Page 1: Vacuum Cleaner
SU10F70 SERIES Vacuum Cleaner user manual ✻ Please read the User Manual thoroughly before operating the vacuum. English ✻ For indoor use only. Thank you for purchasing a Samsung product. -
Page 2: Table Of Contents
Contents YOUR VACUUM CLEANER 07 Product view 08 Carton contents BEFORE USING THE VACUUM 09 Assemble the handy vacuum, pipe, and 2 in 1 accessory CLEANER 10 Using the accessories OPERATING CLEANER 11 Stowing the power cord 12 Operating the On / Off switch 13 Operating the Brush bar On / Off switch 13 Resetting the overload protector 14 Using the vacuum's handle... - Page 3 Safety information SAFETY INFORMATION Before operating the appliance, please read this manual thoroughly and retain it for your reference. WARNING Because the following operating instructions cover various models, the characteristics of your vacuum cleaner may differ slightly from those described in WARNING this manual.
-
Page 4: Important Safety Instructions
Safety information IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, you should always follow these basic precautions: READ ALL INSTRUCTIONS BEFORE USING YOUR UPRIGHT VACCUM WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY: 1. Do not leave the vacuum cleaner unattended when it is plugged in. - Page 5 9. Do not put any object into openings or vents. Do not use with any opening blocked. Keep free of dust, lint, hair, and anything that may reduce air flow. 10. Keep hair, loose clothing, fingers, and all parts of your body away from openings and moving parts.
- Page 6 26. If the power cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person. 27. Hold plug when rewinding onto cord reel. Do not allow plug to whip when rewinding. 28. Do not pick up hard or sharp objects such as glass, nails, screws, coins, etc.
-
Page 7: Your Vacuum Cleaner
Your vacuum cleaner PRODUCT VIEW Handle Power On/Off Dust Bin (Handy) Button Handy Release Dust Bin Release Button Button Upper Cord Brush bar Hanger Carrying Handle On/Off (Dust Bin Handle) Button Pipe Dust Bin Lower Cord Hanger Brush bar Do not plug in your vacuum cleaner until you are familiar with all instructions and operating procedures. -
Page 8: Carton Contents
CARTON CONTENTS ( 1 ) ( 2 ) ( 3 ) ( 4 ) ( 5 ) ( 6 ) ( 5 ) ( 6 ) • Empty carton. Find the parts shown above before disposing of packing materials. 1. Vacuum cleaner body 2. Handy Vacuum cleaner 3. Pipe 4. 2 In 1 Accessory 5. Eco Hard Floor(Optional depending on the model) 6. -
Page 9: Before Using The Vacuum Cleaner
Before using the vacuum cleaner ASSEMBLE THE HANDY VACUUM, PIPE, AND 2 IN 1 ACCESSORY Click Click • Connect the Handy Vacuum cleaner and • Connect the 2 In 1 Accessory and the pipe. pipe. Click • When inserting the handle (the handy vacuum cleaner) into the top of vacuum body, put in the hole of the lower cord hanger after pull back the dusting brush. -
Page 10: Using The Accessories
• Wind the cord around the cord hangers and secure with clip. USING THE ACCESSORIES • Crevice tool • Dusting Brush English - 10... -
Page 11: Operating Cleaner
Operating cleaner STOWING THE POWER CORD When removing the plug from an electrical outlet, grasp the plug, not the cord. CAUTION English - 11... -
Page 12: Operating The On / Off Switch
OPERATING THE ON / OFF SWITCH Handy vacuum cleaner mode • Push the release button, and then separate the handy vacuum cleaner from the body. • Push the power On/Off switch. "Eco Hard Floor" brush and Pipe(Connector for Eco Hard Floor) should be connected to the tip of Pipe, not the end of handle. -
Page 13: Operating The Brush Bar On / Off Switch
OPERATING THE BRUSH BAR ON / OFF SWITCH • Push the power On/Off switch, and then push the brush bar On/Off switch. • The Brush Switch should be in the "On" position for normal carpet cleaning. • Turn the Brush Switch "Off" for bare floor cleaning or other delicate surfaces. When the vacuum is in the upright position, the brush bar does not work. -
Page 14: Using The Vacuum's Handle (The Dust Bin Handle)
USING THE VACUUM'S HANDLE (THE DUST BIN HANDLE) When you carry the vacuum cleaner by the handle, do not push the dust bin release button. CAUTION USING THE ACCESSORY KIT (OPTIONAL) Funiture tool Window tool English - 14... - Page 15 Multiple Angle Stair Tool • Cleaning a narrow corner. • Cleaning a carpet and stairs. • Adjust the multiple angle tool manually. You can rotate the entire tool 90 degrees and change the angle of both wings. English - 15...
