  • Page 1 Version-E150528 Manual...

  • Page 2: Important Information

    Important Information General Before using your ALGE-TIMING device read the complete manual carefully. It is part of the device and contains important information about installation, safety and its intended use. This manual cannot cov- er all conceivable applications. For further information or in case of problems that are mentioned not at all or not sufficiently detailed, please contact your ALGE-TIMING representative.

  • Page 3: Declaration Of Conformity

    Manual Speaker System BANG Declaration of Conformity We hereby declare that the following product complies with the below stated standards. All components used by us are CE certified by their producer and are not modified by ALGE- TIMING GmbH. ALGE-TIMING GmbH...

  • Page 4: Table Of Contents

    Headset Micro for BANG ......................... 7 2.4.4 BANG SPK ............................7 Commissioning ......................8 Operation ........................9 Multifrequency Receiving Unit for Headset Micro BANG-HS ......... 9 Power Supply ......................10 Mains ........................10 Rechargeable Battery ..................10 5.2.1 Battery Operating Time ........................10 5.2.2...

  • Page 5: Operating Elements And Connections

    Manual Speaker System BANG 1 Operating Elements and Connections 1 ..UHF-PLL radio receiver for Headset micro BANG-HS 2 ..Connections for timing 3 ..On-off switch 4 ..Amplifier controller und amplifier connections 5 ..Mains (90 - 230 V~ / 47 – 63 Hz) 6 ..

  • Page 6: General

    TREBLE (7) and BASS (8). Note: The BANG is not provided with a volume control for the unit at the input LINE IN (10); i.e. the signal of the unit is always fed to the output LINE OUT at its input volume.

  • Page 7: Connections For Timing

    The passive speaker BANG SPK can be connected at the BANG (it is possible to connect a maximum of eight BANG SPK). It consists of a passive horn speaker with an output line of about 10 W. It has a fixed cable of 12 m (connection at BANG or BANG SPK and a speaker jack (RCA)) to connect additional BANG SPK.

  • Page 8: Commissioning

    Therefore, always observe the notes in the chapter 5. Power Supply. The BANG can be integrated with different devices from ALGE-TIMING as a start system: • Electronic start gun e-Start •...

  • Page 9: Operation

    Manual Speaker System BANG 4 Operation • Advance the control MASTER (6) for the master volume to such an extent that the sub- sequent adjustments can be heard well via the speakers. • Switch on the desired signal sources and mix their signals with the corresponding vol-...

  • Page 10: Power Supply

    Manual Speaker System BANG 5 Power Supply The BANG can be use connected to the mains or running on the internal rechargeable bat- teries. 5.1 Mains To operate the active speaker system via a mains socket and/or to recharge the internal lead gel batteries, connect the mains cable provided to the mains jack (5) and to a mains socket (90 - 230 V~ / 47 –...

  • Page 11: Functions

    Speaker System BANG 6 Functions If you receive a start impulse at the BANG from a device that is connected to one of the two identical LTW-jacks (14) or to the DIN jack (15) you get a start sound output.

  • Page 12: Start Unit Su2 Or Su3

    The Start Unit SU2 or SU3 can be connected at one of the two LTW jacks (14) with cable 199-xx. With the built-in microphone of the start unit you can give oral commands to the ath- letes through the BANG. Further, you can connect a headset to communicate with the timing operator.

  • Page 13: Technical Specifications

    2 ..status 3 ..ground 4 ..power supply output (+10 VDC out) 5 ..empty 6 ..empty 7.3 Radio Receiver for Headset Micro BANG-HS Receiving Unit: PLL- multifrequency receiver in diversity technique Range: ca. 30 m Radio Frequency: 863.1 –...
  • Page 14 When the screws are removed, you can pull out the unit. Now you can change the setting with the red jumper: After finishing the setting plug the unit in the Bang again. After that you have to fix the screws again.
  • Page 15 Manual Speaker System BANG Page 15...
  • Page 16 Manual Speaker System BANG Subject to changes Copyright by ALGE-TIMING GmbH Rotkreuzstr. 39 6890 Lustenau / Austria www.alge-timing.com Page 16...
