Stereo usb cassette player with encoding to computer (9 pages)
Summary of Contents for Jensen JSCR-50
Page 2
The serial number of this product is found on its back cabinet. You should note the serial number of this unit in the space provided as a permanent record of your purchase to aid in identification in the event of theft of loss. Model Number: JSCR-50 Serial Number:...
Audio output enables you to listen on your stereo, headphones or other speaker systems. ● Note: You can also use your JSCR-50 as a regular, portable cassette player. Just insert batteries into the slot under where the cassette goes, and you’re ready to listen to your...
2. VOLUME: Adjusts the volume of the headphones and USB connection. 3. HEADPHONE JACK: Connect 1/8” headphones here. 4. USB port: Use the included USB cable to connect the JSCR-50 to your computer in order to transfer audio. Software is provided on the included CD to aid in this process.
Plug in the small end of the included USB cable into the matching USB Port (#4) on the JSCR-50 and the large end of the USB cable into a matching USB port on your computer. USING AN ADAPTOR (NOT INCLUDED) TO POWER THE PLAYER 1.
2. Connecting the USB Cord: Plug in the small end of the USB cable into the matching USB port on the JSCR-50 (#4) and the large end of the USB cable into a matching USB port on your computer. (The rectangular USB Ports and are usually located on the front or back of...
Page 7
(wav, MP3 or wma), bit rate 32 kbps – 320 kbps (128kbps default) and record path (where your files will be saved). On the JSCR-50, you can choose whether or not you would like the tape to loop over to the other side automatically by setting the PLAY MODE (#9) to double arrows or single arrow icon.
Page 8
E. Album and track information can be recorded or changed. 8. Recording: To start recording, you must first press the “Play” button on the JSCR-50 and then immediately click the “Record” button in the CassetteMate software. 9. To stop recording, press the “Stop” button in the software first, and then press the “Stop” on the JSCR-50.
Double-click on it. Q. Why doesn’t the audio wave in the CassetteMate software move? A. The volume dial on the side of the JSCR-50 may be set to minimum. Try turning it to maximum. A. The JSCR-50 may not be plugged in correctly, which will be confirmed if you see the the desktop taskbar found in the lower right corner of your computer.
Page 10
A. The quality of the original tape/sound recording is a key factor in the transfer process. Try lowering the volume control on the side of the JSCR-50 when recording. Try recording with different settings in the Sound and Audio device panel (see above questions for more information).
Page 11
At Spectra, environmental and social responsibility is a core value of our business. We are dedicated to continuous implementation of responsible initiatives with an aim to conserve and maintain the environment through responsible recycling. Please visit us at http://www.spectraintl.com/green.htm for more information on Spectra’s green initiatives or to find a recycler in your area.
Page 12
“Record Path” box to verify the file destination. If you want to change this Record Path, click the icon. 3. Plug the JSCR-50 into the computer USB port using the USB cable provided. Insert a cassette tape into the Cassette compartment. If the icon shows on your desktop and...
