Genelec 7060A Quick Setup Manual page 2

Connection to the 6.1 bass management
GENELEC
Setting the LFE channel reproduction bandwidth
LFE reproduced full range
LFE BANDWIDTH
REDIRECT
SUM IN MODE
LFE + 10 dB
85
TEST TONE
ON
120
85 Hz
Center speaker
Subwoofer
redirect on
Phase alignment
LFE BANDWIDTH
REDIRECT
SUM IN MODE
LFE + 10 dB
85
TEST TONE
ON
120
1.
Switch on the test tone
by setting dip switches 3
and 4 on the left switch
group to “on”. An 85 Hz
signal should be heard
from the subwoofer and
the monitor connected
to “FRONT CENTER”
channel.
Genelec Document BBAQSLSE001. Copyright Genelec Oy 2.2003. All data subject to change.
Optional
slave subwoofer
“SUM IN”
input only
LFE
LFE reproduced up to 85 Hz
85
120
85 Hz
Subwoofer
ROLL-OFF PHASE ROLL-OFF
-2 dB 0/-90 DEG
-4 dB 0/-180 DEG
ON
2. 3.
Toggle the sub- Toggle the sub-
woofer’s dip switch 4 on woofer’s dip switch 3 on
the right switch group the right switch group
“on” and “off” and set it “on” and “off” and set it
to the position which to the position which
gives the lowest sound gives the lowest sound
level at the listening level at the listening
position. position.
Quick setup guide
OVL
ON
GENELEC
GENELEC
L
OVL
ON
GENELEC GENELEC
SL
LFE BANDWIDTH
REDIRECT
SUM IN MODE
LFE + 10 dB
TEST TONE
ON
PHASE ROLL-OFF
-2 dB 0/-90 DEG -2 dB
-4 dB 0/-180 DEG -4 dB
ON
4.
Set dip switch 4 to
the opposite setting.
7060A-7070A-7071A
OVL OVL
ON ON
GENELEC
R
C
OVL
OVL ON
ON
GENELEC
SC SR
LFE reproduced up to 120 Hz
LFE BANDWIDTH
REDIRECT
SUM IN MODE
LFE + 10 dB
85 TEST TONE
ON
120
120 Hz
Subwoofer
PHASE
LFE BANDWIDTH
REDIRECT
0/-90 DEG SUM IN MODE
LFE + 10 dB
0/-180 DEG
85
TEST TONE
ON ON
120
5.
Switch off the test tone.
Be sure to turn off both
switches to disable the test
tone.
