ASSEMBL Y INSTRUCTIONS
12
Ce3
-
Ce1
electronic ignition assembly
The electrode sets for main burner (CF), side burner (DF) and
instastart buttons (CE3) are found under the control panel, attached
to the manifold (CA). Insert them into the electronic ignition (CE1).
(CE3)
InstaStart
Button
Ce1
Ce2
+
Ce2
22
Ce1
Side
Burner
Main
Burner
