Summary of Contents for Splawn Amplification QUICK ROD
- Page 1 UICK OD & Owners Manual...
- Page 2 12. Treble Channel - Controls the treble frequency on the clean channel 13. Volume Control - Controls the overall volume of the clean channel 14. Gain Control - Controls the amount of pre-amp gain to the clean channel Splawn Amplification 115 South Gaston St. Dallas, NC 28034 704-922-0020...
- Page 3 3. Pre-amp tube - 12AX7b Side A 3rd gain stage of OD channel -- Side B 4th gain stage of OD channel 4. Pre-amp tube - 12AX7b Phase inverter Power Tubes 5. Power tube - EL34B (Quick Rod) -- KT88 6. Power tube - EL34B (Quick Rod) -- KT88 7. Power tube - EL34B (Quick Rod) -- KT88...
- Page 4 Clean/Overdrive Overdrive 1/ Overdrive 2 Solo Boost Mode Splawn 4 Button Footswitch Operation Available with the Quick Rod, Pro Mod, Nitro, Street Rod (optional), and Super Sport (optional) 1. Clean/Overdrive Switch 2. Mode Switch 3. Overdrive 1/Overdrive 2 Switch 4. Solo Boost Switch - LED on indicates Solo Volume Boost control activated...
- Page 5 Overdrive 1/ Overdrive 2 Solo Boost Clean/Overdrive Splawn Standard/C lassic 3 B utton F ootswitch Available with Street Rod 2. Overdrive 1/Overdrive 2 Switch 3. Solo Boost Switch - LED on indicates Solo Volume Boost control activated O D 1 / O D 2 Clean/Overdrive Mode Splawn Super Sport 3 Button Footswitch...
- Page 6 For instance if your serial number is QR109996 this would be a Quick Rod 100 watt built in 2009 and was the 996 amp built. *WARNING* Please check that the proper fuse is being used for your voltage, especially if traveling internationally! Please check the "on"...
