SERVICE
THIS SUPPLEMENT CONTAINS EXPLODED VIEW AND PARTS LIST FOR MODEL MR5483G/MR5484W. FOR
MORE SERVICING INFORMATION, PLEASE CONSULT THE PREVIOUS SERVICE MANUAL FOR
MR5481G/MR5482W WHICH WAS DISTRIBUTED IN APRIL 1998.
MICROWAVE OVEN
SEA
MICROWAVE OVEN
MR5483G / MR5484W
1. Precaution
2. Control Panel
3. Exploded View & Parts List
4. P.C.B Diagram
5. Schematic Diagrams
TIMER
POWER SOURCE
One Minute +
Popcorn
Diet Cook
Frozen
Potato
Dinner
Fresh
Frozen
Vegetable
Breakfast
Auto
Auto
Defrost
Reheat
POWER CONSUMPTION
1
2
3
4
5
6
7
8
9
0
Power Level
More/Less
Clock
Hold
OUTPUT POWER
Auto Start
Timer
Pause
Start
Cancel
OPERATING FREQUENCY
MAGNETRON
COOLING METHOD
OUTSIDE DIMENSIONS
Manual
Supplement
CONTENTS
Specifications
99 MINUTES 99 SECONDS
120V/60Hz, AC
MICROWAVE : 1,300W
90W/900W
(IEC-705 TEST PROCEDURE)
2,450MHz
OM75PH(31)ESS
COOLING FAN MOTOR
20
11/32
(W) x 11
11/32
(H) x 14
5/8
(D)
Advertisement
Table of Contents
Related Manuals for Samsung MR5484W
Summary of Contents for Samsung MR5484W
-
Page 1: Microwave Oven
MICROWAVE OVEN MR5483G / MR5484W SERVICE Manual Supplement THIS SUPPLEMENT CONTAINS EXPLODED VIEW AND PARTS LIST FOR MODEL MR5483G/MR5484W. FOR MORE SERVICING INFORMATION, PLEASE CONSULT THE PREVIOUS SERVICE MANUAL FOR MR5481G/MR5482W WHICH WAS DISTRIBUTED IN APRIL 1998. MICROWAVE OVEN CONTENTS 1. - Page 2 CENTRAL SERVICE CENTER 16. Always connect a test instrument's ground lead to the instrument chassis ground before connecting the positive lead; always remove the instrument's ground lead last. 10. Service technicians should remove their watches while repairing an MWO. Samsung Electronics...
- Page 3 (Use a screwdriver.) 3. High voltage is maintained within specified limits by close-tolerance, safety-related components and adjustments. If the high voltage exceeds the specified limits, check each of the special components. Fig. 1-1. Discharging the High Voltage Capacitor Samsung Electronics...
-
Page 4: Control Panel
1. One Minute + Button 7. Pause Canel Button 2. Auto Defrost Button 8. Start Button 3. Power Level Selection Button 9. Instant Cook Buttons 4. Clock/Auto Start Button 10. Auto Reheat Button 5. Hold/Timer Button 11.Number Key Buttons 6. More/Less Button Samsung Electronics... -
Page 5: Exploded Views And Parts List
3. Exploded Views and Parts List 3-1 Exploded Views Samsung Electronics... -
Page 6: Main Parts List
MOTOR-DRIVE;M2HJ49ZR02,ST-16 21V 5/6 M 22 DE71-60011A COVER-MGT;PP T2.0 WHT M745 M 23 ASSY CONTROL-BOX;120V60Hz MR5483G/XAA D/GRY MR5483G M 23 ASSY CONTROL-BOX;120V60Hz MR5484W/XAA WHT MR5484W M 24 ASSY DOOR;TOUCH GRAY MW5471G MR5483G M 24 ASSY DOOR;TOUCH WHT MW5470W 800W MR5484W M 25 DE61-80003A HINGE-LOWER;SCP1 T2.3 26 77 ZPC3 WHT CHR... -
Page 7: Door Parts List
DE66-20010A BUTTON-PUSH;ABS (VH-080) WHT 17.6G MW4370W MR5484W DE61-70076A SPRING-BUTTON;HSWR PI0.6 DE34-10217Y SWITCH-MEMBRANE;PET W91.5 L174.5 MR5483G 120V MR5483G DE34-10217Z SWITCH-MEMBRANE;PET W91.5 L174.5 MR5484W 120V MR5484W DE72-70161B CONTROL-PANEL;ABS(HR0370U) GRY MW5471G MR5483G DE72-70161A CONTROL-PANEL;ABS(VH-0800) PURE-WHT MW5470W MR5484W DE67-40003A WINDOW-DISPLAY;ACRYL T2.3 W36.8 L91.8 SM DE91-10368A ASSY P.C.B-MAIN;120V/60HZ NS V.F.D N/HEL... -
Page 8: Standard Parts List
DE60-10113A SCREW-TAP PH;2S-4X12 FE ZPC3 FUSE-H DE60-10188A SCREW-ASSY TAP;2S-4X8 MSW3ZPC YEL WS B/HVC 3-7 Installation Parts List Ref. No. Parts No. Description/Specification Q'ty Remarks DE70-40311A PLATE-BOTTOM;SGCC T0.6 W253 L264.5 MR5481 DE72-50092A DUCT-AIR;SGCC T0.6 W150 L212 MR5481G TRIMMER-LOWER TRIMMER-UPPER Samsung Electronics... - Page 9 4. P.C.B Diagrams 4-1 P.C.B Diagrams Samsung Electronics...
- Page 10 IC-MCU;MB89143AP-168 8K DIP 64PIN IC01 DE13-20009A IC;KA7533 DIP IC02 DE26-20144A TRANS-L.V;DN-5574W,CE-5574W 120V 60HZ AC LVT1 DE30-20016A BUZZER;CBE2220BA STICK BUZ1 DE39-60001A WIRE-SO COPPER;PI0.6 SN T 52MM J01~25 DE60-60012A PIN-EYELET;ID2.1 OD2.5 L3.0 SN BSP T0.25 DE61-90164A HOLDER-DIGITRON;NYLON#66 T1.8 BLK MW4370 Samsung Electronics...
-
Page 11: Schematic Diagrams
: P.C.B IN/OUT POINT ORG : ORANGE SECONDARY PRIMARY (CON1) INTERLOCK DOOR GRN : GREEN INTERLOCK INTERLOCK MONITOR SENSING RED : RED SWITCH SWITCH SWITCH SWITCH MAGNETRON HIGH VOLTAGE DIODE TO CHASSIS HIGH VOLTAGE CAPACITOR HIGH VOLTAGE TRANSFORMER Samsung Electronics...
