Philips CED750/55 Service Manual

Hide thumbs

Advertisement

Quick Links

CED750
/55/98/51
Exploded View & Parts List
9
3141 785 33263
DB-SL 0950
Version 1.3

Advertisement

loading

  Also See for Philips CED750/55

  Related Manuals for Philips CED750/55

  Summary of Contents for Philips CED750/55

  • Page 1 CED750 /55/98/51 Exploded View & Parts List 3141 785 33263 DB-SL 0950 Version 1.3...
  • Page 3: Specifications

    Specifications General Power supply: 12V DC(11V-16V) negative groud Fuse: Suitable speaker impedance: Maximum power output: 50W×4channels Continous power out: 24W×4channels(4 10% T.H.D.) Pre-Amp output voltage: 2.0V(CD play mode;1kHz,0dB,10k load) Subwoofer output voltage: 2.0V(CD play mode) Aux-in level: 500mV Dimensions(W×H×D): 188×58×193mm Weight: 2.5kg Disc Player...
  • Page 39 12 - 2 12 - 2 SET MECHANICAL EXPLODED VIEW --- BREAKDOWN PART1 _ FRONT PANEL ASSEMBLY...
  • Page 40 12 - 3 12 - 3 SET MECHANICAL EXPLODED VIEW --- BREAKDOWN PART 2 _ SLIDE BRACKET ASSEMBLY...
  • Page 41 12 - 4 12 - 4 SET MECHANICAL EXPLODED VIEW --- BREAKDOWN PART 3 _ MAIN BOARD ASSEMBLY...
  • Page 42 12 - 5 12 - 5 SET MECHANICAL EXPLODED VIEW --- BREAKDOWN PART 4 _ BOTTOM COVER ASSEMBLY...
  • Page 43 12 - 6 12 - 6 SET MECHANICAL EXPLODED VIEW --- BREAKDOWN PART 5 _ TFT SCREEN ASSEMBLY...
  • Page 44 12 - 7 (ONLY FOR /55) MECHANICAL & ACCESSORIES PARTS LIST - OVERALL VIEW 996510020441 MAIN BOARD 996510020508 KEY BOARD MI ASSM 996510020532 SERVO BOARD & DVD DRIVE LCD1 996510020530 LCD BOARD (CLR) FRONT PANEL ASS'Y 996510020394 FFC 50P 0.5MM 996510020529 MIC1 996510020244...
  • Page 45 12 - 8 MECHANICAL PARTS LIST - BOTTOM COVER ASS'Y (ONLY FOR /55) BOT2 996510020392 VM-700 R-TRACK BOT7 996510020388 VM-700 LEFT RACK BOT9 996510020389 VM-700 RIGHT RACK BOT11 996510020393 VM-700 L-TRACK MECHANICAL PARTS LIST - TFT SCREEN ASS'Y TFT1 996510020401 WIDE BUTTON TFT26 996510020415...
  • Page 46 12 - 9 ELECTRICAL PARTS LIST - LCD BOARD ELECTRICAL PARTS LIST - MAIN BOARD 996510020531 BACK LIGHT BH-H102SW 996510020452 REC DIODE CON2 996510020488 FFC SOCKET 8P 996510020452 REC DIODE 996510020518 TACT SW 996510020452 REC DIODE 996510020518 TACT SW 996510020452 REC DIODE 996510020518 TACT SW...
  • Page 47 12 - 10 ELECTRICAL PARTS LIST - MAIN BOARD ELECTRICAL PARTS LIST - MAIN BOARD Q120 996510020493 TR KN12907A(PNP) SOT-23 996510020472 IC 74HCT4052DB SSOP16 Q121 996510020493 TR KN12907A(PNP) SOT-23 996510020473 IC 74HC00 SOP14 Q122 996510019571 TRANSISTOR 2N3904(NPN) 996510019713 IC UTC4558 SOP-8 Q123 996510020461 TR KRA304 USM...
  • Page 48 IC BA7071 SOP8 ROHM D2006 996510020503 SW DIODE U2002 996510020475 IC 78L05L SOT-89 UTC D2007 996510020452 REC DIODE U2003 996510020522 IC 74HC4538PW PHILIPS D2008 996510020517 ZENER DIODE U2005 996510019701 IC NJM3414AM SOP-8 D2009 D2009 996510020503 996510020503 SW DIODE SW DIODE...
  • Page 49 13 - 1 ONLY FOR CED750/51 & /98 MECHANICAL & ACCESSORIES PARTS LIST - OVERALL VIEW 996510031149 MAIN BOARD ASSM 996510020508 KEY BOARD ASSM 996510031159 SERVO BOARD & DVD DRIVE /51 LCD1 996510027828 LCD MI ASSM 996510024015 SERVO BOARD & DVD DRIVE /98 996510020394 FPC MB TO LOADER 50P (CLR)
  • Page 50 13 - 2 ELECTRICAL PARTS LIST - USB/SD/AUX BOARD CON1 996510020499 SOCKET 4P 2.0mm USB2.0 996510020500 SOCKET EARPHONE CON3 996510020502 FFC SOCKET 24P CON4 996510019625 12P 2.5MM SD/MMC SOCKET ELECTRICAL PARTS LIST - MOTOR DRIVE BOARD CN4001 996510020506 FFC SOCKET 12P 996510020500 SOCKET EARPHONE D4000...
  • Page 51 13 - 3 ELECTRICAL PARTS LIST - MAIN BOARD 996510020503 DIODE 1N4148 200mW 300mA /51 Q107 996510020464 TR KTC4375Y SOT-89 KEC 996510020452 DIODE 1N4004 3A 1V 400V /98 996510020462 TR KRC402 USM D101 996510020456 REC DIODE 1SR154 1A 400V Q110 996510020461 TR KRA304 USM D104...
  • Page 52 DIODE 1N4148 200mW 300mA U2002 996510020475 IC 78L05L SOT-89 UTC D2006 996510020503 DIODE 1N4148 200mW 300mA U2003 996510020522 IC 74HC4538PW PHILIPS D2007 996510020452 REC DIODE 1N4004 3A 1V 400V U2005 996510019701 IC NJM3414AM SOP-8 D2008 996510020517 ZENER DIODE 11V 300mW...
  • Page 53 13-1 REVISION LIST 1.0 Manual 3141 785 33260 Initial Service Manual released. 1.1 Manual 3141 785 33621 In this version, version /94 added. In Chapter 12, Mechanical & Electrical Parts List updated. 1.2 Manual 3141 785 33622 In this version, version /98 added. In Chapter 12, Mechanical &...
