RODEC
TABLE OF CONTENTS
- Specifications
- Installation of the pre-amplifier-mixer
- Pictures on cover
Inputs
symm.
Outputs
- THD:
- Tone controls:
- Subsonic filter:
- Power source:
- Power consumption:
- Approbation:
- Dimensions:
- Weight:
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
MODEL miXboX
SERIAL NUMBER ................................. (on the back of the set)
Please give model and serial number when you request info.
Thank you very much for purchasing the RODEC miXboX mixing panel.
This mixer is a topline-mixing panel, capable of outstanding performance in combination with high-
grade systems.
SAFETY INSTRUCTIONS
1)
Do not expose the set to rain or water. Do not spill liquid or insert (metal) objects inside the
set. Rain, water or liquid such as cosmetics as well as metal, may cause electric shocks,
which can result in fire or shock hazard. If anything gets inside, unplug the power cord.
Input sensitivity
Signal/Noise
< 0.02%
Bass +/-13dB @ 100Hz
Middle +/-13dB @ 1kHz
High +/-13dB @ 10kHz
Standard with an AC-adapter of: 230V / 50Hz-60Hz
On request: 100V-117V / 50Hz-60Hz
OFF=6VA
CE
Front: 203mm x 310mm (8" x 7HE)
Chassis: 197mm x 304mm x 83mm (same height as Technics
3.2kg
Remarks
ON=10VA
MIXBOX
- 2 -
- 2 -
- 3 -
- 3 -
- 4 -
- 5 -
- 6 -
- 6 -
- 23 -
2
