PANEL DESCRIPTION

■ Programmable function keys

For the Non-display type transceivers, the following functions
can be assigned to [Emer], [Upper], and [Lower].
For the Simple type transceivers and the 10-key type trans-
ceivers, the following functions can be assigned to [P0], [P1],
[P2], [P3], [Emer], [Up], and [Down].
Consult your Icom dealer or system operator for details con-
cerning your transceiver's programming.
CH UP/DOWN
As described in the following topics, after pushing a pro-
➥
grammed key, push [CH Up] or [CH Down] to select an
option, setting, and so on.
ZONE
// only for the Simple type and 10-key type transceivers //
Push this key, then select the desired zone by pushing
➥
Up] or [CH Down].
What is a "zone"?— Certain channels are grouped to-
gether and assigned to a zone, according to their intend-
ed use. For example, 'Staff A' and 'Staff B' are assigned
to a "Business" zone, and 'John' and 'Cindy' are assigned
to a "Private" zone.
5
SCAN START/STOP
< for the Non-display type transceivers >
Push to start and cancel a scan.
➥
• When a scan is started with the Power ON Scan or Auto-
matic scan function, push this key to cancel it. The can-
celled scan resumes after a set time period.
< for the Simple type and 10-key type transceivers >
Push to start and cancel a scan.
➥
➥ To select the scan group, hold down this key to display
scan groups, then push [CH Up] or [CH Down] to select
a desired group.
SCAN ADD/DEL (TAG)
// only for the Simple type and 10-key type transceivers //
Push to add the operating channel to, or delete it from, the
➥
scan group.
1. Hold down to display the scan group, then push [CH
Up] or [CH Down] to select the desired one.
[CH
2. Push to add the channel to, or delete it from, the select-
ed scan group.
3. Hold down to exit the scan list selection mode.
While a scan is paused on a non-priority channel, push this
➥
key to delete the selected channel from the scan group.
Depending on the presetting, the cleared channel may
be automatically added to the scan group again after
the scan is cancelled.
