Alarms

Alarm system

The system continuously checks for dangerous situations and
system faults while the system is running. When an alarm situation
occurs, an alarm message pops up on the screen.
If you have enabled the siren, the alarm message is followed by an
audible alarm, and the switch for external alarm becomes active.
The alarm is recorded in the alarm listing so that you can see the
details and take the appropriate corrective action.

Type of messages

The messages are classified according to how the reported situation
affects your vessel. The following color codes are used:
Color
Red
Orange
Yellow
Blue
Green

Single alarms

A single alarm is displayed with the name of the alarm as the title,
and with details for the alarm.

Multiple alarms

If more than one alarm is activated simultaneously, then the alarm
message displays a list of up to 3 alarms. The alarms are listed in the
order they occur with the alarm activated first at the top. The
remaining alarms are available in the Alarms dialog.
Alarms | ELITE Ti Operator Manual
Importance
Critical
Important
Standard
Warning
Light warning
