Check safety valve 2
The O-Ring must not be damaged.
ƒ
The O-Ring must be in the groove (right at the bottom)
ƒ
The steel ball must not be stuck. By using finger
ƒ
pressure, check if it moves freely and springs
back.
Check safety valve 3
The seal cap must be fitted and clean.
ƒ
By using finger pressure, check that the blue ball
ƒ
(under the seal cap) is not stuck, moves freely and
springs back.
Check whether the valve in the lid is clean and moves
ƒ
freely.
Check O-Ring under the Visiotherm S
The O-Ring must not be damaged and lie completely
ƒ
below in the groove.
Assembling
Placing sealing ring
Pay attention to the installation position: wavy line below.
ƒ
With the fingers, press all around
