- Page 1 CHW-1 & CHS-1 Publication No. ZZ 1336-3 June 2009 SLIM LINE COOKER HOOD HEAT RECOVERY UNITS for use with Installation & Users Instructions R E L I A B I L I T Y Y O U C A N T R U S T...
- Page 2 2.4.1 Determine the location and height of the cooker hood and AW2163 ISSUE 2 CHW-1 mark off the 4 fixing hole positions using the hood as a template. 2.4.2 Drill the 4 x 7.5mm holes and secure the canopy in the required position with the screws provided.
- Page 3 2.8 INSTALLATION WITH AN INTEGRAL LE155/250 & LE155-1/250-1 HEAT RECOVERY UNIT NOTE: Refer to the Installation, Commissioning and Servicing Instructions provided with the heat recovery unit and fit in the predetermined position above the cooker. DO NOT FIT the base plate to the heat recovery unit. This item is to be discarded! 2.8.1 Remove the grille from the cooker hood allowing access to the screw positions on the inside of the unit.
- Page 4 USERS INSTRUCTIONS The cooker hood will not extract unless the heat recovery unit is operating. 4.2 SWITCH 1 ON position Lamp ON MAINTENANCE & CLEANING 5.1 WARNING: Cleaning instructions must be followed to prevent danger of fire! Switch OFF at mains before starting. Cleaning of the cooker hood and inspection of the filter must be carried out at least once per month, but ideally on a weekly basis.
