About this document
This Quick Reference Guide summarizes the operation of your
A-series display. This guide assumes that the display has been
installed and set up in accordance with the procedures in the installa-
tion guide and that you have read the User reference manual on the
accompanying CD-ROM.
Safety
WARNING: Read the user manual
Before using the software read the safety information
contained within the user reference manual on the
accompanying CD-ROM.
WARNING: Navigation aid
This product is intended to serve only as an aid to
navigation. Use of specific features such as AIS
overlay, and various cartographic aids are meant
only to aid safety and decision-making. These
features cannot be relied upon as complete or
accurate as their use and availability may vary
locally. It is your responsibility to use caution,
sound judgement, official government charts,
notices to mariners and proper navigational skill
when using this or any other electronic device.
Powering the display ON/OFF
To Power ON:
Press and hold the POWER key until the screen shows
the Raymarine logo. The unit starts up in the last used dis-
play configuration.
To Power OFF:
Press and hold the POWER key until the power down
countdown reaches zero. The unit is powered OFF.
Releasing the POWER key before the countdown is com-
plete cancels the power off sequence.
Simulator
Your A-Series display includes a simulator mode that enables you to
practice operating the unit without data from a GPS antenna or trans-
ducer unit.
Note: The simulator will NOT display any real-data, including any
safety messages (e.g. those received from AIS).
To turn the simulator ON or OFF:
1. Press and hold the PAGE/MENU key to display the setup menu.
2. Use the trackpad up / down keys to select System Setup.
3. Press trackpad right to select the System Setup options.
4. Select the Simulator option
5. Select ON or OFF as required.
6. Press the OK key to return back through the menus.
A-Series Displays
Quick Reference guide
