LOCATION OF CONTROLS

6
5
4
3
2
1
1. CASSETTE DOOR
2. STOP BUTTON
3. PLAY BUTTON
4. FAST FORWARD
BUTTON (F.FWD)
5. VOLUME CONTROL
6. DIAL SCALE

POWER SOURCE

This Stereo Cassette Player operates on 2 'AA' (UM-3)
batteries or from an AC adaptor.
Note: Battery and AC adaptor are not included.
A. BATTERY OPERATION
For better performance and longer operating time, we
recommend the use of alkaline-type batteries.
1. Open the BATTERY DOOR by sliding downwards and
hinging upwards.
2. Following the polarity diagram on the back cabinet,
FM 88 91 95 100 104 108 MHz
AM 530 620 750 950 1200 17 0 1 KHz
12
7. EARPHONE JACK
8. FUNCTION SELECTOR
9. DETACHABLE BELT CLIP
10. TUNING CONTROL
11. AM/FM BAND SELECTOR
12. DC JACK
1
7
8
9
10
11
