SERVICE MANUAL
1、 Caution ....................................................................................
2、 Specification ..............................................................................
3、 BOM list ....................................................................................
4、 Alignment Procedure ..................................................................
5、 Block Diagram ...........................................................................
6、 Schematic Diagram .....................................................................
7、 PCB Layout ..............................................................................
8、 Explode View Diagram ...............................................................
This manual is the latest at the time of printing, and does not
include the modification which may be made after the printing, by
the constant improvement of product.
M70(NTSC)
MODEL 14DN2NYD

Advertisement

loading
Need help?

Need help?

Do you have a question about the 14DN2NYD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Disney 14DN2NYD

Summary of Contents for Disney 14DN2NYD

  • Page 1 M70(NTSC) SERVICE MANUAL MODEL 14DN2NYD 1、 Caution ………………………………………………………………………… 2、 Specification …………………………………………………………………… 3、 BOM list ………………………………………………………………………… 4、 Alignment Procedure ………………………………………………………… 5、 Block Diagram ………………………………………………………………… 6、 Schematic Diagram …………………………………………………………… 7、 PCB Layout …………………………………………………………………… 8、 Explode View Diagram ……………………………………………………… This manual is the latest at the time of printing, and does not include the modification which may be made after the printing, by the constant improvement of product.
  • Page 2 TTE Overseas Support Department 1. Cautions When working, the unit is with ultra high voltage about 21.8KV inside. So, to avoid the risk of electric shock, be careful to adjust the chassis! 1. Only qualified personnel should perform service procedures. 2.

