Page 1: Media Converter
10/100BASE-TX to 100BASE-FX Fast Ethernet Media Converter Quick Installation Guide... -
Page 2: Fcc Class A Certification
FCC Class A Certification This equipment has been tested and found to comply with the regulations for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: About Media Converter
Introduction Thank you for choosing the 10/100BASE Fast Ethernet Media Converter, The Converter introduced here provides one channel media conversion between 10/100BASE-TX and 100BASE-FX. About Media Converter The Media Converter is a network technology specified by IEEE 802.3 10BASE-T, IEEE802.3u 100BASE-TX, 100BASE-FX standards. -
Page 4: Product Features
Product Features One-channel media conversion between 10/100BASE-TX and 100BASE-FX Fiber media allows: multi-mode fiber using SC,ST, LC or MT-RJ connector; single-mode fiber using SC connector Auto negotiation of speed and duplex mode on TX port Auto MDI-X on TX port ... -
Page 5: Installation
Installation This chapter gives step-by-step installation instructions for the Converter. Selecting a Site for the Equipment As with any electric device, you should place the equipment where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference. Specifically, the site you select should meet the following requirements: The ambient temperature should be between 32 and 104 degrees Fahrenheit (0 to 40 degrees... -
Page 6: Connecting To Power
Connecting to Power This Converter is a plug-and-play device. Connect the supplied AC to DC power adaptor with a power voltage of 7.5Vdc/1.5Amp to the receptacle on the rear panel of the converter, and then attach the plug into a standard AC outlet with a voltage range from 100 to 260 Vac. -
Page 7: Installing In A Chassis
Installing in a Chassis The Converter can be fit into any of the expansion slots on a special designed chassis. Unscrew and pull out the media converter board First, install the converter onto a carrier supplied with the chassis: Step 1- Unscrew the carrier from the desired expansion slot on the chassis. -
Page 8: Led Indicator
LED Indicator The LED indicators give you instant feedback on status of the converter: LEDs State Indication Power Steady Power on (PWR) Power off 100 Mbps Steady Runs at 100Mbps on TX port (100) Runs at 10Mbps on TX port Steady Connection in full duplex mode (FDX) -
Page 9: Specifications
Specifications Applicable IEEE 802.3 10BASE-T IEEE802.3u 100BASE-TX & 100BASE-FX Standards 1 TX port, 1 FX port Fixed Ports 10/20Mbps for half/full-duplex Speed 100/200Mbps for half/full-duplex Forwarding 148,800pps rate Per Unit- (2 LEDs): Power; Speed( 100 ) LED Indicators Per Port- (2 LEDs): FDX/COL, LINK/ACT 10BASE-T -- Cable 2-pair UTP Cat. -
Page 10: Ordering Information
Ordering Information Please include the following information when ordering: Fiber type: multi-mode or single-mode Fiber connector type: SC,ST, LC or MT-RJ Segment distance range for the fiber port TX port Connector Cabling Segment Distance Type RJ-45 Copper Wire Max. 100 m FX port Connector Cabling...
