Philips CED750/55 Quick Start Manual

Register your product and get support at
ENG Quick Start Guide
3
4
CED750
1
1
2
3
4
5
6
7
8
9
0
!
English
Connect wires: ISO connectors
1
Pull out the ISO connectors from the car
dashboard and connect them to the bigger
end of the supplied standard connector.
2
Connect the other end of supplied standard
connector to the unit.
• If necessary, connect the following:
Connector Connect to/with
1 Black cable Antenna
2 Yellow cable Video out 1
3 Yellow cable Video out 2
4 Yellow cable Camera in
5 Green/white Parking
wire
6
Black cable Bluetooth microphone
7 Blue cable Subwoofer
8 Red cable Front line out L
9
White cable Front line out R
0 Red cable Rear line out L
! white cable Rear line out R
Mount in the dashboard
Note
• Check wire connection before you mount
the unit into a car.
• If preset radio stations are lost when the
ignition key is turned OFF and then back
ON, reconnect the red leads crosswise to
the yellow ones.
1
If the car does not have an on-board drive or
navigation computer, disconnect the negative
terminal of the car battery.
• If you disconnect the car battery in
a car that has an on-board drive or
2
navigation computer, the computer may Set clock
lost its memory.
1
• If the car battery is not disconnected,
2
to avoid short-circuit, ensure that bare
wires do not touch each other.
2
Ensure that car dashboard opening is within 3
these measurements:
4
• Since the unit cannot be used if the
dashboard opening's slant angle is above
20 degrees: Ensure that the horizontal
slant of the car dashboard opening is
5
between 0 and 20 degrees
6
3
Remove the screws on the both side of the
unit. 7
4
Remove the mounting sleeve.
8
5
Install the sleeve into the dashboard and
bend the tabs outward to fi x the sleeve.
6
Place the rubber cushion over the end of the
Tune to a radio station
bolt.
7
Slide the unit into the dashboard until a click
1
sound is heard.
2
• If the unit cannot fi t into the dashboard,
remove the mounting bracket on the
both side of the unit and replace them
3
with the supplied short mounting
brackets.
8
Attach the trim plate.
9 4
Reconnect the negative terminal of the car
battery.
Play discs
Turn on
1
1
Press the to turn on the unit.
The screen opens automatically.
»
The available OSD (On-Screen Display)
»
languages are displayed.
2
Touch a language to select.
The OSD language is changed to the
»
selected language immediately.
• To adjust the screen tilt, press TILT .
• To close the screen, press OPEN/CLOSE .
• To adjust the brightness/contrast, press / , Insert USB or SD/MMC card
then adjust 4 WAY NAVIGATION .
• To turn off the system, press for 3 sec-
1
onds.
The screen closes automatically.
»
2
Insert the USB device or SD/MMC card into
the USB socket or SD/MMC card slot.
Touch to display main menu.
Play starts automatically.
»
Touch [Setting].
The setup menu is displayed.
»
Pair the Bluetooth-enabled
Touch [General].
devices
Touch the [Clock mode] repeatedly to
select:
1
Turn on the Bluetooth function on the
• [12hr] : 12 hour mode
device.
• [24hr] : 24 hour mode
2
Setup the Bluetooth function on your device.
Touch the hour digits, then touch or .
3
Select "CED750" in the pairing list.
Touch the minute digits, then touch or .
4
Enter default password "0000".
If 12 hour mode is selected, touch or
iI pairing succeeds. [Connect] is displayed
to select AM or PM . »
on the panel.
Touch to exit.
Make a call
1
Pair the phone with the system.
Touch to display the main menu.
2
Touch
Touch [Radio].
3
Touch [Bluetooth].
Band and frequency infor mation is
»
The Bluetooth menu is displayed.
displayed. »
4
Touch to dial.
Touch [Band] repeatedly to select:
• FM band options: FM1, FM2, FM3
• AM band options: AM1, AM2
Receive call
Briefl y touch [Previous] or [Next] to tune
to a radio station by step.
1
If there is incoming call, [Incoming call...]
fl ashes on the screen. Speak into the Blue-
tooth microphone.
2
When conversation ends, touch
Insert the disc into the disc slot with label
terminate the call.
side facing up.
Play starts automatically.
»
To remove the disc, press the button.
»
When the disc is ejected, the unit switches
»
to the previous source, if connected. Other-
wise, the unit switches to [Radio] mode auto-
matically.
© 2008 Koninklijke Philips Electronics N.V.
Open the USB/SD/MMC card cover.
to return to main menu.
to
All rights reserved.