  • Page 3: Specification

    >2X1.5W +Speaker Size User Interface +Interface Name UI-SOEM-DU1 +Voice Control Disney cartoon Icon w/motion +Menu Disney Icon w/High light Control +Menu Colours Multi-color (minimum 7 color per character/total 64 colors) +Menu Languages English,French,Spanish, +Menu Languages(default) English +Special Features Child lock, TV guardian（1st version:no, 2nd version: t.b.c.,running change to...
  • Page 4 Styling +Cabinet Name Disney--Pooh main set w/Pooh head + color TV shoe +Configuration +Graphics/Logo's "Disney"--color printing t.b.c +Cabinet Colour and Finish +Mechanics FC: main tooling w/tooling module 1 for 3 frent keys BC: main tooling w/tooling modulle 2 for Jacks...
  • Page 5 +Power in "OFF" for +INDICATION on BACKCOVER Rating labe: Model no./Voltage rating/UL,FCC mark, Warning (caution) +INDICATION on set warning label for detachable speakers/ Disney customer service number/Serial No./UPC bar code/Made in ?/ +Channel Miscellaneous +EAN Indication FCC Part 15 sub B, FCC/FDA (USA),...
  • Page 6 TTE Overseas Support Department Final Equipment +Packaging - methods Carton/ polyfoam/ plastic bag IB+WC( paper 190Lb) +Documents and manuals +IB/WC Languages IB:English, Spanish, French; WC: English,French Draft IB and WC provided by Memorex co, referring to Orion IB/WC +IB/WC SIZE +Cables Supplied +Antenna Supplied +Band and screw Supplied...
  • Page 7 TTE Overseas Support Department 3.BOM List Item No. Description BOM text Remark T8-EDN2AY-MANSM ASS"Y - MAIN BOARD T8-EDN2AY-CRY CRT BD 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D501 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D502 11-SC2482-0BX TRANSISTOR 2SC2482 1 Q503 11-SC2482-0BX TRANSISTOR 2SC2482 1 Q502 11-SC2482-0BX TRANSISTOR 2SC2482...
  • Page 8 TTE Overseas Support Department 26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C502 26-EBP331-JCX CAP. CER 330PF 50V +/-5% CH 1 C501 40-M70002-CRB1X P.C.B. CRT BD 46-10967W-01X PIN BASE *1 TJC1-1A 1 P531 46-35179W-04X PIN BASE TJC3-4A 1 P502 46-33079W-05X PIN BASE *5 TJC3-5A 1 P501 47-CRT009-CX0...
  • Page 9 TTE Overseas Support Department 46-35148H-02X HS 2P24 200 TJC3-2Y/SCN-2Y 1 P003 46-CD025T-07J02 HS 7PIN 1 P002A 48-TAC001-XX0 TACT SWITCH 1 S002 48-TAC001-XX0 TACT SWITCH 1 S006 48-TAC001-XX0 TACT SWITCH 1 S005 48-TAC001-XX0 TACT SWITCH 1 S004 48-TAC001-XX0 TACT SWITCH 1 S003 48-TAC001-XX0 TACT SWITCH 1 S001...
  • Page 10 TTE Overseas Support Department 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C603 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C606 25-BDA471-M1X CAP. ELEC 470 UF 25V +/-20% 1 C604 25-BDB220-M1X CAP. ELEC 22 UF 25V +/-20% 1 C617 27-MBC474-J0X CAP.
  • Page 11 TTE Overseas Support Department 09-38C3V9-DTX SMD.DIODE BZX384-C3V9 115 1 D304 09-38C2V4-DTX SMD.DIODE 2.4V 1 D307 09-BAS316-ATX SMD.DIODE BAS316 115 1 D306 09-BAS316-ATX SMD.DIODE BAS316 115 1 D302 09-BAS316-ATX SMD.DIODE BAS316 115 1 D305 09-BAS316-ATX SMD.DIODE BAS316 115 1 D404 09-BAS316-ATX SMD.DIODE BAS316 115 1 D303 10-0FR104-FBX...
  • Page 12 TTE Overseas Support Department 18-FG0122-JAX RES. M.O.F 1.2K OHM 2W +/-5% 1 R414 18-FF0221-JAX RES. M.O. 220 OHM 1W +/-5% 1 R336 18-CE0330-JAX RES.C.F 33 OHM 1/2W +/-5% 1 R412 18-RF0109-JAX RES.C.C. 1W 1OHM +/-5% 1 R301 18-DF0159-FAX1 RES. M.F.1W 1.5 OHM/+/-1% 1 R309 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603...
  • Page 13 TTE Overseas Support Department 26-AIC391-KBX CAP. CER 390 PF 500V +/-10% B 1 C412 26-AIC391-KBX CAP. CER 390 PF 500V +/-10% B 1 C409 26-AMK331-KRX CAP. CER 330 PF 2KV +/-10% 1 C402 26-ABC102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C401 26-ABC563-ZFX CAP.
  • Page 14 TTE Overseas Support Department 09-BAS316-ATX SMD.DIODE BAS316 115 1 D309 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 1 J314 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 1 J406 18-CE0152-JNX RES. C.F. 1.5K OHM 1/2W +/-5% 1 R315 37-SC2502-07Q01 FBT BSC25-0207Q 1 T402 T8-EDN2AY-MAN...
  • Page 15 TTE Overseas Support Department 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 1 J031 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 1 J030 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 1 J027 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 1 J026 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603...
  • Page 16 TTE Overseas Support Department 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 1 R044 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 1 R010 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 1 R008 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 1 R004 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 1 R002...
  • Page 17 TTE Overseas Support Department 19-AB0393-JTX SMD. RES 39K OHM 1/10W +/-5% 1 R204 19-AB0470-JTX RES SMD 47 OHM 1/10W +/-5%0603 1 R013 19-AB0470-JTX RES SMD 47 OHM 1/10W +/-5%0603 1 R014 19-AB0102-JTX RES SMD 1K OHM 1/10W 0603 1 R026 19-AB0223-JTX SMD.
