CC nn CalIon carry
if c= 1
(SP - n<=PCH
(SP - 2) <=PCL
PC<=nn
CALL C,a16
Push the program counter onto the stack and load the program counter
with the 16-bit address in byte 2 and byte 3 if the Carry flag is set.
low-order addr
high-order addr
cycles:
3/5
states: 10/17
flags: none
CPO nn CalIon parity odd
if P/V=O
(SP -
1)
< = PCH
(SP - 2)<=PCL
PC<=nn
o
DC
CALL PO,a16
Push the program counter onto the stack and load the program counter
with the 16-bit address in byte 2 and byte 3 if the Parity/Overflow flag
is reset.
1
low-order addr
high-order addr
cycles: 3/5 states: 10/17
flags: none
o
E4
100-0123-001
2-96
