- Page 1 TREET Owners Manual...
- Page 2 1st Gear Splawn TREET OD by Street Rod Front Panel Controls Overdrive Channel 1. Power Switch - Switches AC power on or off 2. Standby Switch - Switches the high voltage on or off 3. Presence Control - High frequency control on the output section 4.
- Page 3 RETURN SEND 2A 220/240V Street Rod Rear Panel Controls 1. Footswitch A - TRS 1/4" Jack: Tip switches Solo Volume -- Ring switches OD1/OD2 2. Footswitch B - TRS 1/4" Jack: Tip switches Clean/Overdrive -- Ring switches Mode Switch 3. Loop Master - Master volume control for the effects loop (When using the loop master do not run the channel volumes over 12 o'clock) 4.
- Page 4 Clean/Overdrive Overdrive 1/ Overdrive 2 Solo Boost Mode Splawn 4 Button Footswitch Operation Available with the Quick Rod, Pro Mod, Nitro, Street Rod (optional), and Super Sport (optional) 1. Clean/Overdrive Switch 2. Mode Switch 3. Overdrive 1/Overdrive 2 Switch 4. Solo Boost Switch - LED on indicates Solo Volume Boost control activated...
- Page 5 Solo Boost Clean/Overdrive Splawn Standard/C lassic 3 B utton F ootswitch Available with Street Rod 2. Overdrive 1/Overdrive 2 Switch 3. Solo Boost Switch - LED on indicates Solo Volume Boost control activated O D 1 / O D 2...
- Page 6 Small Box Head - 25.5“ Wide x 10” Tall x 8.5“ Deep, 50lbs Street Rod Head Box - 25.5” Wide x 10” Tall x 11” Deep, 45lbs Super Sport Mini Head Box - 20.375“ Wide x 10” Tall x 8“ Deep, 35lbs Street Rod Combo - 25.5”...
