Splawn 4 Button Footswitch Operation; Splawn 3 Button Single Channel Amp Footswitch - Splawn Amplification QUICK ROD Owner's Manual

Footswitch connections - Two 1/4" TRS plugs marked A and B with a 5 pin din connector at the box end on a 25' cable
Clean/Overdrive
Available with the Quick Rod, Pro Mod, Nitro, Street Rod (optional),
1. Clean/Overdrive Switch
2. Mode Switch
3. Overdrive 1/Overdrive 2 Switch
4. Solo Boost Switch - LED on indicates Solo Volume Boost control activated
Mode
1. Mode Switch
2. Overdrive 1/Overdrive 2 Switch
3. Solo Boost Switch - LED on indicates Solo Volume Boost control activated
Mode

Splawn 4 Button Footswitch Operation

and Super Sport (optional)
Overdrive 1/ Overdrive 2

Splawn 3 Button Single Channel Amp Footswitch

Available with the Competition, Pro Stock, and Super Comp
Overdrive 1/ Overdrive 2 Solo Boost
Solo Boost