  • Page 18 TTE Overseas Support Department 27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% 1 C238 27-MBC474-J0X CAP. M.P.E 0.47UF 63V +/-5% 1 C222 27-PBC152-J0X CAP. P.E 0.0015UF 63V +/-5% 1 C201 28-AB0101-JCX SMD. CAP 100 PF 50VDC +/-5% 1 C239 28-AB0102-JCX SMD. CAP 1000PF 50V +/-5% 0603 1 C243 28-AB0102-KBX SMD.
  • Page 19 TTE Overseas Support Department 28-AB0150-JCX CAP.SMD 15P 50V +/-5% 0603 1 C024 28-AB0221-JCX CAP.SMD 220PF 50V C 0603 +/-5% 1 C008 28-AB0221-JCX CAP.SMD 220PF 50V C 0603 +/-5% 1 C007 28-AB0221-JCX CAP.SMD 220PF 50V C 0603 +/-5% 1 C009 28-AB0222-KBX CAP.SMD 2200PF 50V +/-10% 0603 1 C207 28-AB0330-JCX...
  • Page 20 TTE Overseas Support Department 40-M70001-MAE1X P.C.B MAIN BD 41-BF0100-0GG WIRE 1007#24 100MM 1 A1 TO A2 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J219 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J008 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J007 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J017 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM...
  • Page 21 TTE Overseas Support Department 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J203 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J221 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J213 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J214 41-WJ0150-B00 WIRE BARE JUMPER 15MM 1 J024 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J222 41-WJ0200-B00...
  • Page 22 TTE Overseas Support Department 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J115 28-AB0101-JCX SMD. CAP 100 PF 50VDC +/-5% 1 C109 28-AB0101-JCX SMD. CAP 100 PF 50VDC +/-5% 1 C110 19-AB0223-FTX SMD. RES 22K OHM 1/10W +/-1% 1 R202A 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 N201 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603...
  • Page 23 TTE Overseas Support Department 12-BC847A-0BX SMD TRANSISTOR BC847A (NPN) 1 Q845 12-BC857B-0BX PNP SMD. TRANSISTOR BC857B 215 1 Q852 13-000TL4-31T IC TL431ACLP 1 IC803 13-0HPC92-2CP PHOTO COUPLER HPC922-C 1 IC802 13-0L7805-CVS +5V 1.5A IC L7805CV 1 IC402 13-TEA150-6TB IC TEA1506T/N1 118 1 IC801 18-CD0101-JNX RES.
  • Page 24 TTE Overseas Support Department 19-AB0681-JTX SMD. RES. 680 OHM 1/10W 0603 1 R835 19-AB0683-JTX RES SMD 68K OHM 1/10W 0603 1 R853 22-NTC479-XX0 NTC 4.7 OHM +/-18% NTC4.7D2-14 1 R803 22-PTC909-3A5 PTC 9 OHM 1 RT801 25-BCA102-M1X CAP. ELEC 1000 UF 16V +/-20% 1 C843 25-BCA102-M1X CAP.
  • Page 25 TTE Overseas Support Department 28-AB0103-KBX SMD. CAP 0.01 UF 50V +/-10% 0603 1 C417 28-AB0103-KBX SMD. CAP 0.01 UF 50V +/-10% 0603 1 C852 28-AB0103-KBX SMD. CAP 0.01 UF 50V +/-10% 0603 1 C844 26-ABC103-ZFX CAP. CER 0.01 UF 50V +80-20% F 1 C831 26-ABC103-ZFX CAP.
  • Page 26 TTE Overseas Support Department 12-BC847A-0BX SMD TRANSISTOR BC847A (NPN) 1 Q841 12-BC847A-0BX SMD TRANSISTOR BC847A (NPN) 1 Q842 18-CE0330-JNX RES. C.F. 33 OHM 1/2W +/-5% 1 R867 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 1 R846 19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 1 R847 19-AB0473-JTX SMD.
  • Page 27 TTE Overseas Support Department 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 1 J823 36-TRF228-AX0 TRANSFORMER CONV.BCK-2872 1 T803 T8-EDN2AY-RAY REAR AV 12-BC847B-0BX NPN SMD. TRANSISTOR BC847B 215 1 Q901 12-C124ET-0BX SMD. TRANSISTOR PDTC124ET 1 Q903 13-EF4053-BTB IC HEF4053BT(D) 1 IC901 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 1 J903...
  • Page 28 TTE Overseas Support Department 33-KLN601-NTX CHIP BEAD 600 OHM +/-25% 1 L931 33-KLN601-NTX CHIP BEAD 600 OHM +/-25% 1 L933 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J906 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J905 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 L932 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 L934...
  • Page 29 TTE Overseas Support Department 25-BFB101-M1X CAP. ELEC 100 UF 50V +/-20% 1 C107 25-BFB101-M1X CAP. ELEC 100 UF 50V +/-20% 1 C103 25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 1 C101 28-AB0103-KBX SMD. CAP 0.01 UF 50V +/-10% 0603 1 C108 28-AB0103-KBX SMD.
  • Page 30 TTE Overseas Support Department 46-33079W-02X PIN BASE *2 TJC3-2A 1 P003A 48-TAC002-XX0 TACT SWITCH 1 S007A T8-EDN2AY-CRT CRT PARTS 02-GND014-XX0 ASS"Y - CRT GND WIRE&HOUSE 1 GROUND 36-DEG140-AX3 DEGAUSSING COIL XC-38 1 T805 44-14OFLP-IR1A 14"CRT 37SX110Y22-DC15 1 CRT 46-20600H-04X HS 4P A/B 360/13 RBGW TJC1-4Y 1 W401 57-10654X-00F TWIST TIE NY66...
  • Page 31 ASS"Y - PACKAGING T8-EDN2AY-PANZ PACKAGING ASSEMBLY 74-081081-80H POLYBAG (81CMX81CM) 76-426220-0AT1A CARTON BOX 74-020030-62C1A PLASTIC BAG 72-EDN2AY-E121A OPERATION MANUAL 70-DISNEY-WAR1B WARRANTY CARD 71-DISNEY-CAU1A LABEL 58-EDN2MP-JKT1A PLATE MODLE NO. 74-008022-60C PLASTIC BAG For left/right decorate foots 74-030050-50H PLASTIC BAG 500X300MM For sound box...

