D10D
Model No.
INTRODUCTION TO FISHTRAX™ INTELLIGENT SONAR
FishTrax™ Intelligent Sonar uses SONAR sound waves to detect
depth, locate fish, and define bottom contour, composition and
structure. Using specialized microprocessors, these sound waves
are generated by the FishTrax™ display and sent to the
FishTrax™ Sonar Sensor (Transducer). The sonar sensor, acting
first as a "speaker", emits these sound waves as a series of
pulses.
Then, microseconds later, the sonar sensor switches to
a "microphone" and listens for the return of the pulses as they
bounce off of objects in the water column (referred to as
"echoes"). The "echoes" are sent back to the display where,
using proprietary algorithms in the FishTrax™ software, they are
analyzed for location, size, and composition. These signal are
then arranged by FishTrax's™ Human Interface Software and
displayed in an easy to understand manner on the VirtuView™
HD Color Display.
OPERATION MANUAL
FishTrax™ 1C Fish Finder (FT1PXC)
To ensure safety and many years of trouble-free
operation of your product, please read this
manual carefully before using this product.
- 1 -
