(187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5" X 10.3" PANTONE 295U 06/28/2013
Krystal Clear
Saltwater System
Model ZS8110
For illustrative purposes only.
Don't forget to try these other fine Intex products: Pools, Pool
Accessories, Inflatable Pools and In-Home Toys, Airbeds and
Boats available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex
reserves the right to change specifications and appearance, which
may result in updates to the instruction manual without notice.
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance, Visit
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
Monday through Friday, 8:30am to 5:00pm Pacific Time
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
Ozone &
TM
IMPORTANT!
www.intexcorp.com
1-800-234-6839
187
187
English
English
PO
PO
187-*PO-R0-1406

Advertisement

Table of Contents
loading

Related Manuals for Intex Krystal Clear ZS8110

Summary of Contents for Intex Krystal Clear ZS8110

  • Page 1 Saltwater System Model ZS8110 For illustrative purposes only. Don’t forget to try these other fine Intex products: Pools, Pool Accessories, Inflatable Pools and In-Home Toys, Airbeds and Boats available at fine retailers or visit our website. Due to a policy of continuous product improvement, Intex reserves the right to change specifications and appearance, which may result in updates to the instruction manual without notice.

  • Page 2: Table Of Contents

    Intex Pools Salt Table............9 Intex Pools Cyanuric Acid Table..........10 Intex Pools Operating Time Table........11 Non-Intex Pools Salt Table........... 12 Non-Intex Pools Cyanuric Acid Table......... 12 Non-Intex Pools Operating Time Table........12 Operating Instructions............13-14 LED Code Chart..............15 Maintenance................16-18 Long Term Storage...............

  • Page 3: Warnings

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • To reduce the risk of injury, do not permit children to use this product. Always supervise children and those with disabilities.

  • Page 4: Parts References

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. SPARE REF.

  • Page 5: Product Information & Specifications

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English HOW THE CHLORINE IS GENERATED This product is specially designed for above ground pools. It will destroy the bacteria, oxidize bather organics and control algae, which provide a safe, clean and comfortable swimming pool. Common salt (sodium chloride) is made up of two elements, sodium and chloride.

  • Page 6: Setup Instructions

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English SETUP INSTRUCTIONS IMPORTANT • The Ozone & Saltwater System requires a separate filter pump [1500~4000 gph (5680~15140 lph)] to drive the water and function properly. •...
  • Page 7 (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English SETUP INSTRUCTIONS (continued) Connecting the system to other types of pump (with different type of thread or no thread): The Ozone & Saltwater System can also be adapted to other filter pumps with different thread or those without a thread on the connection.

  • Page 8: Salt & Pool Water Volumes

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English SALT & POOL WATER VOLUMES • Which kind of salt to use: Use only Sodium Chloride Salts Use only sodium chloride (NaCl) salt that is at least 99.8% pure. It is also acceptable to use water conditioning salt pellets (the compressed forms of evaporated salt).

  • Page 9: Intex Pools Salt Table

    Easy Set & Oval Pool) 3.0g/L (3000ppm) (CODE “91”) (Gals) (Liters) (Lbs) (Kgs) (Lbs) (Kgs) INTEX ABOVE GROUND POOLS (AGP’s) 15' x 33" (457cm x 84cm) 2587 9792 15' x 36" (457cm x 91cm) 2822 10681 15' x 42" (457cm x 107cm) 3284 12430 15' x 48"...

  • Page 10: Intex Pools Cyanuric Acid Table

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English INTEX POOLS CYANURIC ACID TABLE Cyanuric acid is a chemical that reduces the loss of chlorine in water due to ultraviolet rays. To maintain the pool water clear and clean, and to maximize the performance of the device, add cyanuric acid to the pool.

  • Page 11: Intex Pools Operating Time Table

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English INTEX POOLS OPERATING TIME TABLE (WITH CYANURIC ACID) Operating Time (hours) Intex Filter Water Capacity (Calculated at at different ambient/air 90% for Frame Pool and 80% pump for Easy Set &...

  • Page 12: Non-Intex Pools Salt Table

    1.13 10000 37500 12000 1.37 45500 1.59 14000 53000 OPERATING TIME TABLE FOR COMMON NON-INTEX POOLS (WITH CYANURIC ACID) Operating Time (hours) Water Capacity at different ambient/air temperatures 10 - 19°C 20 - 28°C 29 - 36°C (Gals) (Liters) (50 - 66°F) (68 - 82°F)

  • Page 13: Operating Instructions

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English OPERATION INSTRUCTIONS IMPORTANT: To maximize the ozone output of the system, select a daily start time, usually after 10:00am, when humidity is the lowest. 1. Turn on the filter pump. 2.
  • Page 14 For example, the boost operating time is 16 hours, the filter pump should be set to run for 17 hours at least. Increase the filter pump operating time if necessary. Note: If an Intex filter pump is attached to the system, set the pump switch to on “I” position.

  • Page 15: Led Code Chart

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English LED CODE CHART LED Reading Definitions Boost Mode Stand-By Mode (Start-up) Minimum Operating Hour (1 hour remaining) Operating Hours (2 hours remaining) Operating Hours (3 hours remaining) Operating Hours (4 hours remaining) Operating Hours (5 hours remaining) Operating Hours (6 hours remaining)

  • Page 16: Maintenance

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English MAINTENANCE IMPORTANT Unplug the power cord before cleaning your system. Also close the plunger valves on your pool or insert the black hat-like plugs in the strainer opening to prevent water spillage.
  • Page 17 (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English MAINTENANCE (continued) Flow Sensor Cleaning 1. In a counter-clockwise motion unscrew the collar of the flow sensor (7) and remove it from the electrolytic cell conduit. See “Part Reference”. 2.

  • Page 18: Long Term Storage

    5. Pour kitchen grade vinegar into a mug to immerse the titanium plates. Soak them for about one hour and then flush with a garden hose. 6. Reverse steps 3 and 4 to replace the Titanium electrode (5). INTEX 3-WAY TEST STRIPS (PACKED WITH THE PRODUCT) ®...

  • Page 19: Pool Maintenance And Chemical Definitions

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English POOL MAINTENANCE & CHEMICAL DEFINITIONS Preferred Water Chemistry Reading Minimum Ideal Maximum Free Chlorine 0.5 - 3 ppm 5.0 ppm Combined Chlorine 0 ppm 0.2 ppm 7.4 - 7.6 Total Alkalinity 100 ppm...

  • Page 20: Troubleshooting Guide

    • Find out the switch and turn on. • LED failure. • Reset the RCD/GFCI. • Contact Intex Service Center. IMPORTANT If you continue to experience difficulty, please contact our Consumer Service Department for assistance. See separate “Authorized Service Centers” sheet.
  • Page 21 • Ensure that the cell cord is plugged firmly into 3. Electrolytic cell cord is loose. the cell housing receptacle. • Contact Intex Service Center. Replace the cell 4. Possible electrolytic cell failure. if needed. • Partially drain the pool and refill it with fresh 1.

  • Page 22: General Aquatic Safety

    (187PO) MODEL ZS8110 OZONE & SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English GENERAL AQUATIC SAFETY Water recreation is both fun and therapeutic. However, it involves inherent risks of injury and death. To reduce your risk of injury, read and follow all product, package and package insert warnings and instructions.

  • Page 23: Limited Warranty

    Service Center. Upon receipt of the returned product, the Intex Service Center will inspect the item and determine the validity of the claim. If the provisions of this warranty cover the item, the item will be repaired or replaced at no charge.
