(342GS) SAND FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 08/22/2019
IMPORTANT
SAFETY RULES
Please read, understand, and follow all
instructions carefully before installing
and using this product. Keep for future
reference.
, 250 W, Hmax 5 m Hmin 0.19 m IPX4
Z
, 450 W, Hmax 7.5 m Hmin 0.19 m IPX4
Z
, 550 W, Hmax 7.5 m Hmin 0.19 m IPX4
Z
342
English
GS
342-*GS-R0-2008
Advertisement
Table of Contents
Related Manuals for Intex SF80220RC-2
Summary of Contents for Intex SF80220RC-2
- Page 1 Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal –...
-
Page 2: Table Of Contents
Warnings................3 Parts References............. 4-5 Setup Instructions ............6-13 Product Specifications........... 8 Operating Instructions ........... 14-16 Intex Pools Operating Time Table........17 Non-Intex Pools Operating Time Table......18 Maintenance..............19 Long Term Storage............20 Troubleshooting Guide........... 21 Common Pool Problems..........22 General Aquatic Safety........... -
Page 3: Warnings
(342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • Always supervise children and those with disabilities. •... -
Page 4: Parts References
(342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. 23 24 23 28 29 31 "... - Page 5 (342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English SPARE PART NO. REF. NO. DESCRIPTION QTY. SF80220RC-2 SF70220RC-2 SF60220RC-2 PRESSURE GAUGE 11411 11224 11224 6-WAY VALVE 11378 11496 11496 DRAIN OUTLET COVER 11131 11131 11131 CLAMP 11380...
- Page 6 (342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English POOL OUTLET - STRAINER & PLUNGER VALVE SETUP (optional) The strainer grid prevents large objects from jamming and/or damaging the filter pump. If your pool has an inflatable top ring, install the strainer, nozzle and plunger valve before inflating the pool liner top ring.
- Page 7 (342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English POOL INLET - NOZZLE & PLUNGER VALVE SETUP (optional) 1. In a counter-clockwise motion unscrew plunger valve union from the inlet threaded air connector (42) (see drawing 5). Be careful not to lose the step rubber washer (23).
-
Page 8: Setup Instructions
English PRODUCT SPECIFICATIONS The sand filter removes suspended particles but does not sanitize your pool. Pool chemistry is a specialized area and you should consult your local pool service specialist for details. Model: SF80220RC-2 SF70220RC-2 SF60220RC-2 Power: 220-240 Volt AC... - Page 9 • The mounting holes are 6.4 mm in diameter and spaced 210 mm for model SF80220RC-2 (spaced 224 mm for model SF70220RC-2 & SF60220RC-2) apart. • Use two bolts and lock nuts with a maximum of 6.4 mm in diameter.
- Page 10 (342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English SETUP INSTRUCTIONS (continued) Sand loading: IMPORTANT: Use No. 20 silica sand or glass sand with particle size range 0.45 to 0.85 mm (0.018 to 0.033 inches) and a Uniformity Coefficient less than 1.75. Only use the filter media specified by the manufacturer.
- Page 11 (342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English SETUP INSTRUCTIONS (continued) WARNING Improper tank valve and clamp assembly could cause the valve and clamp to blow off and cause serious injury, property damage or death. 6-way valve installation: Lower the 6-way valve over the tank slowly, and ensure the bypass pipe protruding underneath the 6-way valve fits securely into the center pipe hub (7) top opening (see drawing 19).
- Page 12 (342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English SAND FILTER PUMP HOSE CONNECTION SETUP WARNING • Keep this product more than 3.5m away from the pool. • Keep the plug of this product more than 4m away from the pool and at a height of 1.2m at least.
- Page 13 Connect the hose (12) to the pool inlet/outlet connection with a large hose clamp. Tighten securely. LARGE HOSE CLAMP POOL For INTEX pool with 1-1/4” (32mm) connections/hoses: Make sure the air jet valve (41) is securely tighten onto the pool inlet air adaptor (43) and facing (Adaptor B) (Adaptor B) Page 13...
-
Page 14: Operating Instructions
(342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English OPERATING INSTRUCTIONS WARNING • Risk of electric shock. Connect this product only to a grounding type receptacle protected by a ground-fault circuit interrupter (GFCI) or residual current device (RCD). Contact a qualified electrician if you cannot verify that the receptacle is protected by a GFCI/RCD. - Page 15 “BACKWASH” under “initial startup and operation” section. Vacuuming device (i.e. Intex auto pool cleaner) attached to the system may also cause the flow to diminish and the pressure to rise. Remove any vacuuming device from the system and check if the pressure gauge reading has dropped from the yellow zone to the green zone.
- Page 16 (342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English OPERATING INSTRUCTIONS (continued) Operating the system under “TIMER” mode or manually: To operate the sand filter pump in “FILTER” mode under “TIMER” control: 1. Activate the unit: Press button.
-
Page 17: Intex Pools Operating Time Table
This table shows the required operating time for average use of the sand filter pump with above ground pools. If the system is attached to an “Intex Saltwater System” unit, the filter pump running time should be longer than the required operating time of the Intex Saltwater System unit. -
Page 18: Non-Intex Pools Operating Time Table
(342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English NON-INTEX POOLS OPERATING TIME TABLE This table shows the required operating time for average use of the sand filter pump with above ground pools. Water Capacity Sand filter pump operating time (For one cycle) / (Hours) -
Page 19: Maintenance
(342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English MOTOR PRE-FILTER CLEANING AND MAINTENANCE It is essential to change any damaged element or set of elements as soon as possible. Use only parts approved by the manufacturer. 1. -
Page 20: Long Term Storage
(342GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 08/22/2019 English POOL CARE & CHEMICALS • All pools require care to keep the water clear and hygienically clean. With proper chemical control, your filter will help attain this objective. Consult your pool supply dealer for instructions regarding the proper use of chlorine, algaecide and other chemical agents required for sparkling clear water. -
Page 21: Troubleshooting Guide
• An air leak on the intake hose. • Tighten hose nuts, check hose for damage. • Faulty motor or the impeller is jammed. • Contact Intex service center. • Sand tank o-ring missing. • Remove 6-way valve cover and ensure the o-ring is in place. -
Page 22: Common Pool Problems
• Finger tighten all caps. • The drain valves are loose. SEDIMENT • Dirt or sand on • Heavy use, getting in • Use Intex pool vacuum to clean ON POOL pool floor. and out of pool. bottom of pool. -
Page 23: Limited Warranty
Other than this warranty, and other legal rights in your country, no further warranties are implied. To the extent possibly in your country, in no event shall Intex be liable to you or any third party for direct or consequential damages arising out of the use of your Sand Filter Pump, or Intex or its agents’...