- Page 16 Pet Tool • Rake the hair. • Seperate the cover from the pet tool, and then throw the hair away. • Re-attach the cover. English - 16...
-
Page 17: Maintenance
Maintenance EMPTYING THE DUST BIN • Empty the dust bin when dust reaches the 'MAX' mark. • Take the dust bin out by pushing the button on the handle. • To empty the dust bin, hold the dust bin over a garbage can, and then push the button near the bottom of the bin. -
Page 18: Cleaning The Grille
CLEANING THE GRILLE • Push the button. Separate the dust bin from the vacuum's body. • Clean the grille with the dusting brush to remove lint. • To re-attach the dust bin to the vacuum's body, follow steps 3 and 4. English - 18... -
Page 19: Cleaning The Premotor Filter
CLEANING THE PREMOTOR FILTER • Pull the dust bin cover to open. • Remove the filter from the dust bin. • Shake the filter to remove dust, and then wash the filter. • Leave the filter in the shade until completely dry. - Page 20 • Put the filter into the dust bin. Check the filter regularly and wash every 1~2 months. Make sure the filter is completely dry before putting it back into the vacuum cleaner. Allow it to dry for 12 hours. Do not use a wet filter Replace the dust filter if it becomes damaged or deformed.
-
Page 21: Cleaning The Filter
CLEANING THE FILTER • Take the dust bin out by pushing button on the handle. • Remove the filter cover. • Separate the filter from the vacuum's body. • Shake the filter to remove dust. Clean the filter when suction is noticeably and continuously reduced or the vacuum cleaner overheats abnormally. - Page 22 • Re-insert the filter into the vacuum's body. • Re-assemble the filter and filter cover. Click • Re-attach the dust bin to the vacuum. The dust bin will not re-attach to the vacuum if the filter cover is not installed correctly.
-
Page 23: Checking The Brush
CHECKING THE BRUSH • Turn off and unplug the vacuum. Lie the vacuum down so its bottom is accessible as shown. • Carefully cut off any hair or string caught in the brush. Before inspecting the brush bar, turn off the brush bar and unplug the vacuum. CAUTION English - 23... -
Page 24: Checking For Clogs
CHECKING FOR CLOGS • Place a foot on the brush, and then tilt the handle back gently to release the lock. • Push the release button on the brush housing, and then pull the hose out. • Check for clogs in the opening of the brush housing and in the hose. -
Page 25: Emptying The Dust Bin Of The Handy Vacuum Cleaner
EMPTYING THE DUST BIN OF THE HANDY VACUUM CLEANER • Separate the dust bin from the vacuum's body. • Remove the filter and grille. • Empty the dust bin. • Re-assemble the filter and grille. English - 25... -
Page 26: Cleaning The Filter Of The Handy Vacuum Cleaner
• Re-attach the dust bin to the vacuum body. (Align the open lock symbol on the dust bin with the arrow on the body, and then turn the bin counterclockwise so that the closed lock symbol aligns with the arrow.) CLEANING THE FILTER OF THE HANDY VACUUM CLEANER •... - Page 27 • Re-assemble the dust bin. • Re-attach the dust bin to the vacuum body. (Align the open lock symbol on the dust bin with the arrow on the body, and then turn the bin counterclockwise so that the closed lock symbol aligns with the arrow.) Make sure the filter is completely dry before putting it back into the vacuum cleaner.
- Page 28 Troubleshooting Check this list of possible problems and solutions before bringing your vacuum to a service center. PROBLEM SOLUTION • Check the electrical plug. Make sure it is fully plugged in. Cleaner won’t run. • Press the Power on/off button. •...
- Page 29 Product fiche [English] According to Commission Regulation (EU) No 665/2013 and No 666/2013 Supplier Samsung Electronics., Co. Ltd Model SU10F70SA SU10F70SB SU10F70SD SU10F70SQ SU10F70SR Energy Efficiency Class Annual Energy Consumption (kWh/ Carpet Cleaning Performance Class Hardfloor Cleaning Performance Class Dust Re-Emission...
- Page 30 Memo...
- Page 31 Memo...
- Page 32 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. COUNTRY CUSTOMER CARE CENTER WEB SITE 0330 SAMSUNG (7267864) www.samsung.com SOUTH AFRICA 0860 7267864 (SAMSUNG) www.samsung.com DJ68-00709C-05...
