Sage Water Dispenser
Instruction Manual
SAGE WATER COOLERS
Please read this manual carefully before using!
CONTENTS
(1) Brief Introduction of the Appearance
(2) Touch panel Introduction
(1) Overview
(2) Water supply connection
(1)
nitially connected to electrical source
I
(2) First time Operation
(3) Operating the dispenser
(4) Setting parameter options
5. Machine maintenance and parts replacement
1. Replacing parts
2. Clear airframe
6. FAQ
1
Advertisement
Summary of Contents for Sage SAGECRDM
-
Page 1: Table Of Contents
CONTENTS Sage Water Dispenser 1. Brief Introduction of The Machine Instruction Manual (1) Brief Introduction of the Appearance (2) Touch panel Introduction 2. Technical Parameter 3. Installation (1) Overview (2) Water supply connection 4. Operation nitially connected to electrical source... -
Page 2: Brief Introduction Of The Machine
(2).Touch Panel Introduction 1. Brief Introduction of the Machine (1) Brief Introduction of the Appearance 1. Touch Panel 9. Condenser 2. Cover of the Drip Tray 10. Heating Switch 3. Drip tray 11. Water Inlet Whole Day - Month - Year 4. - Page 3 The capacity is calculated under ambient temperature of 25 degrees and the water inlet temperature of 25 degrees. Note: Sage Water reserves the right to change any product specifications and parameters without notice and without incurring any obligations or liabilities...
-
Page 4: Technical Parameter
2. Technical parameter 3.Installation (1). Machine parameter (1). Overview (2).Theoretical sketch: Please install the machine in a place of cool, ventilation and soundness, but away from hot objects. Keep the unit 10cm(4") away from the wall and leave enough space for both sides of the unit. -
Page 5: Operation
(Picture 3) (Picture 4) (Picture 5) 4. Operation (1) Initially Connect with Electric Supply Once connected to power, the screen display will appear, means it is testing the unit. Interface should appear as shown below. After entering into initial adding water interface, follow the instructions to add water to both hot tank and cold tank. - Page 6 Hot Water ① ，then touch When setting with the child lock, first touch . You can get hot water after 3 seconds. Touch any button to stop the water flow. Warm Water: Touch for mixed hot/cold water, touch any key to stop the water flow. ②...
- Page 7 A. Enter the Setting Interface ① Press to enter the setting interface and follow to the interface prompts. Setting interface includes temperature settings, water settings, time and date settings, energy saving mode, child lock settings, filters and UV change settings, language settings, ring settings and restore factory settings.
- Page 8 D. Time Settings (year - month - day) Select Calendar settings, enter into the time adjustment interface and follow the prompts to set the parameters, as follows: ② Automatic On/Off Switch Then press to save parameters E. Energy Saving Mode Select energy-saving mode, enter into power saving mode adjustment Standby mode, will appear similar to screen below: Interface and follow the prompts to set parameters as follows:...
- Page 9 F. Child Lock Settings H. Language Settings Select the Child Lock setting and enter into the child lock adjustment Interface. Follow the prompts to set parameters, as follows: I. Ring Settings G. Filter / UV Maintenance Settings Select Filter / UV maintenance setting item, enter into the filter / UV maintenance adjustment interface, and follow the prompts to set parameters, as follows: ①...
- Page 10 5. Maintenance And Replacement of Machine Parts (1). Replacement A. Filter maintenance Filter should be replaced approximately every 6 months (about 2,000 liters of water), when the filter is reaches its lifetime, the unit will remind you to replace the filter. Enter into the setting mode after replacing the filter - filter / UV maintenance - filters - filter replacement and press Confirm B.
- Page 11 in the socket. use and maintenance during the operation and use the safety of electrical equipment . ◎ When using the unit for the first time (or cleaned), pleas e ensure there is water flowi ng out, and then open the heating function to avoid equipment damage! ◎...
-
Page 12: Troubleshooting
Please note: If the unit is connected with electricity, do not get ·Long-term of not using, turning on power use the back of the machine wet. cold water tank frozen ·Drip tray is full ·Empty water drip tray Machine ·Leakage inside ·Turn off the power and water, please leaking...
