- Page 1 TiLite ZRA ™ Technical Manual 1426 East Third Avenue Kennewick, Washington 99337 Toll Free: (800) 545-2266 Fax: (509) 586-2413 Web: www.TiLite.com SPEC0077 REV A 7/1/03...
- Page 2 TiLite™ ZRA AXLE ASSEMBLY HD100333 - 1/4-28 NYLOCK CP102293 - ZRA CAMBER MOUNT CP102296 - TOE CLAMP 1 1/4 NUT, BLACK ZINC PLATE WEBBED RIGHT HAND CAMBER MOUNT WITH HOLE CP102060 - CAMBERTUBE CP102050 - CAMBERTUBE MOUNT MOUNT MONOTUBE RIGID LT...
- Page 3 CP102046/CP102058 - 1.25 OD X .125 WALL CASTER MOUNT FOR BEARING FORK HD100333 - 1/4-28 NYLOCK NUT CP102093 - ZRA CASTER HD100132 - 8-32 X 3/16" EXTENSION 1/2" SOCKET SET SCREW HD100330 - 1-1/8" CP102048 - CASTER CAP INTERNAL RETAINING...
- Page 4 HD100112 - FOAM GRIP FOR 1" TUBING, .940 I.D. X .125 WALL X 12" LONG CP101296 - XC ARMPIN EXTERNAL THREAD CP102073 - ZRA SPORT ARMREST TUBE LEFT CP101295 - XC ARMRESTPIN INTERNAL THREAD CP102074 - ZRA SPORT ARMREST TUBE RIGHT HD100134 - END CAP 1"...
- Page 5 TiLite™ ZRA ANGLE ADJUSTABLE FOOTPLATE ASSEMBLIES I N G SEE EXTENSION TABLE U N T HD100338 - 1/4-28 X 1-1/2" LONG W I D EXTENSION TABLE FLAT HEAD CAP SCREW, BLACK ZINC PART NUMNBER MOUNTING WIDTH 10¼"-11¼" CP100859 CP100859 11¾"-12¾"...
- Page 6 Doc number: SPEC0082 Revision D Authored By: D. BERRIOCHOA Date: 7/29/04 Approved By:_________________________ Date:_________________ Title: TiLite™ ZRA LOCTITE CHART USE VIBRATITE (RED): 2X BACKREST RELEASE BAR SCREW 2X ARMREST PIN USE VIBRATITE (RED): 2X LUGGAGE CARRIER SCREWS 2X BACKREST EXT. SCREW...