  • Page 32: Alignment Procedure

    TTE Overseas Support Department 4.Alignment Procedure Ⅰ. Summarize M70 is a chassis based on TB1238AN and SDA55XX. In trial run, burn the latest software to SDA5555 which has a 128KByte flash memory. At least after the first batch production, make the mask， please take care in production.

  • Page 33: Ⅱ. Alignment Contents

    Check the voltage across C835, it should match the below table or check the mains supply building block. Model Mains supply (V) 14DN2NYD 44-140FLP-IR1A 108±3 2. AFT adjustment: Cut off the RF signal and input a 45.75MHz (for NTSC set) color bar signal to the IF pin of tuner (pin11).
  • Page 34 TTE Overseas Support Department SIGNAL 50 OHM TUNER 105dBuV GENERATOR ATTENUATOR NETWORK 4. VG2 & Focus voltage adjustment 1) Apply a crosshatch pattern signal in nominal status. Enter Factory mode，press “CC” button to stop vertical scan. (Note：RCUT/GCUT/BCUT should be preset to 80，and GDRV/BDRV to 40) 2) Adjust the SCRREEN potentiometer (nether one) on the line output transformer to make a horizontal shining line just visible on the screen.
  • Page 35 EHT/HEW Expected Result: should match the requirements below： Model RATIO EHT(0uA)(KV) HEW(0Ua)(V) 14DN2NYD 44-140FLP-IR1A 37-SC2502-07Q01 22.5±1.5 21.0±1.5 1071±3% 9. X-rays over protecting circuit test: Turn on the TV and wait for the screen lighted up, then apply a 26V DC voltage across C431，the set should enter protecting mode，or check X-ray protecting circuit.
  • Page 36 Model Power on Standby Less than 5W 14DN2NYD ±5% 12. EHT Range test (random test) Instruments： High voltage meter， Ib meter. Input signal pattern：...
  • Page 37 TTE Overseas Support Department 13. Heater voltage test (random test) Instruments： RMS voltage meter Input signal： White pattern Input signal intensity： 1mVrms（60dBuV）to 50mVrms Connect the RMS voltage meter across CRT filament, set contrast, brightness to max, test the heater voltage and it should meet：6.3±0.3Vrms 14.
  • Page 38 PAGE 0 Data BACK Model COLOR OSD HL OSD HH OSD VL OSD VH CLKL CLKH TXCX RGCN 14DN2NYD 14DN1NYD Data PAGE 1 Model RCUT* GCUT* BCUT* GDRV* BDRV* 14DN2NYD 14DN1NYD Data PAGE 2...
  • Page 39 TTE Overseas Support Department PAGE 6 Data Model SHPX SHPN SHPTV3 SHPAV3 SHPTV4 SHPAV4 14DN2NYD 14DN1NYD PAGE 7 Data Model VOL01 VOL25 VOL50 VOL100 14DN2NYD 14DN1NYD Data PAGE 8 Model SWITCH THEME TUNER POWER MODE INIT USER 14DN2NYD 14DN1NYD Data...
  • Page 40 TTE Overseas Support Department Ⅲ. CDRH Document 1. Testing for EHT and HEW EHT(Ib=0uA) HEW(Ib=0uA) Model RATIO (KV) 14DN2NYD 44-14OFLP-IR1A 37-SC2502-07Q01 22.5±1.5 21.0±1.5 1071±3% 2. The Value of Sample Register in X-ray protection circuit Model Designator value R254/R255 390Ω/120Ω 14DN2NYD...

  • Page 41: Block Diagram

    TTE Overseas Support Department 5. Block Diagram...
  • Page 42 6.Schematic Diagram...
  • Page 43 7.PCB Layout...
  • Page 45 8.Explode View Diagram...
