 5 -
- 22 -
2
