- Page 1 CHW & CHS Publication No. ZZ 1318-2 October 2008 SLIM LINE COOKER HOOD HEAT RECOVERY UNITS for use with Installation & Users Instructions R E L I A B I L I T Y Y O U C A N T R U S T...
- Page 2 GENERAL DESCRIPTION The Slim Line Cooker Hood is part of a whole house mechanical WARNING ventilation system with heat recovery. You should read these instructions in conjunction with the instructions provided with the Do not flambé whilst LE155 heat recovery unit. using this appliance! 1.2 HOW IT WORKS Warm, humid, stale air from the kitchen is drawn through the cooker...
- Page 3 2.8 INSTALLATION WITH AN INTEGRAL LE155 HEAT RECOVERY UNIT NOTE: Refer to the Installation, Commissioning and Servicing Instructions provided with the heat recovery unit and fit in the predetermined position above the cooker. DO NOT FIT the base plate to the heat recovery unit.
- Page 4 USERS INSTRUCTIONS The cooker canopy will not extract unless the heat recovery unit is operating. 4.2 SWITCH 1 ON position Lamp ON 4.3 SWITCH 2 OFF position Extract Only ON position Heat Recovery ON 4.4 SWITCH 3 On position Boost for maximum power MAINTENANCE &...
