- Page 1 Thank you for purchasing one of our products. Please read this manual before using this product. When using this product, always follow the instructions contained in this manual, and pay attention to the safety information.
- Page 2 Do not expose this product to water, rain or moisture. Doing this can result in electric shock or fire. Never take this product apart or try to modify it. Doing so is very dangerous and could result in electric shock. Do not store this product near open flame.
- Page 3 · Can be used with a standard 6-4 telephone phone jack if the internal contact closure is not used The CATS-2 is designed to accept a remote contact closure for each video input. When the desired contacts are closed by a button or relay, the appropriate picture is selected. A master timer is then activated that can be adjusted to guarantee that the picture remains on the screen for the desired hold time.
-
Page 4: Cable Requirements
Cable Requirements: The cable run from the phone plate should not exceed 300 feet and it is recommended that 24 GA wire or larger is used. Do not connect the wires for the alarm to any other piece of equipment or voltage source as you may damage the inputs to the alarm circuitry. If you provide the cable , it must have a reversal in wire. - Page 5 Power Up: When the CATS-2 switcher is first turned on, the unit will go into alarm and remain until the internal timer clears. After connecting the video and the Normally open contact closures to the Alarm input you can adjust timer hold time in the unit. Turning the unit over, there is a small screwdriver adjustment that will vary the timer.
-
Page 6: Key Features
· High Quality Construction · Made in the USA Compu-Video System’s CATS-2 is a high performance 2x1 composite video alarming sequential switcher. The switcher is designed to handle up to two high resolution color video sources and uses an external UL listed power supply to meet today’s safety requirements. - Page 7 P.O. Box 749 Peekskill, NY 10566 Tel: (845) 737-7009 Fax: (845) 737-0426 Web: www.compuvideosystems.com...
- Page 8 NOTES P.O. Box 749 Peekskill, NY 10566 Tel: (845) 737-7009 Fax: (845) 737-0426 Web: www.compuvideosystems.com...
- Page 9 NOTES P.O. Box 749 Peekskill, NY 10566 Tel: (845) 737-7009 Fax: (845) 737-0426 Web: www.compuvideosystems.com...
- Page 10 NOTES P.O. Box 749 Peekskill, NY 10566 Tel: (845) 737-7009 Fax: (845) 737-0426 Web: www.compuvideosystems.com...
-
Page 11: Limited Warranty
Compu-Video Systems Inc. to the user is free of charge. How To Get Service Please contact CVS by phone for return authorization number and then return the defective unit, transportation prepaid and a dated proof of purchase to: Compu-Video Systems Inc.
